Summary of Contents for Nortel 15000

  • Page 1 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120...
  • Page 2 Document date: February 2005 Product release: sPCR6.1 Job function: Product Fundamentals Type: NTP Language type: U.S. English Copyright © 2005 Nortel Networks. All Rights Reserved. NORTEL, NORTEL NETWORKS, the globemark design, and the NORTEL NETWORKS corporate logo are trademarks of Nortel Networks.
  • Page 3: Table Of Contents

    Multiservice Switch 15000 overview 15 Multiservice Switch 15000 VSS overview 17 Multiservice Switch 20000 overview 19 Architecture of a Multiservice Switch 15000 or Multiservice Switch 20000 21 Mounting apparatus overview 22 Breaker interface panel overview 23 Shelf assembly overview 23...
  • Page 4 Fabric card location and physical description 76 Fabric card carrier 79 Fabric card transportation 81 Fabric replacement can affect traffic 83 Fabric replacement can affect system cooling 84 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 5 Connecting nodes through Multiservice Switch 15000 VSS 116 Connecting Multiservice Switch 15000 or Multiservice Switch 20000 node to a SER 5500 116 Connecting a Multiservice Switch 15000 or Multiservice Switch 20000 node to an EdgeLink 100 117 Blank processor card 119...
  • Page 6 SFP modules for an NTHW46 181 Optical interface characteristics for a 4-port MR POS and ATM FP 181 4-port OC-3/STM-1 ATM FPs 184 4-port OC-3/STM-1 ATM FP cable assembly 185 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 7 Voice services processor 2 (VSP2) FP 227 Voice services processor 3 (VSP3) FP 228 VSP3 line connections 228 VSP3 cable assemblies 229 VSP3 sparing 230 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 8 MT-RJ fiber cables and connectors 280 Preparing coax distribution cables 281 Preparing control port cables 283 Handling alarm cables 284 Prefabricated DS3 or E3 cable assemblies 284 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 9 Status LEDs of a PIM 293 Status LEDs of a fabric 295 Status LEDs of fabric cards in a Multiservice Switch 15000 295 Status LEDs of fabric cards in a Multiservice Switch 20000 296 Status LEDs of a CP or an FP card 299...
  • Page 10: About This Document

    About this document The information in this document describes the hardware parts and subassemblies for housing a Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000 in a Network Equipment Building System (NEBS) frame or equivalent mounting apparatus. The frame has product engineering code (PEC) NTRU04.
  • Page 11: What's New In This Document

    Other changes made to this document include the following: • rebranded the terms Passport and PVG in conjunction with the new Nortel Networks’ brand simplified naming format. Passport is now referred to as the Nortel Networks Multiservice Switch, and PVG is now Media Gateway 7480/15000.
  • Page 12: 4-Port Mr Pos And Atm Fp With Pec Nthw46

    (page 265) • increased the number of air filters to 10 in the tables Spare parts kit NTQS29AB for a Multiservice Switch 15000 (page 314) Spare parts kit NTQH29AB for a Multiservice Switch 20000 (page 315) • removed all mention of the 1-port OC-48/STM-16 POS FP with PEC...
  • Page 13: Fabric Card Nthr16Ea

    Fabric card NTHR16EA The following have been updated for this feature: • the table Features of a 40 Gbit/s Multiservice Switch 15000 fabric card pre-NTHR16EA (page 76) • the table Features of a 40 Gbit/s Multiservice Switch 15000 fabric card NTHR16EA (page 77) •...
  • Page 14: How To Get More Help

    Power System Detailed Installation Guidelines and Procedures Manual How to get more help For information on training, problem reporting, and technical support, see the “Nortel Networks support services” section in the product overview document. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard...
  • Page 15: Introducing Multiservice Switch 15000 And Multiservice Switch 20000 Hardware

    Hardware parts that can be replaced or upgraded (page 25) Multiservice Switch 15000 overview A Nortel Networks Multiservice Switch 15000 is a high-capacity ATM node, which can act as a backbone or edge node to an ATM network. Each Multiservice Switch 15000 supports electrical and optical interfaces with a variety of speeds from E3 up to STM-16 and from DS3 up to OC-48.
  • Page 16 - 16 - Introducing Multiservice Switch 15000 and Multiservice Switch 20000 hardware Multiservice Switch 15000 nodes support two types of timing source: building integrated timing supply (BITS) to the alarm/BITS module, and line timing to a fiber optic functional processor (FP). The node can receive the external timing signal from BITS or line timing, and distribute either signal throughout the switch.
  • Page 17: Multiservice Switch 15000 Vss Overview

    - 17 - Introducing Multiservice Switch 15000 and Multiservice Switch 20000 hardware Two Multiservice Switch 15000 or Multiservice Switch 20000 nodes in a NEBS 2000 frame ultiservice NEBS2000 Switch 15000 frame or 20000 ultiservice Switch 15000 or 20000 SS 3159 001 AA...
  • Page 18 Switch 15000 VSS is a Multiservice Switch 7400 packaged within a Multiservice Switch 15000. In addition to ATM, a Multiservice Switch 15000 VSS delivers a wide range of standard-based high-speed interfaces and services, including frame relay, circuit emulation, voice, and IP. These interfaces provide a wide variety of access and trunking speeds from channelized DS0 to OC-48.
  • Page 19: Multiservice Switch 20000 Overview

    - 19 - Introducing Multiservice Switch 15000 and Multiservice Switch 20000 hardware A Multiservice Switch 15000 VSS node in a NEBS 2000 frame PPT 2912 001 AA Multiservice Switch 20000 overview A Nortel Networks Multiservice Switch 20000 is a member of the Multiservice Switch family of nodes.
  • Page 20 Multiservice Switch 15000 cannot be upgraded to a Multiservice Switch 20000 by changing plug-in cards or modules. Processor cards from a Multiservice Switch 15000 or Multiservice Switch 20000 can be shared, but the Multiservice Switch 20000 is a unique shelf with its own software identity.
  • Page 21: Architecture Of A Multiservice Switch 15000 Or Multiservice Switch 20000

    For a detailed description of Multiservice Switch 20000 cards or modules, see the appropriate section in this document. For the procedures to initially install and maintain a Multiservice Switch 15000 or Multiservice Switch 20000, see NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade.
  • Page 22: Mounting Apparatus Overview

    PPT 3161 002 AA Mounting apparatus overview The mounting apparatus to house the switch hardware of a Nortel Networks Multiservice Switch is the NEBS 2000 frame with PEC NTRU04. The frame complies to the network equipment building system (NEBS). The frame accommodates: •...
  • Page 23: Breaker Interface Panel Overview

    - 23 - Introducing Multiservice Switch 15000 and Multiservice Switch 20000 hardware A single Multiservice Switch 15000 or Multiservice Switch 20000 can also be installed in a mounting apparatus other than a NEBS 2000 frame. Continue at Switch hardware mounting apparatuses (page 26).
  • Page 24: Upgrading Processor Cards

    Peripheral interworking equipment Peripheral equipment is any non-Nortel Networks Multiservice Switch equipment that can be connected to a Multiservice Switch 15000 or Multiservice Switch 20000 to provide additional functionality, service, Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard...
  • Page 25: Equipment Status Of A Multiservice Switch 15000 Or Multiservice Switch 20000

    Maintenance, and Upgrade. Hardware parts that can be replaced or upgraded Most of the hardware units of a Nortel Networks Multiservice Switch 15000 and Multiservice Switch 20000 can be replaced in the event of failure or damage. All such field replaceable units (FRUs) and service replaceable units...
  • Page 26: Switch Hardware Mounting Apparatuses

    Switch hardware mounting apparatuses The switch hardware of a Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000 is mounted in the 21-inch wide NEBS 2000 frame (NTRU04). The frame has a footprint of 60 cm by 60 cm (23.62 in. by 23.62 in.) and a height of 212.5 cm (83.66 in.).
  • Page 27: Anchors For A Nebs 2000 Frame

