Eiffel 28.35 Mobile Cabinet
Mobile Cabinet with 2 doors and 1 drawer
Armoire mobile avec 2 portes et 1 tiroir
Model # 252BMC6, 252BMC8, 252BMC83, 252BMC84, 252BMC85
20
lb
15
lb
15
lb
26
lb
The indicated values consider static weights and evenly distributed over the parts.
Les valeurs indiquées tiennent compte des poids statiques et uniformément répartis sur les pièces.
Ed. 001, 2022/06 - Manhattan Comfort.
