Multitech OneBox Smart Building Quick Start

Additional Documentation
For additional MTCAP documentation, go to:
•
https://www.multitech.com/brands/multiconnect-conduit-ap and select the specific model.
For additional sensor documentation, go to:
•
https://www.multitech.com/products/sensors and select the specific sensor.
OneBox Smart Building Quick Start
Part Number: 82131201L
Copyright © 2023 by Multi-Tech Systems, Inc.
MultiTech, the MultiTech logo, and Conduit are registered trademarks
and Reveal and OneBox are trademarks of Multi-Tech Systems, Inc.
®
The LoRa Mark is a registered trademark of Semtech Corporation.
The Apple logo and App Store are registered trademarks of Apple Inc.
Google Play and the Google Play logo are trademarks of Google LLC.
All other products and technologies are the trademarks or
registered trademarks of their respective holders.
Multi-Tech Systems, Inc.
2205 Woodale Drive
Mounds View, Minnesota 55112
Phone: 763-785-3500 or 800-328-9717
Support
Portal: support.multitech.com Knowledge Base: multitech.com/kb.go
support@multitech.com (800) 972-2439 or (763) 717-5863
OneBox Smart Building Kit
MultiTech OneBox™ kit includes a tailored set of LoRa
®
LoRaWAN that brings data from sensors to the cloud, regardless of the application. OneBox provides
automatic monitoring and configuration as well as notifications for immediate access to critical information.
Package Contents
SIM Activation
The MTCAP has a pre-installed KORE SIM card for 90 days of free cellular connectivity.
Refer to the KORE document included in the box for SIM activation instructions.
For SIM activation, you need the MTCAP IMEI number and SIM number from the
MTCAP label.
When you submit the form, KORE sends an email to confirm that your SIM is activated.
Preparing the MTCAP Gateway
After receiving the SIM activation confirmation, prepare the MTCAP gateway:
1. Finger-tighten the antenna to the antenna connector on the MTCAP.
2. Attach the power blade to the power supply.
3. Connect the power supply to the MTCAP power jack and plug it into an electrical
outlet. When the MTCAP is ready to use, the STATUS LED blinks.
The MTCAP is pre-configured for the OneBox; you do not need to configure
device settings.
For your records, the MTCAP login information:
®
enabled sensors and an easy-to-deploy Conduit
1. Conduit AP (MTCAP) gateway
2. Ethernet cable
3. Antenna
4. Power supply
5. Conduit AP mounting bracket
6. Wireless Air Temperature & Humidity Sensor
7. Wireless Water Leak Sensor
8. Single Push Button Sensor
9. Wireless Acceleration-based Movement Sensor
10. Wireless Door & Window Sensor
Not pictured: Adhesive strips, magnets, and tamper resistant screws
for sensors and documentation.
IMEI
SIM
Username: admin
Password: Admin[serial number]
®
AP gateway for
