User Manual
ARS-P3800 Series
Compact Display Computer for
railway applications

Advertisement

Table of Contents
loading

Related Manuals for Advantech ARS-P3800 Series

Summary of Contents for Advantech ARS-P3800 Series

  • Page 1 User Manual ARS-P3800 Series Compact Display Computer for railway applications...
  • Page 2 Copyright The documentation and the software included with this product are copyrighted 2010 by Advantech Co., Ltd. Reserves the right to make improvements in the products described in this manual at any time without notices. Acknowledgements AMI is trademark of American Megatrends Inc.

  • Page 3: Product Warranty (2 Years)

    Product Warranty (2 years) Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse accident or improper installation.

  • Page 4: Technical Support And Assistance

    2. Contact your distributor, sales representative, or Advantech’s customer service center for technical support if you need additional assistance. Please have the following information ready before you call: ...

  • Page 5: Packing List

    Connection for DC Power Source: Attention: Only trained service personnel are authorized to install and remove the 110 volt DC power supply, and make the connections to and disconnections from the 110 volt DC power source. The customer is responsible for ensuring that only trained service personnel install or remove the 110 volt power cable.

  • Page 6: Ordering Information

    Ordering Information Model number Description ARS-P3800-40A1E 38" PIS, AMD GX-217GA, 4G , 64GB mSATA Safety Instructions 1. Please read these safety instructions carefully. 2. Please keep this User’s Manual for later reference. 3. Please disconnector this equipment from AC outlet before cleaning. Use a damp cloth.
  • Page 7 18. RESTRICTED ACCESS AREA: The equipment should only be installed in a Restricted Access Area. 19. DISCALIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of and statements contained herein. ARS-P3800 User Manual...

  • Page 8: General Information

    Chapter General Information This chapter gives background information on the ARS-P3800 Passenger Information System. Sections include:  Introduction  General Specifications  Dimensions...

  • Page 9: Production Features

    Introduction The ARS-P3800 is a dedicated panel computer for rolling stock passenger information system. Locomotive Control system will go according to different requirements from which ARS-P3800 show a different station name and message. TheARS-P3800 has some of IO ports, such as LAN, USB, etc., which it can work in a wide temperature range (-25 °...

  • Page 10: System Block Diagram

    1.3.1 System Block Diagram Figure 1.1 ARS-P3800 System Block Diagram Mechanical Specifications 1.4.1Dimensions 1048.6[41.28] x 279.2[10.99] x 54[2.12] (Unit:mm [Inch]) ARS-P3800 User Manual...

  • Page 11: Power Requirement

    Figure 1.2 ARS-P3800 Mechanical dimension drawing 1.4.2Weight 9 kg (19.84lb)  Power Requirement 1.5.1 System Power ARS-P3800 User Manual...

  • Page 12: Environment Specification

    Power Input: 110Vdc@ 0.9A  1.5.2 RTC Battery Lithium 3V/210mAh  Environment Specification 1.6.1 Operation Temperature With Industrial Grade SSD/Cfast: -25 ~ 55 ℃(-13 ~131℉), with air flow.  Speed=0.7 m/sec 1.6.2 Relative Humidity 95%@ 40℃(non-condensing)  1.6.3 Storage Temperature -40 ~ 85℃...

  • Page 13: Hardware Information

    Chapter Hardware Information This chapter introduces external I/O and the installation of the ARS-P3800 Hardware.
  • Page 14 ARS-P3800-40A1E I/O Connectors Figure 2.1 ARS-P3800 front sides Figure 2.2 ARS-P3800 rear sides ARS-P3800 User Manual...

  • Page 15: Power Input Connector

    ARS-P3800 external I/O connectors Figure 2.3 ARS-P3800 Series IO Connector Side Drawing Figure 2.4 ARS-P3800 Series IO Connector _Bottom Right Drawing 2.2.1 Power Input Connector ARS-P3800 comes with a M12 A-coded connector that carries VDC external power input. Figure 2.5 Power Input Connector Table 2.24 Power Input Connector...
  • Page 16 2.2.2 USB M12 Connector Figure 2.6 M12 USB connector Table 2.22 USB connector of M12 A-Coded Signal Signal Data - Data + 2.2.3 M12 A-Coded LAN Connector Figure 2.7 M12 A-coded connector Table 2.21 LAN connector of M12 A-Coded Signal Signal MDI2+ MDI3+...

  • Page 17: Usb Connector

    2.2.4 USB Connector Figure 2.8 USB Connector Table 2.3: USB connector pin assignments Signal Signal USB data- USB data+ ARS-P3800 User Manual...
  • Page 18 Chapter BIOS Settings...

  • Page 19: Bios Setup

    BIOS Setup AMIBIOS has been integrated into numerous motherboards over the last decade. With the AMIBIOS Setup program, users can modify the BIOS settings and control various system features. This chapter describes the basic navigation of the ARS- P3800 BIOS Setup Utility menu. AMI's BIOS ROM has a built-in setup program that allows users to modify the basic system configuration.

  • Page 20: Entering The Setup Menu

    Entering the Setup Menu Power on the computer and press <F2> or <Del> to enter the setup menu. 3.2.1 Main Setup Menu When first entering the BIOS Setup Utility, users are directed to the Main setup page. Users can return to the Main setup page at any time by selecting the Main tab. The Main setup menu features two options, which are explained in this section.

