AURORA 4 LED STRIP
This document provides basic setup instructions and safety
warnings for the following product(s):
64508-001
Aurora 4 LED Strip
Read all instructions before installing or using this product.
Retain this manual for future reference. Additional product
information and descriptions may be found on the product
specification sheet.
INSTALLATION AND SETUP
MOUNTING
The unit should be mounted via its screw holes on the bracket. Always ensure that the unit
is firmly fixed to avoid vibration and slipping while operating. Al- ways ensure that the struc-
ture to which you are attaching the unit is secure and is able to support a weight of 10 times
of the unit's weight. Always use a safety cable that can hold up to 12 times the weight of the
unit when installing the fixture.
The luminaire must be mounted by professionals.
SET UP
CONTROL PANEL
64508-001
INCLUDED ITEMS
Aurora 4 LED Strip
W W W. S T R A N D L I G H T I N G . C O M
1
QUICK START GUIDE
POWER CONNECTOR
QUICK START GUIDE
(this document)
WARRANTY CARD
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Strand Aurora 4 LED Strip
Summary of Contents for Strand Aurora 4 LED Strip
- Page 1 QUICK START GUIDE AURORA 4 LED STRIP INCLUDED ITEMS This document provides basic setup instructions and safety warnings for the following product(s): 64508-001 Aurora 4 LED Strip POWER CONNECTOR Read all instructions before installing or using this product. Retain this manual for future reference. Additional product...
- Page 2 AURORA 4 LED STRIP QUICK START GUIDE QUICK REFERENCE DMX MAPS SSCC MODE 1 ZONE (DEFAULT) SSCC MODE 4 CELL PARAMETER PARAMETER PARAMETER CHANNEL CHANNEL CHANNEL Intensity (High) Intensity (High) Magenta (Low) 2 Intensity (Low) Intensity (Low) CTO 2 Strobe...
- Page 3 AURORA 4 LED STRIP QUICK START GUIDE SOCC MODE 4 CELL SOCC MODE 4 CELL SOCC MODE 4 CELL CHANNEL CHANNEL Intensity (High) Cyan (High) 2 Intensity (Low) Cyan (Low) 2 Strobe Red (High) 3 Color Preset Red (Low) 3...
- Page 4 COMPLIANCE SAFETY WARNINGS AND NOTICES This equipment has been tested and found to comply with the limits for a Class A When using electrical equipment, basic safety precautions should always be followed digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide including the following: reasonable protection against harmful interference when this equipment is operated READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
