Torque
Power Source
Factory Mounted
Accessories
Control Input
Travel and Timing
2 M Motor Actuators—M100C Series of Motor Actuators
The following table lists the torque rating for each model
(MXXXCYZ—where X = Model No.):
Table 1: Torque Ratings
MODEL DESCRIPTION
M110 25 in·lb (2.8 N·m) Torque with Spring Return
M120 35 in·lb (4.0 N·m) Torque, Non-Spring Return
50 in·lb (5.6 N·m) Torque with Spring Return
M130
M140 75 in·lb (8.5 N·m) Torque, Non-Spring Return
M150 150 in·lb (17 N·m) Torque, Non-Spring Return
The following table lists the input voltage options available
(MXXXCYZ—where Y = Power Source Option):
Table 2: Input Voltage Options
OPTION DESCRIPTION
A 120 VAC
D 240 VAC
G 24 VAC
H 24 VAC 1:1 Isolation
The following table lists the factory mounted accessories available
(MXXXCYZ—where Z = Accessory Option):
Table 3: Factory Mounted Accessories
OPTION DESCRIPTION
A No auxiliary switch
B One SPDT switch S91DJ-1 installed on auxiliary end of M100
Two SPDT switches S91EJ-1 installed on auxiliary end of M100
C
D S91 Potentiometer (1000 ohm) installed on auxiliary end of M100
M100C Actuators receive and interpret digital commands from a
controller for accurate positioning of the output shaft. The M100CAA-2 is
a dual direct and reverse action model replacing the M100CAA-1 (direct
acting only) and M100DAA-1 (reverse acting only) models.
The M100C Motor Actuator travel is factory set at 90 degrees and is field
adjustable from 65 to 270 degrees.
The timing of the actuator is 38 seconds for 90 degree rotation and
60 seconds for 160 degree rotation.
