- Page 1 TDR-P USER MANUAL TDR5-P TDR7-P TDR8-P WARNING Read the instructions before using the machine. EN (Original Instructions) 9123872 / 1903...
- Page 2 TDR-P KEEP THIS USER MANUAL FOR FUTURE USE © 2019 Fri-Jado BV, Oud Gastel, The Netherlands. We advise you to contact your supplier for the guarantee period and conditions. Further we refer to our General Terms and Conditions for Sales and Delivery that are available upon request.
- Page 3 TDR-P Empty page. 3 / 48...
-
Page 4: Table Of Contents
TDR-P CONTENTS INTRODUCTION ......................6 General ..........................6 Identification of the unit ..................... 6 Pictograms and symbols ....................6 Safety instructions ......................7 1.4.1 General ........................7 1.4.2 Moving ......................... 8 1.4.3 Outdoor use restrictions ....................8 Hygiene ..........................9 Service and technical support ................... - Page 5 TDR-P Operation options ......................23 5.2.1 Pre-heat function ....................... 23 5.2.2 Continues pre-heat function ..................23 5.2.3 To end a running program..................24 5.2.4 Check the actual temperature ..................24 5.2.5 Check the remaining time in a program ..............25 5.2.6 Show all actual program information ................
-
Page 6: Introduction
TDR-P INTRODUCTION General This manual is intended for the user of the TDR-P . The features and controls are being described, along with directions for the safest and most efficient use, in order to guarantee a long life of the unit. All pictograms, symbols and drawings in this manual apply to all available TDR-P models. -
Page 7: Safety Instructions
TDR-P Safety instructions WARNING The outside of the unit can be very hot. WARNING The maximum load on top of the unit may never exceed 50 kg (110 lbs.). WARNING Risk of slippery floor: Spills may cause slippery surfaces, clean-up promptly WARNING Always use the brakes on both front wheels: 1.4.1... -
Page 8: Moving
TDR-P 1.4.2 Moving When moving the unit: Before moving the unit, first switch off the mains voltage by pulling the plug from the wall socket and empty the fat collecting drawer. After that, cool-down the unit for at least ten minutes. -
Page 9: Hygiene
TDR-P Hygiene The quality of a fresh product always depends on hygiene. Especially grilling products. With the risk of salmonella contamination – especially for chicken products – you must make sure that grilled products can never be mixed with uncooked products. Also contact between grilled products and hands or tools that have been in contact with raw chicken meat, must be avoided at all times. -
Page 10: Description Of The Unit
The control has a capability to store 99 different programs. Communication through USB enables easy read-out, re-work and creating of programs via a PC. For this, special software is available at Fri-Jado. Intended use The TDR has been designed for grilling meat products. Any other use will not be regarded as intended use. -
Page 11: Installation And First Use
TDR-P INSTALLATION AND FIRST USE All packing materials used for this unit are suited for recycling. After unpacking, check the state of the unit. In case of damage, store the packing material, and contact the transporter within fifteen working days after receiving the goods. Unpacking the unit Your unit is packed in a plastic top cover, protective corners and a carton box around it. -
Page 12: Dismantling The Pallet
TDR-P Dismantling the pallet For proper unpacking the unit, the pallet must be taken apart. Installation and positioning WARNING Position the unit on a flat and horizontal surface. A temporally inclined plane of maximum 5° is allowed. The user must have sufficient freedom of movement to properly operate the unit. ... -
Page 13: First Use Program
TDR-P First use program When using the unit for the first time, clean the interior thoroughly with soap suds and heat up the unit, see section 3.4.1. After commissioning discoloration of the cooking/grilling area can occur. The cleaning remains will find its way to the fat collection drawer, so this drawer must be cleaned and emptied after cleaning the unit. -
Page 14: Metal Odor
TDR-P Place the bottom plates in the grilling compartment. Bottom Plates 3.4.1 Metal odor To remove the metal odor that will appear at first use, the unit must be heated at the maximum temperature (250°C/482°F) for at least half an hour (a “first use” program is pre-set at position 99). 14 / 48... -
Page 15: Operation And Use
TDR-P OPERATION AND USE Control Panel ON/OFF UNDO LIST FORWARD BACK ROTOR Functions of the controls Button Function ON / OFF Switching the unit on / off UNDO Go back to previous menu LIST Recipe / Programming modus FORWARD One step ahead in setting ROTOR Switching the rotor ON Acknowledge a function or change... -
Page 16: Switching-On The Unit
Whole uncut chickens should always be grilled using the meat forks. This way their natural fat will baste each other, giving a perfectly slender cooking result. Refer to the You-Tube movie: “Fri-Jado instruction for binding and loading chicken”. 16 / 48... - Page 17 TDR-P For preparing chicken or any other poultry, you can work as follows: Insert one point of the meat fork through the chest at the position of the wings. Insert the other point through the drum sticks. Don’t forget to include the wings. Leave some space between the products, for an even exposure and browning.
