NEO COMPACT 10
PC WING
This document provides basic setup instructions and safety
warnings for the following product(s):
54104-101
NEO Compact 10 PC Wing
ABOUT THIS GUIDE
The document provides experienced users with the necessary information to get up and running very quickly.
Refer to the online user manual for complete information regarding all console operations. The manual can be
downloaded at www.strandlighting.com. Go directly to the NEO Compact 10 PC Wing product page and down-
load the product manual or other product information.
ABOUT THE NEO COMPACT 10 PC WING
The STRAND NEO Compact 10 PC Wing is a 10 fader USB wing designed to work with a PC running Strand
NEO PC software. With quality-built hardware and a small footprint, the NEO Compact 10 PC Wing can be used
anywhere. Thanks to the power of NEO PC, users get the full power of NEO from their own computer, with the
ability to connect to devices over a DMX Ethernet lighting network or with the DMX connectors on the PC Wing.
Because the Compact 10 PC Wing off ers a true 0-10 button numeric keypad, programming can be performed
quickly and easily. Thanks to the internal touchscreen, users can quickly select palettes and groups, while using
NEO PC to select fi xtures, access eff ects, and manipulate the cue list.
NOTE: Monitors, cables and other accessories are not included and are sold separately. For available accesso-
ries, please contact you local Authorized Strand Lighting Dealer. A list of Authorized Dealers is located on the
Strand Lighting web site at www.strandlighting.com.
Refer to the product datasheet for a complete list of accessories and technical specifi cations.
OVERVIEW
CONSOLE LAYOUT
shows the features and controls of the NEO Compact 10 PC Wing. Refer to the documentation sup-
FIGURE 1
plied on the console USB Key or on-line manual for additional information and operation.
©2020 Signify Holding. All rights reserved.
INCLUDED ITEMS
•
Power supply, 12 V DC, 5 A, 5' (1.5 m) lead
•
Power input cable, EU, IEC C13, CEE 7/4, 6 ft. (1.83 m)
•
Power input cable, US, IEC C13, NEMA 5-15P, 6 ft. (1.83 m)
•
Power input cable, UK, IEC C13, BS-1363-1, 6 ft. (1.83 m)
•
USB 3.0 cable, Type A, Type B, 6.6 ft. (2 m)
•
Dust cover
W W W. S T R A N D L I G H T I N G . C O M
1
QUICK START GUIDE