    Switch hardware mounting apparatuses The plug-in processor cards and fabric cards are shipped installed in a Multiservice Switch 20000, and separately for a Multiservice Switch 15000 or Multiservice Switch 15000 VSS. Optional switch hardware and frame enclosure hardware is typically not installed on the frame and must be added either before or after a frame is anchored.
  • Page 28 M12 anchor, 12.3 mm ID, 17.3 mm OD Belleville washer P0891271 0.5” ID, 1.75” OD flat washer P0891273 0.6” ID (2 of 3) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 29 (81.35 Nm). The remaining anchor nut has a fixed plastic collar to indicate that the nut has not been re-tightened. Since the collar must be removed to unfasten or re-tighten the nut, it acts as an integrity seal, especially in Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 30 Depth at 65 mm (2.56 in.) Cone or 80 mm (3.15 in.) Lower threaded rod MSS 3574 001 AA Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 31: Cable Management On The Mounting Apparatus

    The procedures for marking the footprint and drilling anchor holes is in NN10600-125 Nortel Networks Multiservice Switch 15000/20000 Planning Site Requirements. The procedures for anchoring the frame are included in the task flows of frame installation in NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade.
  • Page 32: Nebs 2000 Frame Enclosure

    The spacial requirements and considerations for installing a door kit or an extended side panel kit are in NN10600-125 Nortel Networks Multiservice Switch 15000/ 20000 Planning Site Requirements. The tasks to install the hardware are in NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade.
  • Page 33: Enclosing The Frame With Regular Side Panels And Frame Cover Panels

    These panels can be installed without the side panels being present, especially if the frame-joining hardware kit NTRU0370 is used to maximize space usage between adjacent frames. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 34 NN10600-125 Nortel Networks Multiservice Switch 15000/20000 Planning Site Requirements. The tasks to install the hardware are in NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade.
  • Page 35 - 35 - Switch hardware mounting apparatuses Installed side panels with front and rear frame cover panels PPT 2821 011 AB Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 36: Breaker Interface Panel

    BIMs to the shelves and cooling units. A Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000 node supports the use of either a two-BIM (single shelf) or a four-BIM (dual shelf) BIP. The BIP also contains an alarm module which monitors system parts, generates alarms, and controls LED status indicators.
  • Page 37 Top hole or dimple of front right frame upright Captive screw Space for air flow PPT 2820 021 AA Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 38: Front Cover Of The Bip

    BIP to the shelf assembly. BIMs are shipped already installed into the BIP. This section includes: • BIP with two or four BIMs (page 39) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 39: Bip With Two Or Four Bims

    BIM pairs in a BIP (page 43). If the NEBS 2000 frame is shipped with one Multiservice Switch 15000 or Multiservice Switch 20000, the insulation boots and lugs are provided for the second set of BIMs. This accommodates adding a second switch of the same kind to the frame.
  • Page 40: Bims Distributing Power To Pims

    BIP. Although the breakers of BIMs for a Multiservice Switch 20000 are greater than those of a Multiservice Switch 15000, the maximum power input feed is 100 A for both switches. When housing a Multiservice Switch 15000 and...
  • Page 41 A2.5- feeds B2.5 B2.5 B2.5 B2.5 B2.5 B2.5+ B2.4+ B2.5- Slot # B2.4- Rear-mounted fabrics PPT 2820 010 AA Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 42 A1.5- feeds B1.5 B1.5 B1.5 B1.5 B1.5 B1.5+ B1.4+ B1.5- Slot # B1.4- Rear-mounted fabrics PPT 2820 010 AB Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 43: Combined Bim Pairs In A Bip

    When two Multiservice Switch 15000s or two Multiservice Switch 20000s are installed in one NEBS 2000 frame, they share the same BIP. If a Multiservice Switch 15000 and a Multiservice Switch 20000 are installed in the same NEBS 2000 frame, they can safely share the BIP NT6C62 or AP6C68 even though the BIMs have different ampere ratings.
  • Page 44: Front Panel Of A Bim

    LED • five PCB circuit breakers (four 20 A and one 5 A) — for a Multiservice Switch 15000, four 20 A and one 5 A — for a Multiservice Switch 20000, four 25 A and one 5 A •...
  • Page 45: Bim Power Filters

    (BIM) slots. Filler plates are fastened to the front of the BIP, over the empty BIM slot, by a captive screw. Filler plates are used in two-BIM modules, when the BIP is installed in a frame that contains only one Nortel Networks Multiservice Switch.
  • Page 46: Location Of The Bip Alarm Module

    Frame level indicators for the BIP alarm module (page 47) Attention: When a Multiservice Switch 15000 shares the BIP with a Multiservice Switch 20000, that is, the two nodes are installed in the same frame, the LED test function operates only for the Multiservice Switch 20000.
  • Page 47 Alarm module of the BIP LED test button Status LEDs of the system Status LEDs of module Captive screw PPT 2822 005 AB Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 48: Hardware Alarm Definitions And Behaviors

    Attention: A fan alarm 7012 0051 will recur only when attribute repeatFanAlarm is enabled. See the procedure for configuring a fan alarm to recur in NN10600-550 Nortel Networks Multiservice Switch 7400/15000/ 20000 Common Configuration Procedures. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard...
  • Page 49 CPs so that an internal alarm clock makes the alarm recur each 8-hour interval and escalate the severity to critical if the problem is still not fixed within 24 hours. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 50: Bip Alarm Led Board

    • Aisle indicator (page 51) • Follow-me indicator (page 51) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 51: Alarm Cable Connectors

    The alarm cable connectors are located at the rear of the BIP backplane on the lower left side. See the figure Location of alarm cable connectors for two shelves (page 52). Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 52: Functions Of The Bip Alarm Connectors

    Features of the BIP alarm connectors The features are listed in the table Features of the BIP alarm connectors (page 53). Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 53 (frame or follow-me) for the module when the view of the indicators are blocked (for example, by cabinet doors); for driving a front and rear LED board Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 54: Bip Alarm Connections From A System Of Ac Rectifiers

    Nortel Networks Multiservice Switch, external alarms can be connected between the two setups. Selected alarm connections can indicate a hardware status of the Multiservice Switch 15000 or Multiservice Switch 20000, while other selected alarm connections on the switch can indicate a hardware status of the rectifier system.
  • Page 55: Power Connections To And From The Bip Backplane

    BIP accommodates • directly routing the cable from the site power source, or a branch panel as the last leg of connection, to the breaker interface panel (BIP) of the Nortel Networks Multiservice Switch • using a cable tapped off a main power cable (instead of directly from the site power source) as the last leg of cable to the BIP •...
  • Page 56: Function Of The Bip Backplane Power Input Connections

    BIP backplane power connections in a dual shelf frame (page 56) shows how the power connections on the backplane of the BIP are connected to other parts in the Multiservice Switch 15000 frame setup. BIP backplane power connections in a dual shelf frame...
  • Page 57: Hardware For Connecting Power Input Cables To The Bip

    Attention: When using power input cables that are thinner than 1/0 AWG, the same insulating boot is used and the gap is addressed by the procedure to connect each cable. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 58: Using An Optional Power-And-Ground Assembly

    See the figures: • The polyvalent power-and-ground assembly A0834143 (page 59) • The ETSI power-and-ground assembly A0834149 (page 60) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 59 Rear of BIP Strain-relief Cable Terminal Super-Flex Insulation fastening block power boot screw input cable PPT 2997 005 AD Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 60: Function Of The Bip Backplane Power Output Connections

    PIMs in the shelves • one 1x2 MATE-N-LOK II connector with louvertec contacts for cables providing power output to either the upper or lower cooling unit Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 61 P26 connection from BIM B2 to the PIM on upper shelf Insulating boot of power input cable PPT 2820 035 AD Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 62: Sources Of Dc Input Power To The Bip Backplane

