Item Description
This option is used to set the GPO_3 signal when PRINT END.
Selections
Off
Applicator Port
Mode 1
The applicator port is off.
Label Label
format format
sent processed
Data
ready
(Pin 14,
GPO_6)
Print
start
(Pin 3,
GPI_1)
Print
End
(Pin 11,
GPO_3)
Description
Waiting Label prints Ready
for start for next
print label
signal
Default
Not ready
Off
Ready
Do not start
Start
Do not end
End
