Label
format
sent
Data
ready
(Pin 14,
Mode 4
GPO_6)
Print
start
(Pin 3,
GPI_1)
Print
End
(Pin 11,
GPO_3)
Use GPIO setting commands for customized settings. For GPIO command, please
Customized
refer to TSPL/TSPL2 programming manual.
Label
Waiting
Lab el prints
format
for start
processed
print
signal
Ready for
next label
Not
ready
Ready
Do not
start
Start
Do not
End
End
63