    PPT 2822 001 AC2 Sources of dc input power to the BIP backplane The breaker interface panel (BIP) of a Nortel Networks Multiservice Switch 15000 receives and distributes dc power for the system. The source of dc power can be from either: •...
  • Page 63: Powering The Bip From Ac Rectifiers

    Breaker interface panel Most of the preparations and requirements for dc power cabling between the MFA150 rectifiers and the BIP of the Multiservice Switch 15000 have the same criteria as cabling from a site dc power plant. For information of this kind, see NN10600-125 Nortel Networks Multiservice Switch 15000/20000 Planning Site Requirements.
  • Page 64: Grounding The Switch And Interworking Equipment

    The NEBS 2000 frame is the grounding point for the switch hardware. The frame has a silvery grounding strip bonded to the front of each frame upright and across the top front. Mounting any Nortel Networks Multiservice Switch equipment onto the frame using the provided self-tapping bolts automatically grounds it to the frame.
  • Page 65 Multiservice Switch must share the same ground window even if the equipment is mounted in different mounting apparatuses. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 66: Shelf Assembly

    Shelf assembly Each node is a separate Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000. A switch is mostly comprised of the power distribution unit, the cooling unit, and a shelf assembly. A shelf assembly accommodates: • plug-in processor cards or filler cards in two rows (cages) across the front •...
  • Page 67 The exterior parts of the shelf assembly are shown in the figures • A typical shelf assembly, front view (page 68) • A shelf assembly of a Multiservice Switch 15000 without fabric cards, rear view (page 69) • A shelf assembly of a Multiservice Switch 20000 with one fabric card...
  • Page 68 Filler ESD jack Cable guides Cable management Cover latch channel, plate cover open SS 2820 036 AA Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 69 - 69 - Shelf assembly A shelf assembly of a Multiservice Switch 15000 without fabric cards, rear view Opening for PIM cable Backplane Cable management bracket address module For fabric Alarm/BITS module For fabric cover hinge pegs Kickplate PPT 2820 037 AB...
  • Page 70: Common Backplane

    • Function of the common backplane (page 71) The backplane can also be considered a midplane since cards can be inserted on both sides. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 71: Backplane Location And Physical Description

    The backplane is not a field-replaceable unit. The location of the backplane is shown in the figure: • A shelf assembly of a Multiservice Switch 15000 without fabric cards, rear view (page 69) •...
  • Page 72 Dual-fabric mode is the standard mode used by both types of node. Single-fabric mode occurs while one of the fabrics is being replaced or upgraded. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 73: Fabric Cards

    Each one operates at about half capacity so that it can take over the traffic of its mate. Either card can handle all traffic carried by a fully provisioned and configured Multiservice Switch 15000 or Multiservice Switch 20000.
  • Page 74 This means a 40G fabric card cannot be used in a Nortel Networks Multiservice Switch 20000 node, and a 70G cannot be used in a Multiservice Switch 15000 node. When the system first detects the type of fabric card, the system automatically: •...
  • Page 75: Fabric Led Behavior Is Different From Fps

    Switch proprietary cell c) AT cell Control cell SS 3161 001 AA For more information, see the chapter on fabric cards in NN10600-550 Nortel Networks Multiservice Switch 7400/15000/20000 Common Configuration Procedures. Fabric LED behavior is different from FPs Since a red LED can be caused by more than disabling, a fabric card with a red LED can still be transmitting traffic.
  • Page 76: Fabric Card Location And Physical Description

    (usable) capacity using that fabric is 40 Gbit/s. The 40G fabric card supports the 2.5 Gbit/s function processors (FPs). The tables Features of a 40 Gbit/s Multiservice Switch 15000 fabric card pre- NTHR16EA (page 76) Features of a 40 Gbit/s Multiservice Switch 15000 fabric card NTHR16EA (page 77) list the major features.
  • Page 77 - 77 - Shelf assembly Features of a 40 Gbit/s Multiservice Switch 15000 fabric card pre-NTHR16EA Feature Description technology CMOS5S6, 0.35 Um backplane signaling 1.5 V Class B compliance CP dependency CP2s or CP3s (2 of 2) Features of a 40 Gbit/s Multiservice Switch 15000 fabric card NTHR16EA...
  • Page 78 CPAC1 or CPAC2. Unilink connections will be used by the FPs that have the C192 ASICs. (The ASICs of each FP type are identified in NN10600-551 Nortel Networks Multiservice Switch 7400/15000/20000 FP Configuration Reference.) Card slots 6 and 7 or 14 and 15 can accommodate FPs that use either DASL or Unilink.
  • Page 79: Fabric Card Carrier

    Switch 15000 (page 80) Faceplates of both fabric cards installed in a lower Multiservice Switch 20000 (page 81), for the location of the fabric cards. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 80 - 80 - Shelf assembly Faceplates of both fabric cards installed in a lower Multiservice Switch 15000 Rear (lower) ESD jack cooling unit Fabric status Fabric cover LEDs Access panel Fabric lever to diagnostic connector (For Nortel Networks personnel) Insertion...
  • Page 81: Fabric Card Transportation

    The method of transporting fabric cards differs between Nortel Networks Multiservice Switch 15000 and Multiservice Switch 20000 nodes. Fabric cards for a Multiservice Switch 15000 are shipped in their own transportation container. The container and packaging protects the card from damage by minor impacts and electromagnetic discharges (ESD).
  • Page 82 A node from package NTQS03 or NTQS04 may not have the tape on it. Removing the protective tape is an essential step in the installation procedure. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 83: Fabric Replacement Can Affect Traffic

    PPT 3087 005 AA2 Fabric replacement can affect traffic When both fabric cards in either Nortel Networks Multiservice Switch node are in service, they operate in a load-sharing mode such that either card can take over all the traffic of its mate. When a fabric card fails completely, the failure triggers the remaining card to take over the incoming traffic from the failed card, and the failed card is put into a lock-out state.
  • Page 84: Fabric Replacement Can Affect System Cooling

    A reset loses all in-progress traffic. The CPs and FPs will not reboot until a fabric card is installed and returns to service. For a description of handling fabric card software sparing, takeover, and lockout, see to NN10600-550 Nortel Networks Multiservice Switch 7400/15000/20000 Common Configuration Procedures. Fabric replacement can affect system cooling An installed fabric card is an integral part of the cooling system and electromagnetic compatibility (EMC).
  • Page 85: Fabric Replacement May Require A Firmware Upgrade

    9.3, it automatically becomes active and controls the operation of the fabric card. For information on installing new firmware on the fabric card, see NN10600-272 Nortel Networks Multiservice Switch 7400/15000/20000 Upgrading Software.
  • Page 86: Fabric Replacement May Require A Software Patch

    When a fabric NTHR16 with version EA (NTHR16EA) is to be inserted into a Multiservice Switch 15000 as a replacement for a fabric that does not have the EA or later version, software on the switch should have either the fabric feature or a patch that enables the operation of the EA version.
  • Page 87: Power Interface Modules (Pims)

    PIM unless the power cable is removed first. This protects the backplane pins from arcing if the PIM is pulled with the power left on. The figure Faceplate of a PIM on a Multiservice Switch 15000 (page 89) shows the opening for the connection point.
  • Page 88 2/4 L -1 input negative battery feed 1/3 L -2 input negative battery feed 2/4 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 89: Power Led Status Indicators For Pims

    PPT 2820 038 AA Power LED status indicators for PIMs Each PIM in a Nortel Networks Multiservice Switch 20000 has LEDs to monitor the status of the A and B power feeds to the BIP. See the figure Location of the PIMs, MAC address, and alarm/BITS module in a Multiservice Switch 20000 (page 91).
  • Page 90: Pim Cable Assembly

    NEBS 2000 frame. The cable assembly of the second node is typically installed even if the frame is shipped with only one node. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 91 PIM at 15RU, Fabric A4 and A5 PIM status LEDS PIM at 15RL, B4 and B5 PPT 3087 009 AC Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 92: Media Access Control (Mac) Address Module

