WAREMA WMS Splitter UP Operating And Installation Instructions page 3

Maintenance
There are no parts inside the device that require mainte-
nance.
Cleaning
Clean the housing with a soft, dry cloth. Do not use deter-
gents, cleaning agents, solvents, abrasive substances or
steam cleaners!
Liability
Failure to comply with the product information contained in
these instructions and any use of the device other than its
intended use and purpose may result in the manufacturer
refusing to honour warranty claims for product damage.
In this case, liability for secondary harm to persons or
damage to property will also be excluded. Also observe
the information in the operating instructions for your sun
shading system. The automatic or manual operation of
the sun shading system when iced over as well as use of
the sun shading system during severe weather may cause
damage and must be prevented by the user by taking
suitable precautions.
Obligations for the disposal of electrical
devices
A marking with this symbol indicates the following
obligations under the scope of legal regulations:
The owner of this electrical device must dispose of it
separately from unsorted municipal waste for further
recycling.
Used batteries and accumulators that are not enclosed
in the old device, as well as lamps/bulbs that can be
removed from the old device without breaking, must be
disposed of separately.
Distributors of electrical devices and disposal companies
are obliged to take back the equipment free of charge.
The owner must take it upon themselves to delete any
personal data contained in the electrical device prior to
disposal.
warema_2029464_alhb_en_v6•2022-11-01
Technical data
WMS Splitter UP
Supply
Operating voltage
Current consumption
at 24 V DC
Output
WAREMA climatronic® bus
connection
Input control
Local voltage active
Local current active
Local voltage inactive
RF transceiver
Transmission frequency
Transmission power
Reception sensitivity
Operating range
(environment without inter-
ference)
Housing
Dimensions in mm
(LxWxH)
Degree of protection
Safety class
Miscellaneous
Conformity
This device meets the EMC directives for use in residential and
commercial areas.
WAREMA Renkhoff SE declares herewith that this radio
system type
WMS Splitter UP
guideline
2014/53/EU.
Ambient conditions
Operating temperature
Storage temperature
Humidity
(not condensing)
Degree of soiling
Connection
Power supply
Network
Floating switch
Article numbers
WMS Splitter UP
WAREMA Renkhoff SE
Hans-Wilhelm-Renkhoff-Strasse 2
97828 Marktheidenfeld
Germany
We reserve the right to make technical modifications
Min. Typ. Max. Unit
21.6 24 26.4
15
RS485
8 24 38
0.4 1.3 2.1
-0.5 0 3
2.40 2.48
<10
-101
30
49 x 49 x approx. 20 mm
Available at www.warema.de/ce
is in compliance with the
-20 60
-20 60
10 40 85
Spring terminals 0.6...0.8 mm ∅
Spring terminals 0.6...0.8 mm ∅
Spring terminals 0.2..1.5 mm²
2020 921
V DC
mA
V DC
mA
V DC
GHz
dBm
dBm
m
IP30
III
°C
°C
%H
rel
2
3