-
Page 18: Loading The Rotisserie Using V-Shape Spits (Accessory)
TDR-P 4.3.2 Loading the rotisserie using V-shape spits (accessory) If you are using V-shape spits act as follows: Place the skewer into the small outside hole on the rotor end plate on your left (as you face the oven). The back of the V-shape spit should be pointing towards you. ... -
Page 19: Loading The Rotisserie Using Two Different Accessories
Take the meat fork at its other end and take it out of the unit. Remove the products from the meat fork. Refer to the You-Tube movie: “Fri-Jado instruction for unloading chicken from a rotisserie”. 4.5.2 Taking out the V-shape spit (accessory) For taking out the V-shape spit you can use the same principle as described in section 4.5.1. -
Page 20: Taking Out The Meat Basket (Accessory)
TDR-P 4.5.3 Taking out the meat basket (accessory). When taking out the meat basket from the TDR it is best to act as follows: Slightly lift both ends of the meat basket. Move the basket towards either the left or right hand side of the unit. This action unlocks one end of the basket. -
Page 21: Operation
TDR-P OPERATION Buttons are lit when functional. Operation of the rotisserie Press Start. Display shows Fri-Jado logo. Display shows software version. Interface P Eco Version x.x.x Display shows latest cooking Drumstick program. Use the arrow buttons for program selection. Display shows selected program. - Page 22 TDR-P After loading, close the door. LOAD Note: press OK or open the door to stop the sound signal. START Note: Screen 8 and 9 alternate each 5 seconds. When loading: press the rotor button to turn the rotor. Press OK to confirm. Display show programmed 180°C 0:59 temperature and time (hour : min).
-
Page 23: Operation Options
TDR-P (Optional) press right arrow for one minute increase, press left arrow for one minute decrease. When activated program continues at step 13. Program ready, open door. UNLOAD Press the rotor button to rotate the rotor. Close the door (if required clean the unit). -
Page 24: To End A Running Program
TDR-P Pre-heat ready (unit returns a sound signal). Note: press OK or open the door Start Program? to stop the signal. Press the OK to start the program. Display shows the next step of the program. Select NO and press the OK to continue with pre-heating. -
Page 25: Check The Remaining Time In A Program
TDR-P 5.2.5 Check the remaining time in a program Use the arrow buttons to show the 1 Chicken remaining time pro step. 230°C P123 10:05 Time left at step 1 1 Chicken (first digit blinks). 230°C P123 0:01 1 Chicken Time left at step 2 (second digit blinks). -
Page 26: Eco Function
TDR-P Press the OK button to update the screen (automatically refreshed every 15 seconds). Press List button to go back. Display returns to the original 1 Chicken operating display. 180°C P123 10:20 5.2.7 Eco function Optional: only available when activated in the 1 Chicken manager and service menu. -
Page 27: Display Information
TDR-P 5.2.9 Display information Display shows the programmed 180°C 0:20 temperature and time. Press the list button. Display shows after 3 seconds 1 Chicken cooking step + temperature + time. 180°C P123 0:20 Note: the current cooking step is underlined. Use arrow button for next screen. -
Page 28: Manager Menu
TDR-P MANAGER MENU Manager menu items Programming Parameters Change pin Pre-Heat Clock Edit Preheat temperature Transfer Delete Holding Version Copy Holding temperature Cook correction* Reading recipes Eco function* Store recipes Language Big digits Sound preheat Sound step Sound done * Only visible when selected in the service menu. Programming the rotisserie Possible programming steps: ... - Page 29 TDR-P Enter the User PIN code. Pin 0 - - - Give User PIN code Note: the original PIN code is 1111. The operator can change the User PIN code. Use the arrow button to enter the PIN code. Press the arrow right button to change the Pin 1 - - - first digit.
- Page 30 TDR-P The first available number is shown. Choose new number Note: use the arrow right button to select the next available number. Press the OK button to confirm. Enter the recipe name. 10 A-------------- for others Use the arrow button to change the character.
- Page 31 TDR-P Press the OK button to confirm. Set the “step 1” temperature. 10 Step 1 Starting with the first digit. Temp 1 - - °C Use the arrow buttons to increase/decrease the value of the selected digit. Press the OK button to confirm. Set the second digit.