    (PIMs) of the upper and lower module cage. The location of the MAC address module is shown in the figure A shelf assembly of a Multiservice Switch 15000 without fabric cards, rear view (page 69). The MAC address module is a field-replaceable unit (FRU) which provides the shelf with MAC addresses for the CP and FP cards.
  • Page 93: Alarm/Bits Module

    • reporting of any cooling unit alarms to the control processors (CPs) • reporting of any CP alarms to the breaker interface panel (BIP) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 94: Types Of Alarm/Bits Modules

    The types of alarm/BITS module are matched to the CP cards for the type of interfacing signal as follows. The types of the alarm/BITS module for a Multiservice Switch 15000 include • NTHR12, for balanced DS1 twisted pair (matched to the DS1 CP NTHR06 or NTHW06) •...
  • Page 95: Alarm/Bits Module Faceplate

    The alarm/BITS module is located at the right side of the rear of the shelf assembly, between the upper and lower fabric modules (see the figure A shelf assembly of a Multiservice Switch 15000 without fabric cards, rear view (page 69)).
  • Page 96 - 96 - Shelf assembly Faceplate of an alarm/BITS module in a Multiservice Switch 15000 J4 for BITS cable J3 for BITS cable J2 for alarm cable to cooling unit J1 for alarm cable to BIP DO NOT REMOVE Captive...
  • Page 97 BITS circuits. Depending on the variant of the alarm/BITS module used, these ports support connection to • a DS1 balanced cable (twisted pair D-sub) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 98 Multiservice Switch 15000 (page 96). Pin assignments and the functional specifications for the transmit and receive circuits for the BITS connectors are listed in NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade under the section for connecting the timing wires.
  • Page 99 CPX slots The location of the BIP alarm connector is shown in the figure Faceplate of an alarm/BITS module in a Multiservice Switch 15000 (page 96). The pin assignments for the BIP alarm connector are shown in the table alarm connector pin-out (page 99).
  • Page 100: Alarm/Bits Module Cable Assemblies

    NTHR75 unbalanced E1 coax for J3 or J4 of the alarm/BITS module NTHR14 • NTHW76 wire-wrap DS1 for J3 or J4 of the alarm/BITS module NTHW76 for a Multiservice Switch 15000, or NTPN78 for a Multiservice Switch 20000 • NTPN81 unbalanced E1 for J3 or J4 of the alarm/BITS module NTPN13...
  • Page 101: Timing Cable Specifications For The Ds1 Circuit

    The optional balun cable assembly NTPN81 for a Multiservice Switch 20000 converts the balanced E1 alarm/BITS module into an unbalanced E1 module. Using custom or prefabricated timing cable assemblies for the building integrated timing supply (BITS) is described in NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade.
  • Page 102: Timing Cable Specifications For The E1 Unbalanced Circuit

    • two 37.4-ohm resistors for matching impedance • generally, a 1-to-1 step-up transformer is added to interface to the transceiver Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 103: Line Build Out Application Settings

    122 m (399 ft) to 163 m (533 ft) DSX-1 163 m (533 ft) to 200 m (655 ft) DSX-1 -7.5 db CSU -15 db CSU Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 104: Cooling Units

    - 104 - Shelf assembly Cooling units Each Nortel Networks Multiservice Switch has a cooling unit to maintain an ambient operating temperature inside its shelf assembly. Maintaining the temperature at optimum levels maintains the operation and performance of the hardware. Keeping the internal temperature within its normal operating range will improve the system’s service life.
  • Page 105 Input power alarm cable A controller carriage Finger guard Power and alarm connectors Fan shroud PPT 2822 013 AF Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 106: Environmental Control Equipment

    Cooling unit connections (page 112) Environmental control equipment Nortel Networks Multiservice Switch environmental control equipment consists of two cooling units located in the middle of the frame between the upper and lower shelf assemblies. The upper cooling unit pushes air from the fan under the modules in the upper shelf assembly and out through the exhaust plenum under the BIP.
  • Page 107 Multiservice Switch should always be operated with the cooling units on to avoid damage to the CP, FPs, and fabric cards, even when dusty air filters are removed. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 108 (rear) cooling unit Air flow into the frame to the shelf assembly Air filter cover PPT 2820 041 AA Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 109: The Impact Of Heat Dissipation On Rising Shelf Temperatures

    (This should already have been done to determine the size of power cable to your node. Otherwise refer to the power distribution and consumption tables in NN10600-125 Nortel Networks Multiservice Switch 15000/20000 Planning Site Requirements.) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard...
  • Page 110 7012 0059 is generated. • At 72 degrees Celsius (161.6 Fahrenheit) inside a fabric card, the card automatically shuts down to protect itself. When both fabric cards reach Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 111: Fans

    Air filters Each shelf assembly of a Multiservice Switch 15000 or Multiservice Switch 20000 has an air filter to prevent dust and other airborne contaminants from being drawn past the processor cards and modules by the cooling units.
  • Page 112: Temperature Sensors

    For the location of the internal connectors, see the figures: • Parts inside a lower cooling unit NTHR51AA (bottom shown upside down) (page 105) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 113 Lower (rear) cooling unit D-sub connector for alarm cable Power connector B, lower cooling unit Power connector A, lower cooling unit PPT 2820 051 AB Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 114: Control And Function Processors

    A typical shelf assembly, front view (page 68). For the list of capabilities of each FP, refer to the FP type in NN10600-551 Nortel Networks Multiservice Switch 7400/15000/20000 FP Configuration Reference. Navigation • Connecting a Multiservice Switch node to another node (page 115) •...
  • Page 115: Connecting A Multiservice Switch Node To Another Node

    Connecting two Multiservice Switch nodes In order for a Nortel Networks Multiservice Switch node to interwork directly with another Multiservice Switch node, establish the connection between two FPs, one at either end, through a fanout panel.
  • Page 116: Connecting Nodes Through Multiservice Switch 15000 Vss

    Switch 7480 if another route must be used. The software configuring of Multiservice Switch 7400 series nodes and Multiservice Switch 15000 nodes is not the same. Any tools you use to configure the network must be able to adapt both sets of configuration commands.
  • Page 117: Edgelink 100

    Interface cables between Multiservice Switch 15000 or Multiservice Switch 20000 nodes and an EdgeLink 100 (page 117). Two cables are required, one for transmitting and one for receiving. Interface cables between Multiservice Switch 15000 or Multiservice Switch 20000 nodes and an EdgeLink 100 Type and Part number...
  • Page 118 - 118 - Control and function processors Interface cables between Multiservice Switch 15000 or Multiservice Switch 20000 nodes and an EdgeLink 100 (continued) Type and Part number Length Type of connector at Type of connector at quantity EdgeLink other end...
  • Page 119: Blank Processor Card

    A shelf assembly is typically shipped with blank cards for installing in empty slots. For Nortel Networks Multiservice Switch 15000 or a shelf-based Multiservice Switch 20000 node, blank cards are shipped in a container. For...
  • Page 120 Faceplate of a blank processor card with PEC NTHR64 Dummy status LEDs Card latches Blank face PPT 2822 012 AB2 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 121: Control Processors

    Ethernet port for CP2 or a 100Base-T port for CP3 • is half of a redundant pair in Nortel Networks Multiservice Switch 15000 and Multiservice Switch 20000 nodes. In the event that the active CP fails, the standby CP takes over...
  • Page 122 Pin Numbering Link Scheme Ethernet port P0 Lower card latch Keyed RJ45 connector (rotated view) PPT 2822 007 AB3 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 123 V.24 CP pinout and signal names (page 129) • CP line rate (page 129) • CP compliance with standards (page 129) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 124: Cp Hardware

    • building integrated timing supply (BITS) from the alarm/BITS module (if connected to the site source) The CP hard disk drive stores the Nortel Networks Multiservice Switch node software, configuration data, and spooled information. CP software requirements See the following tables for minimum software requirements of Nortel...
  • Page 125: Cp Cables