  • Page 21: Advanced Bios Features

    3.2.2 Advanced BIOS Features Select the Advanced tab of the BIOS Setup Utility menu to access the Advanced BIOS setup page. Users can select any item, such as CPU Configuration, in the left frame of the screen to access the submenu for that item. Users can view the Advanced BIOS setup options by highlighting various items using the <Arrow>...
  • Page 22 3.2.2.1 PCI Subsystem Settings Configuration  PCI Latency Timer This item allows users to select the 32 / 64 / 96 / 128 / 160 / 192 / 224 / 248 PCI bus clocks.  VGA Palette Snoop This item allows users to enable or disable snooping of VGA palette registers. ...
  • Page 23 3.2.2.2 ACPI Settings Configuration  Enable ACPI Auto Configuration This item allows users to enable or disable BIOS ACPI auto configuration.  Enable Hibernation This item allows users to enable or disable the hibernation function (if supported by the OS). ...
  • Page 24 3.2.2.3 Trusted Computing  TPM Support This item allows users to enable or disable TPM support for security. ARS-P3800 User Manual...
  • Page 25 3.2.2.4 S5 RTC Wake Settings  Wake System with Fixed Time This item allows users to enable or disable system wake on alarm event.  Wake System with Dynamic Time This item allows users to enable or disable system wake on alarm event, and to set a delay interval of between 1 to 5 minutes.
  • Page 26 3.2.2.5 CPU Configuration  PPS Support This item allows users to enable or disable ACPI _PPC, _PSS, and _PCT objects.  PSTATE Adjustment This item allows users to specify the P-state level.  PPC Adjustment This item allows users to specify the _PPC object. ...
  • Page 27 3.2.2.6 IDE Configuration  IDE Configuration This item allows users to view SATA Port 0 / Port 1 information. ARS-P3800 User Manual...
  • Page 28 3.2.2.7 USB Configuration  Legacy USB Support This item allows users to enable support for legacy USB. The auto option dis- ables legacy support if no USB devices are connected.  USB3.0 Support This item allows users to enable or disable USB3.0 (XHCI) function. ...
  • Page 29 3.2.2.8 SMART Settings  SMART Self Test This item allows users to enable or disable the SMART self-test function. ARS-P3800 User Manual...
  • Page 30 3.2.2.9 Super I/O Configuration  Serial Port 1 / Port 2 Configuration This item allows users to select serial Ports 1 or 2 and view their detailed func- tions.  Watch Dog Function Configuration This item allows users to enable or disable the watchdog timer function. ...
  • Page 31 3.2.2.10 H/W Monitor  PC Health Status This page displays the system temperature and voltage information. ARS-P3800 User Manual...

  • Page 32: Chipset Configuration

    3.2.3 Chipset Configuration  GFX Configuration This item allows users to view the options for GFX items.  South Bridge This item allows users to view the options for South Bridge items.  North Bridge This item allows users to view the options for North Bridge items. ...
  • Page 33 3.2.3.1 GFX Configuration  Primary Video Device This item allows users to specify the primary video device for first output.  Integrated Graphics This item allows users to enable or disable the integrated graphics controller.  PSPP Policy This item allows users to specify the PCIe speed power policy. ARS-P3800 User Manual...
  • Page 34 3.2.3.2 South Bridge Configuration  SB SATA Configuration This item allows users to configure the SB SATA options.  SB USB Configuration This item allows users to configure the SB USB options.  SB HD Azalia Configuration This item allows users to configure the SB HD Azalia options. ...
  • Page 35 3.2.3.3 North Bridge Configuration  Memory Configuration This item allows users to specify the memory frequency.  2nd LVDS Backlight Control This item allows users to select the LVDS backlight mode. ARS-P3800 User Manual...
  • Page 36 3.2.3.4 DPx Output mode  DP0 Output Mode This item allows users to select the DP0 DVI panel function.  DP1 Output Mode This item allows users to select theDP1 HDMI function. ARS-P3800 User Manual...

  • Page 37: Boot Configuration

    3.2.4 Boot Configuration  Setup Prompt Time-out This item allows users to set the setup activation key wait duration (in seconds).  Bootup NumLock State This item allows users to select the power-on state for Numlock.  Quiet Boot When this option is set to “Disabled”, the BIOS system displays standard POST messages.

  • Page 38: Security Configuration

    3.2.5 Security Configuration Select the Security tab from the main BIOS Setup Utility menu. All security setup options, such as password and virus protection, can be accessed from this menu. To access the submenu of any item, select the item and press <Enter>.

  • Page 39: Save And Exit

    3.2.6 Save and Exit  Save Changes and Exit This item allows users to save changes and exit the setup menu.  Discard Changes and Exit This item allows users to exit the setup menu without saving changes.  Save Changes and Reset This item allows users to save changes and reset the system.
  • Page 40 Appendix Exploded Diagram & Setting Diagram...

  • Page 41: Exploded Diagram

    Exploded Diagram Figure A.1 Exploded Diagrams ARS-P3800 User Manual...

  • Page 42: Setting Diagram

    Setting Diagram Figure A.2 Setting Diagrams ARS-P3800 User Manual...

This manual is also suitable for:

Ars-p3800-40a1e
