- Page 1 ASSEMBLY INSTRUCTIONS COD BR: BE 839-06 COD US: 22AMC6...
-
Page 3: Table Of Contents
Summary Introduction Before starting Avoid accidents Dimensions and tools Indentifying parts Hardware included in box Furniture assembly Read this manual and follow the steps in order to keep the guarantee and also for the perfect fit. V : 11/19... -
Page 4: Before Starting
Before starting Prepare the room before starting the assembly, leaving it completely clean and the area in good condition to start the work. Use the cardboard of the packaging to Cover the assembly area with a blanket separate and support the parts removed or carpet to avoid damaging the parts from the boxes. -
Page 5: Dimensions And Tools
Dimensions and tools Dimensions: W: 18.7 H: 70.87 D: 11.57 inches W: 475 H:1805 D: 294 mm Cleaning You can clean the product with slightly damped cloth followed by a drycloth. Do not use chemicals or abrasives. All the furniture parts have been marked with a number. Before you start assembling, please identify the numbered parts in relation to the assembly instructions. -
Page 6: Indentifying Parts
COD US: 22AMC6 PART DESCRIPTION LEFT SIDE TOP/BASE/SHELF LOWER SHELF SHELF INTERMEDIARY PARTITION LOWER PARTITION BASEBOARD LONGER PARTITION RIGHT SIDE LOWER BACK LONGER BACK... -
Page 7: Hardware Included In Box 01
HARDWARE INCLUDED IN BOX 01 Glue ROUND FEET x 4 EF 000008x 1 EF 000106 x 8 EF 000033 x 44 EF 000168 X 28 EF 000132 x 28 EF 000061 X 2 CHALK x 01 STICKER x 30... -
Page 8: Furniture Assembly
= 2KG - 4.41LB = 3KG - 6.61LB = 5KG - 11LB = 8KG - 17.6LB STEP 1 Use the glue (EF 000008) before connecting hardware EF 000033 into pieces 03, 04, 05, 06 and 08 EF 000033... - Page 9 STEP 2 Use the glue (EF 000008) before connecting hardware EF 000033 into pieces 02. EF 000033 STEP 3 Use the glue before connecting pieces 02 and 06. Attach piece 07 using hardwares EF 000061 and EF 000106. (2x) EF 000061 EF 000008 EF 000106 STEP 4...
- Page 10 STEP 5 Use the glue before connecting pieces 02 and 05. EF 000008 STEP 6 Use the glue to fix piece 03 at the part assembled in the previous step. EF 000008 STEP 7 Connect pieces 01 and 09 to the parts assembled in steps 03, 04 and 06 using hardware EF 000132.
- Page 11 STEP 8 Fix the round feet and pieces 10 and 11 to the part assembled furniture using hardware EF 000168. round feet EF 000168 STEP 9 Use stickers to cover apparent screws. Sticker STEP 10 Use the chalk to give the final finish on the product. Chalk...