    CP2 or CP3, and on the equipment at the other end. You must provide the cables and connectors to link a CP to Nortel Networks equipment, such as a local user interface terminal or a Multiservice Data Manager workstation communicating through a router or hub of a local area network (LAN), or to any other CPE termination.
  • Page 126 CP in a custom-made CP cable Multiservice NTBP25 (page 128) Switch 7400 node within a Multiservice Switch 15000 VSS Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 127 Label of Pin 15 part number Pin 8 Pin 15 Pin 8 To FP ethernet connector PPT 3419 002 AA Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 128: Ethernet Cp Pinout And Signal Names

    CP2 10BaseT Ethernet and the CP3 100BaseT Ethernet ports. Ethernet connector pinouts Pin numbers Signal name Tx + Tx - (1 of 2) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 129: V.24 Cp Pinout And Signal Names

    The CP’s line rate supports asynchronous data transfer at 9.6 kbit/s. CP compliance with standards The V.24 port supports a subset of CCITT V.24 standards and can accommodate most interface devices. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 130: Ethernet Compliance With Standards

    Ethernet compliance with standards The Ethernet FP complies with these standards and conventions: • IEEE 802.3 • Digital/Intel/Xerox (DIX) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 131: 2-Port Ds3Ch Tdm Fp

    • Assigning sparing panel connections for 2-port DS3C TDM FPs (page 134) The software name (card type) of the NTHW91 is 2pDS3cAal. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 132: 2-Port Ds3Ch Tdm Line Connections

    NTHW52. Refer to Termination panels for FPs (page 242) for the description, function, and capabilities of the panel. The connections can be made to equivalent non-Nortel Networks equipment provided the cabling criteria are met. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard...
  • Page 133: 2-Port Ds3Ch Tdm Cable Assemblies

    15 m (49 ft) When a prefabricated interface cable from Nortel Networks is connected between a DS3 FP and a Nortel Networks termination panel, the connection is grounded. You can custom make your own traffic port cables to connect the FP to the...
  • Page 134: Assigning Sparing Panel Connections For 2-Port Ds3C Tdm Fps

    CPE. A sparing panel has a transmit (Tx) and receive (Rx) pair for each port. When cabling Nortel Networks Multiservice Switch FPs and sparing panels, do Tx-to-Tx and Rx-to-Rx for all equipment from the FP up to the far-end termination of the FP connection.
  • Page 135 Monitor P1 LINE LINE LINE LINE P1 TX P1 RX P0 TX P0 RX Monitor P0 PPT 2175 001 AC2 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 136: 4-Port Ds3Ch Fr Fp

    NTHR88 NTHR89 4pDS3Ch When a specific PEC is not mentioned, assume the text applies to both PQC versions of the card. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 137: 4-Port Ds3 Fr Fp Line Connections

    Termination panels for FPs (page 242) for the description, function, and capabilities of the panels. The connections can also be made to equivalent non-Nortel Networks equipment provided the cabling criteria are met. 4-port DS3 FR FP cable assemblies The maximum cable distance for DS3 lines to customer premises equipment (CPE) is 137 m (450 ft).
  • Page 138 15 m (49 ft) When a prefabricated interface cable from Nortel Networks is connected between a DS3 FP and a Nortel Networks termination panel, the connection is grounded. You can custom make your own control port cable using the following specifications: •...
  • Page 139 DS3Ch FR FP (page 140). Information about assigning port connections is described in the processor card cabling chapter of NN10600-175 Nortel Networks Multiservice Switch 7400 Hardware Installation, Maintenance, and Upgrade. Labels of mini-coax and BNC cable connections on a 4-port NTHR58 cable assembly...
  • Page 140: Assigning Sparing Panel Connections For 4-Port Ds3 Fps

    Assigning sparing panel connections for 4-port DS3 FPs A sparing panel has a transmit (Tx) and receive (Rx) pair for each port. When cabling Nortel Networks Multiservice Switch FPs and sparing panels, do Tx-to-Tx and Rx-to-Rx for all equipment from the FP up to the far-end termination of the FP connection.
  • Page 141 The prefabricated cable assemblies that can be used with the DS3 FPs are identified in each FP description in this chapter. • All FPs must be in the same shelf, that is, share the same CPs. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 142 NTHR79 (page 141) is an example of connections. The control port cable connections are omitted to clearly indicate the traffic port connections. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 143 4-port DS3 Main FPs Control ports spare FP1 FP2 FP3 FP4 FP5 FP6 4-port DS3 Spare FP PPT 2819 017 AD Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 144: 4-Port Ds3Ch Atm Fp With Ima

    NTHR79. Refer to Termination panels for FPs (page 242) for the description, function, and capabilities of the panels. The connections can also be made to equivalent non-Nortel Networks equipment provided the cabling criteria are met. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard...
  • Page 145: 4-Port Ds3Ch Atm Fp With Ima Cable Assemblies

    15 m (49 ft) When a prefabricated interface cable from Nortel Networks is connected between a DS3 FP and a Nortel Networks termination panel, the connection is grounded. You can custom make your own control port cable using the following specifications: •...
  • Page 146 Mapping an 8W8 and BNC cable to a termination panel from a DS3Ch ATM FP (page 147). Information about assigning port connections is described in the processor card cabling chapter in NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade.
  • Page 147 <node_id>/<fp_slot_no>/P0/Tx4 Rx 3 <node_id>/<fp_slot_no>/P0/Rx3 Tx 3 <node_id>/<fp_slot_no>/P0/Tx3 Rx 2 <node_id>/<fp_slot_no>/P0/Rx2 Tx 2 <node_id>/<fp_slot_no>/P0/Tx2 Rx 1 <node_id>/<fp_slot_no>/P0/Rx1 Tx 1 <node_id>/<fp_slot_no>/P0/Tx1 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 148: 4-Port Ds3Ch Fp With Aal1 Ces

    NTHR79. Refer to Termination panels for FPs (page 242) for the description, function, and capabilities of the panels. The connections can also be made to equivalent non-Nortel Networks equipment provided the cabling criteria are met. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard...
  • Page 149: 4-Port Ds3Ch Fp With Aal1 Ces Cable Assemblies

    15 m (49 ft) When a prefabricated interface cable from Nortel Networks is connected between a DS3 FP and a Nortel Networks termination panel, the connection is grounded. You can custom make your own control port cable using the following specifications: •...
  • Page 150 DS3Ch FP (page 151). Information about assigning port connections is described in the processor card cabling chapter in NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade. Labels of mini-coax and BNC cable connections on a 4-port NTHR58 cable assembly...
  • Page 151 <node_id>/<fp_slot_no>/P0/Tx4 Rx 3 <node_id>/<fp_slot_no>/P0/Rx3 Tx 3 <node_id>/<fp_slot_no>/P0/Tx3 Rx 2 <node_id>/<fp_slot_no>/P0/Rx2 Tx 2 <node_id>/<fp_slot_no>/P0/Tx2 Rx 1 <node_id>/<fp_slot_no>/P0/Rx1 Tx 1 <node_id>/<fp_slot_no>/P0/Tx1 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 152: 12-Port Ds3 Fp

    Faceplate of a 12-port DS3 FP with PEC NTHR23 (page 152) The figure includes the mapping of port numbers to connector pins. Information on assigning port connections is described in NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade. •...
  • Page 153: 12-Port Ds3 Fp Line Connections

    The connections can also be made to equivalent non-Nortel Networks equipment provided the cabling criteria are met. When connecting a DS3 to a fanout panel, up to three DS3 8W8-to-BNC cable assemblies are required.
  • Page 154 15 m (49 ft) When a prefabricated interface cable from Nortel Networks is connected between a DS3 FP and a Nortel Networks termination panel, the connection is grounded. You can custom make your own control port cable using the following specifications: •...
  • Page 155 NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade. Attention: Unlike Multiservice Switch 7400 series FP faceplates, Multiservice Switch 15000 and Multiservice Switch 20000 FP faceplates have their ports numbered from bottom to top. The reversal is required to accommodate the downward cable management.
  • Page 156: Assigning Sparing Panel Connections For A 12-Port Ds3 Or E3 Fp

