S-5504-TRM
Elm
Tub/Hand Shower Trim
™
Operation & Maintenance Manual
Operation
Temperature Control
1) Turn shower handle counterclockwise approximately
1/4 turn to put valve in cold position.
2) Turn shower handle counterclockwise approximately
1/2 turn to put valve in warm position.
3) Turn shower handle counterclockwise approximately
3/4 turn to put valve in hot position.
Symmons Industries, Inc.
6
©2014 Symmons Industries, Inc.
■
■
31 Brooks Drive
Braintree, MA 02184
■
www.symmons.com
Diverter Control
1) Turn diverter lever left for tub spout operation.
2) Turn diverter lever right for hand shower operation.
■
Phone: (800)796-6667
■
■
gethelp@symmons.com
ZV-3029 REV A 082114
■
Fax: (800)961-9621