- Page 32 TDR-P Press the OK button to confirm. Set the second digit. 10 Step 1 Temp 215 °C Time 21 - Press the OK button to confirm. Set the last digit. 10 Step 1 Temp 215 °C Time 210 Press the OK button to confirm. The Step is now completed.
- Page 33 TDR-P When ready programming press the OK button to confirm. Save the finished programs. 10 TEST Note: if the program is not saved all Save 1… changes are lost! Press the OK button to confirm. The screen returns to the RECIPES RECIPES menu.
-
Page 34: Programming Parameters
TDR-P Programming parameters Press the list button. Pin * * * * Enter your user PIN code. Give User PIN code Press the OK button to confirm. Press the arrow buttons to select MANAGER MENU Parameters. Parameters 1... Press the OK button to confirm. Press the arrow buttons to select Change Language: Dutch or Previous. - Page 35 TDR-P Use the arrow buttons to select Change, Language: English Next or Previous. … Next 1… Press back to enter the manager menu. Press the OK button to confirm or select Save parameters? Discard to cancel. Save 1... Use the arrow buttons to select the other settings: Big Digits YES/NO:...
-
Page 36: Change Pin Code
TDR-P Change pin code Manager menu. MANAGER MENU Select Change Pin. … Change Pin 1… Press the OK button. Enter the new pin code. Pin 0 0 0 0 Press the OK button. Enter new code Clock Manager menu. MANAGER MENU Select Clock. -
Page 37: Usb
TDR-P Manager menu. MANAGER MENU … Programming 1... Use the arrow buttons to select the USB function. Screen shows the USB function. MANAGER MENU Place the USB stick into the USB- … slot. Press the OK button to confirm. Use the arrow buttons to select Read to exchange an existing Read program or STORE to save a... -
Page 38: Cleaning And Maintenance
TDR-P CLEANING AND MAINTENANCE WARNING Appliance must be disconnected from the power supply during cleaning or maintenance and when replacing parts. Do not use aggressive or abrasive materials. These will damage the surface which will make it more difficult to remove dirt. Clean the inside, the removable parts and the accessories thoroughly with cleanser and water before putting the unit into use. -
Page 39: Weekly Cleaning
TDR-P Rotor and bottom plates Remove the rotor and bottom plates from the unit (no tools required). Place the detachable parts in a wide rinsing container filled with hot water and an appropriate cleaning agent. Soak these parts for one night and clean them the next day. Fat collecting drawer ... -
Page 40: Monthly Cleaning
TDR-P Monthly Cleaning WARNING Remove the power plug from the wall socket. Clean the fan plate and the fan blade thoroughly as described below. Fan plate: Remove the fan plate by loosening two winged nuts. This plate hinges at two points at the sides. -
Page 41: Cleaning Guidelines For Non-Stick Coated Surfaces
TDR-P Cleaning guidelines for non-stick coated surfaces Several parts of your rotisserie may have a non-stick coating surface. Abrasion and caustic chemicals reduce the life of the coating. With proper care, the non-stick coating surface should provide a long life of easy-to-clean service. DO NOT do the following: Do not use scouring pads, steel wool, Scotch-Brite pads, plastic wash pads, or other abrasive cleaning aids (abrasive pads remove the coating over time significantly reducing the life of the... -
Page 42: Malfunctions And Service
TDR-P MALFUNCTIONS AND SERVICE Before you contact your supplier/dealer in case of a malfunction, there are some items you can check yourself: Is the power supply working properly? Check fuses and differential switch. Has the timer clock been properly set? Item Malfunction Possible action... -
Page 43: Replace A Lamp
TDR-P Replace a lamp WARNING Remove the power plug from the wall socket. WARNING Do not touch the lamps with bare hands. Use a clean cloth or paper tissues when replacing the lamp. Remove any moisture with alcohol or methyl spirits after the lamp has cooled down. -
Page 44: Technical Specifications
TDR-P TECHNICAL SPECIFICATIONS WARNING Consult the identification plate to get the proper specifications of the unit. The electrical data may vary from country to country. The technical specifications of the different models in the TDR-P are shown in the next tables. European Models Model TDR 5... - Page 45 TDR-P Empty page. 45 / 48...
- Page 46 TDR-P Empty page. 46 / 48...
- Page 47 TDR-P Empty page. 47 / 48...
- Page 48 TDR-P Fri-Jado B.V. Blauwhekken 2 4751 XD Oud Gastel The Netherlands Tel: +31 (0) 76 50 85 400 Fax: +31 (0) 76 50 85 444 www.frijado.com 48 / 48...