    FP connection. Choose the sparing panel connections before doing the cabling procedure. Record each port connection at the Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 157 A sparing panel has a transmit (Tx) and receive (Rx) pair for each port. When cabling Nortel Networks Multiservice Switch FPs and sparing panels, do Tx-to-Tx and Rx-to-Rx for all equipment from the FP up to the far-end termination of the FP connection.
  • Page 158 <node_id>/<fp_slot_no>/P2/Tx10/A-BNC5 Rx 9 BNC 4 <node_id>/<fp_slot_no>/P2/Rx9/A-BNC4 Tx 9 BNC 3 <node_id>/<fp_slot_no>/P2/Tx9/A-BNC3 Rx 8 BNC 2 <node_id>/<fp_slot_no>/P2/Rx8/A-BNC2 (1 of 2) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 159 <node_id>/<fp_slot_no>/P0/Rx1/A-BNC4 Tx 1 BNC 3 <node_id>/<fp_slot_no>/P0/Tx1/A-BNC3 Rx 0 BNC 2 <node_id>/<fp_slot_no>/P0/Rx0/A-BNC2 Tx 0 BNC 1 <node_id>/<fp_slot_no>/P0/Tx0/A-BNC1 (2 of 2) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 160: 32-Port E1 Tdm Fp

    32-port E1 TDM cable assemblies (page 162) • Assigning sparing panel connections for 32-port E1 TDM FPs (page 163) The software name (card type) of the NTHW92 is 32pE1Aal. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 161: 32-Port E1 Tdm Line Connections

    PEC NT0486 • the 3-port DS3, E3, or E1 one-for-one sparing panel NTFP99AA • the 12-port DS3 fanout panel NTHW52 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 162: 32-Port E1 Tdm Cable Assemblies

    15 m (49 ft) When a prefabricated interface cable from Nortel Networks is connected between a E1 FP and a Nortel Networks termination panel, the connection is grounded. You can custom make your own traffic port cables to connect the FP to the...
  • Page 163: Assigning Sparing Panel Connections For 32-Port E1 Tdm Fps

    FPs and their sparing panel. It also identifies the endpoints at the sparing panel from the far-end or next-hop CPE, in this case from a multiport aggregate device. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 164 Control and function processors A sparing panel has a transmit (Tx) and receive (Rx) pair for each port. When cabling Nortel Networks Multiservice Switch FPs and sparing panels, do Tx-to-Tx and Rx-to-Rx for all equipment from the FP up to the far-end termination of the FP connection.
  • Page 165: 12-Port E3 Atm Fp

    Faceplate of a 12-port DS3 FP with PEC NTHR23 (page 152) The figure includes the mapping of port numbers to connector pins. Information on assigning port connections is described in NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade. •...
  • Page 166: 12-Port E3 Fp Line Connections

    The connections can also be made to equivalent non-Nortel Networks equipment provided the cabling criteria are met. When connecting a E3 to a fanout panel, up to three E3 8W8-to-BNC mini- coax cable assemblies are required.
  • Page 167 15 m (49 ft) When a prefabricated interface cable from Nortel Networks is connected between a E3 FP and a Nortel Networks termination panel, the connection is grounded. You can custom make your own control port cable using the following specifications: •...
  • Page 168 NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade. Attention: Unlike Multiservice Switch 7400 series FP faceplates, Multiservice Switch 15000 and Multiservice Switch 20000 FP faceplates have their ports numbered from bottom to top. The reversal is required to accommodate the downward cable management.
  • Page 169 <node_id>/<fp_slot_no>/P0/Rx3 Tx 3 <node_id>/<fp_slot_no>/P0/Tx3 Rx 2 <node_id>/<fp_slot_no>/P0/Rx2 Tx 2 <node_id>/<fp_slot_no>/P0/Tx2 Rx 1 <node_id>/<fp_slot_no>/P0/Rx1 Tx 1 <node_id>/<fp_slot_no>/P0/Tx1 (2 of 2) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 170: 2-Port General Processor With Disk

    (not supported) 100 BT Ethernet port P1 100 BT Ethernet port P0 Lower card latch PPT 3002 001 AA3 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 171: 2-Port Gpdsk Components

    (for example, Enhanced Category 5 UTP cabling) to overcome cross-talk, immunity, and other noise problems. Attention: In order to meet Class B electromagnetic compatibility (EMC) requirements, use shielded twisted pair (STP) cabling. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 172: 4-Port Gigabit Ethernet Fp

    Custom-making an LC cable assembly for an NTHW49 (page 174) • SFP modules for an NTHW49 (page 175) The software name (card type) of the NTHW49 is 4pGe. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 173: 4-Port Gigabit Ethernet Cable Assemblies

    Optional retrofit kit NTPS40 is available to add a stick-on fiber cable management guide to the faceplate of the FP. Versions of the FP prior to PCR 6.1 GA do not have the guide installed at the factory. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 174: Custom-Making An Lc Cable Assembly For An Nthw49

    The LC cable assembly with duplex connectors and duplex cables (page 196) for the limitations of lengths of the cable neck parts Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 175: Sfp Modules For An Nthw49

    (IR) up to 10 km (6.25 mi) and with a nominal wavelength of 1310 nm The general description and purpose of SFPs is in SFP optical modules (page 239). Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 176: 6-Module Packet Server Fp

    FP to support radio bearer processing and protocol conversion. Using the capabilities of the packet server, Nortel Networks Multiservice Switch 15000 and Multiservice Switch 20000 nodes support the development of wireless internet. In the future, other CPU-intensive applications will develop new uses for the card.
  • Page 177: 6Mpktservsp Components

    PMCs, the ATM management hardware, and the processor block • a PCI PMC daughter card containing four PMCs and the ATM segmentation and reassembly (SAR) processors Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 178: 6Mpktservsp Sparing

    PMC-M fails. 6mPktServSP configuration The 6mPktServSP FP has no external connections or ports that need configuration. The card type value <cardtype> for the FP is 6mPktServSP. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 179: 4-Port Mr Pos And Atm Fp

    Identifiers of the 4-port MR POS and ATM FP Software name (card type) 4-port MR POS and ATM NTHW46 4pMRPosAtm Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 180 Optical module sockets Hood captive screw Cable guide Status LEDs Lower card latch Cable guides MSS 3549 001 AA Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 181: Cable Assemblies For A 4-Port Mr Pos And Atm Fp

    Receive characteristics of an NTHW46 with SM OC-12 IR-1/S-4.1 SFP modules (page 182) • Transmit characteristics of an NTHW46 with SM OC-12 LR-1/L-4.1 SFP modules (page 183) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 182 Minimum Maximum Unit Receive laser power Optical path power penalty not applicable Maximum received reflectance not applicable not applicable Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 183 Receive characteristics Minimum Maximum Unit Receive laser power Optical path power penalty not applicable Maximum received reflectance not applicable Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 184: 4-Port Oc-3/Stm-1 Atm Fps

    The CA vintage or higher is required to support hitless software migration and equipment protection features. When a specific identifier is not mentioned, the text applies to both PQC versions of the card. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 185: 4-Port Oc-3/Stm-1 Atm Fp Cable Assembly

    Single-mode fiber cable must have a core diameter of 9 microns and a cladding diameter of 125 microns. The attenuation is less than 0.5 dB/km at 1300 nm. The OC-3 uses standard duplex SC connectors. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 186: 4-Port Oc-3/Stm-1 Atm Fp Optical Interface Characteristics

    Compliant with ITU G.957 Fig 2, ANSI T1E1.2/94-002R1-Fig 10, TA-253 Issue 8 Fig 4-2 Side node suppression ratio (SSR) not applicable Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 187 -14 dBm Minimum receive power (average) -30 dBm Optical path power penalty 1 dB Maximum received reflectance not applicable Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 188: 4-Port Oc-3/Stm-1Ch Tdm/Ces Fp

    4-port OC-3/STM-1Ch TDM/CES FP cable assembly Use only single-mode (SM) fiber cable with the 4-port OC-3/STM-1Ch TDM/ CES FP. You must provide the cable with attached connectors. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 189: 4-Port Oc-3/Stm-1Ch Tdm/Ces Fp Optical Interface Characteristics

    Maximum RMS spectral width 7.7 nm Mean transmission power -15 to -8 dBm Minimum extinction ratio 8.2 dB (1 of 2) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 190 -8 dBm Minimum receive power (average) -31 dBm Optical path power penalty not applicable Maximum received reflectance not applicable Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 191: 16-Port Oc-3/Stm-1 Atm Fp With Mt-Rj Connectors

    MSS 2925 003 AA3 Cable assemblies for an NTHW21 The fiber mode type must be the same as the FP mode type. You must provide the cable with attached connectors. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 192: Optical Interface Characteristics For An Nthw21

    Maximum dispersion 96 ps/nm Maximum RMS spectral width 7.7 nm Mean transmission power -15 to -8 dBm (1 of 2) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 193 -8 dBm Minimum receive power (average) -28 dBm Optical path power penalty 1 dB Maximum received reflectance not applicable Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 194: 16-Port Oc-3/Stm-1 Atm Fp With Lc Connectors

    MSS 2925 003 AB3 Cable assemblies for an NTHW31 With an NTHW31 FP, use single-mode (SM) fiber cable with small-form LC connectors at the FP end. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 195: Cable Specifications For Custom-Making Lc Cable Assemblies

    • After each connector, add a stiff strain relief no longer than 1.6 cm (0.63 in.), as indicated in the figure The LC cable assembly with duplex Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 196: Optical Interface Characteristics For An Nthw31

    General interface characteristics for an NTHW31 (page 197) • Transmit characteristics for an NTHW31 (page 197) • Receive characteristics for an NTHW31 (page 197) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 197 Receive sensitivity at window edge (average) Receive power (average) Optical path power penalty Maximum received reflectance not applicable not applicable Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 198: 16-Port Oc-3/Stm-1 Atm Fp With Oam Cell Conversion

    Cable specifications for custom-making LC cable assemblies The specifications to make an LC cable assembly are the same as described Cable assemblies for an NTHW31 (page 194). Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 199: 16-Port Oc-3/Stm-1 Pos And Atm Fp

    Port 0 Hood captive screw Port 1 Cable guide Lower card Cable guides latch MSS 3397 002 AA3 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 200: Cable Assemblies For An Nthw44

    (NTHW50). Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 201 The fiber mode type must be the same as the SFP mode type. You can have single-mode and multimode SFP modules on the same FP. You must provide the cable with attached connectors. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 202: Sfp Modules For An Nthw44

    Receive characteristics for an NTHW44 with SM IR-1/S-1.1 SFP modules (page 204) • Transmit characteristics for an NTHW44 with SM LR-1/L-1.1 SFP modules (page 204) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 203 Receive power for single-mode intermediate reach (IR) Optical path power penalty not applicable Maximum received reflectance not applicable not applicable Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 204 Eye pattern mask Compliant with Telcordia GR-253-CORE and ITU G.957 Side node suppression ratio (SSR) not applicable Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 205: Cable Specifications For Custom-Making Lc Cable Assemblies

    (0.63 in.), as indicated in the figure The LC cable assembly with duplex connectors and duplex cables (page 196). Applying a coating of resilient Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 206: Specifications For Y-Splitter Cable Assemblies For Y-Protection

    Y-splitter cables used for Y-protection (page 208). The far end can be: • another NTHW44 in a Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000 node • an OC-3 in any other Multiservice Switch node •...
  • Page 207 LC connectors. At the single end of the cable (the far end from the FPs), the connectors are determined by whatever type of optical interface you have for that port. Nortel Networks does not support mixing single-mode and multimode at opposite ends of a connection. If you must have MM at the far end: —...
  • Page 208 - 208 - Control and function processors The behavior of FPs when cabled with Y-splitter cable assemblies is described in NN10600-550 Nortel Networks Multiservice Switch 7400/15000/ 20000 Common Configuration Procedures, in the section about understanding Y-protection for dual FPs. The connection setup of a fiber optical duplex Y-splitter cables used for Y-protection...
  • Page 209 Switch with no slack FP NTHW44 15000 or 20000 cable management channel SS 3467 001 AA Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 210: 1-Port Oc-12/Stm-4 Fp

    (LR) FP. You must provide the cable with attached connectors. The SM fiber cable must have a core diameter of 9 microns and cladding diameter of 125 microns. The attenuation is less than 0.5 dB/km at 1300 nm. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 211: 1-Port Oc-12/Stm-4 Fp Optical Interface Characteristics

    Compliant with ITU G.957 Fig 2, ANSI T1E1.2/94-002R1-Fig 10, TA-253 Issue 8 Fig 4-2 Side node suppression ratio (SSR) 30 dB Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 212 -8 dBm Minimum receive power (average) -28 dBm Optical path power penalty 1 dB Maximum received reflectance -14 dB Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 213: 4-Port Oc-12/Stm-4 Atm Fp

    NTHW11 NTHW86 4pOC12SmIrAtm When a specific PEC is not mentioned, assume the text applies to both PQC versions of the card. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 214: 4-Port Oc-12/Stm-4 Atm Fp Cable Assembly

    FP can send a signal. The maximum distance from the FP to CPE is 15 to 20 km for single- mode cable, depending on the losses due to splices and connectors. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 215: 4-Port Oc-12/Stm-4 Atm Fp Optical Interface Characteristics

    4-port OC-12/STM-4 SM IR ATM FP receive characteristics Receive characteristics Minimum Maximum Unit Receive laser power Sensitivity not applicable Overload not applicable (1 of 2) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 216 Maximum received reflectance not applicable Jitter tolerance Compliant with Telcordia GR-253 and ITU-T G.958 (2 of 2) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 217: 1-Port Oc-48/Stm-16 Atm Fp With Aps

    1-port OC-48/STM-16 ATM FP with APS cable assembly Use only single-mode (SM) fiber cable with the 1-port OC-48/STM-16 ATM FP with APS. You must provide the cable with attached connectors. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 218: 1-Port Oc-48/Stm-16 Atm Fp With Aps Optical Interface Characteristics

    Emission wavelength 1260 1360 Attenuation Maximum dispersion Spectral width Mean transmission power (launch) -5.0 Extinction ratio (1 of 2) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 219 Sensitivity Overload Optical path power penalty Received reflectance Jitter tolerance and transfer Compliant with Telcordia GR-253 and ITU-T G.958 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 220: 1-Port Stm-1Ch Fp

    The single-mode fiber cable must have a core diameter of 9 microns and a cladding diameter of 125 microns. The attenuation is less than 0.5 dB/km at 1300 nm. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 221: 1-Port Stm-1 Fp Optical Interface Characteristics

    Compliant with ITU G.957 Fig 2, ANSI T1E1.2/94-002R1-Fig 10, TA-253 Issue 8 Fig 4-2 Side node suppression ratio (SSR) not applicable Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 222 -8 dBm Minimum receive power (average) -28 dBm Optical path power penalty 1 dB Maximum received reflectance not applicable Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 223: Vpn Extender Card

    VpnXc to provide enhanced IP-VPN scalability without impacting the multi-service performance of Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000 nodes. The VPN extender card is used to host all the virtual routers (VRs) that support IP-VPN services. The VPN extender card allows IP-VPN services to scale well beyond the capabilities of a CP only scenario.
  • Page 224 10 BaseT debug port 2 (not supported) 100 BaseT Ethernet port 1 (not supported) Port 0 Lower card latch PPT 3002 001 AB4 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 225: Vpnxc Components

    The VPN extender card has no external connections or ports that require configuration. The card type value <cardtype> is VpnExtender or VpnXc for the VPN extender card. For more information on configuring Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000 FPs, see NN10600-550 Nortel Networks Multiservice Switch 7400/15000/20000 Common Configuration Procedures.
  • Page 226: Vpnxc Compliance With Standards

    - 226 - Control and function processors VpnXc compliance with standards The VPN extender card is compliant with ISO 8601 and Nortel Networks Corporate Standard 1805.00. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 227: Voice Services Processor 2 (Vsp2) Fp

    The software name (card type) of the NTHW87 is VSP2. Faceplate of a VSP2 FP with PEC NTHW87 Status LEDs Card latches PPT 2973 003 AA3 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 228: Voice Services Processor 3 (Vsp3) Fp

    Internet Protocol (IP) local area network (LAN). Using the gigE ports enables having a direct Ethernet port connection to an IP network without needing an Ethernet card as an interface. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 229: Vsp3 Cable Assemblies

    FP • the signal strength reaching the port must be between -3 dbm and -17 dbm. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 230: Vsp3 Sparing

    The sparing of a VSP3 can be configured from the end that the virtual ports or gigabit Ethernet ports connect to. The sparing for VSP3 cards is different from the usual Nortel Networks Multiservice Switch method of equipment protection because •...
  • Page 231: Nortel Networks Multiservice Switch 15000/20000 Hardware Description

    When using the virtual ports of the a voice services processor 3 (VSP3) function processor (FP) card, no cabling from the FP faceplate is required. The virtual ports communicate through the backplane of the Nortel Networks Multiservice Switch node. When using the gigabit Ethernet ports to access an Internet Protocol (IP) network, the FP must be cabled to various kinds of far-end equipment.
  • Page 232 — one card is configured as the Spare and each other card is configured as a Main — up to nn cards in the same Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000 node are configured for sparing, where...
  • Page 233 It automatically becomes the standby. A switchover from the active to the standby VSP3 card occurs provided: • the attribute switchoverOnFailure under the component IpInterface is enabled (for the description of components, see NN10600-060 Nortel Networks Multiservice Switch 7400/15000/20000 Component Reference) • Media Gateway...
  • Page 234 Switch 8600 VSP3 Port 0 network VRRP Spare Port 1 Bridge Router VSP3 Port 0 SS 3194 001 AA Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 235: Voice Services Processor 3 With Optical Tdm Interface (Vsp3-O) Fp

    Voice services processor 3 with optical TDM interface (VSP3-o) FP The voice services processor 3 with optical TDM interface (VSP3-o) FP card is supported in Media Gateway (MG) cards in a Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000 node.
  • Page 236: Vsp3-O Fp Line Connections

    The VSP3-o FP card can receive IP-routed traffic over the backplane from a 4-port gigabit Ethernet FP card or an ATM IP FP card in the same Nortel Networks Multiservice Switch node, and send the traffic to the TDM network through the active port 0 of the two OC-3/STM-1 optical TDM ports on the VSP3-o FP card.
  • Page 237 The sparing of a VSP3-o FP card can be configured from the end that the virtual ports connect to. The sparing for VSP3-o FP cards is different than the usual Nortel Networks Multiservice Switch method of equipment protection because •...
  • Page 238 Control and function processors The following hardware sparing configurations are supported • one-for-one (formerly 1:1) For details about the hardware sparing setup, see NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard...
  • Page 239: Sfp Optical Modules

    SM or MM fibers. The bale latch on the SFP optical module ensures that the SFP optical module cannot be removed from the FP until unplugging the fiber. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 240: Sfp Optical Module Cable Assemblies

    SFP optical module cable assemblies (page 240). To install or replace an SFP optical module, see NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade. The port on the FP must be configured in software to match the type of module that plugs into it.
  • Page 241: Optical Module Compliances

    1040.10 dated 4-1-03 • LASER Safety IEC Class 1 as per IEC 60825-1 Edition 1.2 dated 2001-08 • Telcordia GR-253-CORE, SONET Transport Systems Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 242: Termination Panels For Fps

    Termination panels for FPs The termination panels available for a Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000 node include fanout panels and sparing panels. These termination panels interconnect equipment to the function processors (FPs) installed in the node.
  • Page 243: Basic Functionality And Operation Of A Sparing Panel

    Basic functionality and operation of a sparing panel The purpose of a sparing panel for Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000 node is to provide space to allow equipment protection to one or more FPs of the same type that are connected to the far end of an FP connection.
  • Page 244: Common Characteristics Of A Sparing Panel

    Common Configuration Procedures. For the procedures to install, replace or redeploy a sparing panel, see NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade. For the description and running of card tests, see NN10600-520 Nortel Networks Multiservice Switch 7400/15000/20000 Fault and Performance Management: Troubleshooting.
  • Page 245: Power Source Of A Sparing Panel

    (Spare) FP can no longer occur. If the Main was active, loss of power makes the sparing panel operate as a one-for-one fanout panel. If the standby FP was active, traffic is lost until the sparing panel is powered again. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 246: Basic Functionality And Operation Of A Fanout Panel

    • provide media conversion • act as a concentrator, reducing the number of cables that are attached to the front of a Multiservice Switch 15000 or Multiservice Switch 20000 • provide a common grounding point for cables • determine the type of connection (DCE or DTE) depending on which...
  • Page 247 Fanout panels do not operate by software or require power. A fanout panel is effectively a fan-in or fan-out patch panel. Some Multiservice Switch sparing panels automatically become a one-for-one fanout panel when power is cut off. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 248: 12-Port Ds3 Or E3 Fanout Panel Nthw52

    The NTHW52 requires no software or power to operate. For the size of the panel, see the table Dimensions of fanout and sparing panels (page 262). Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 249: Assigning The Fanout Panel Cable Connections

    FP connection. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 250 Termination panels for FPs The 12-port fanout panel has 24 connectors, a transmit (Tx) and receive (Rx) pair for each port. When cabling Nortel Networks Multiservice Switch FPs and sparing panels, do Tx-to-Tx and Rx-to-Rx for all equipment from the FP up to the far-end termination of the FP connection.
  • Page 251: 12-Port Ds3 Or E3 Sparing Panel Ntqs31

    FPs in the same sparing group must be connected to the other sparing panel P1s. This is made clear in the FP cabling procedures of NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade. The faceplate has standard female BNC connectors for the signaling ports, standard female DB9 connectors for the control ports, and proprietary female 8W8 D-sub mini-coax connectors from the FPs.
  • Page 252: Testing A Transmit Port On The Ntqs31

    If the external test equipment indicates a problem, then the DS3 or E3 FP and the cable to the port must be tested. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 253 1 to 6. Port numbers are indicated in hexadecimal from 0 (zero) to b. The FP and port numbers each have their own LED display beside the selection buttons. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 254: 4-Port Ds3 Sparing Panel Nthr79

    The size of the panel is in the table Dimensions of fanout and sparing panels (page 262). Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 255 P0 RX From the Main FP, For port test equipment Tx to Tx and Rx to Rx PPT 3205 001 AA Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 256: 3-Port Ds3, E3, Or E1 Sparing Panel Ntfp99Aa

    The NTFP99AA has standard coax BNC-to-BNC connections. See the figure A 3-port DS3, E3, or E1 one-for-one 19-inch sparing panel NTFP99AA (page 257). Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 257 The NTFP99AA can be used as a patch panel without sparing (like a one-for-one fanout panel) for one DS3 card provided the signaling and control port cables are connected to the respective Main ports on the sparing panel. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 258: Multiport Aggregate Device For A 32-Port E1 Tdm

    • NT0486 for the balanced • NT0421 for the unbalanced The multiport aggregate device mounts in a Nortel Networks Multiservice Switch or seismic cabinet, or a standard 19 inch rack. See the figure Balanced multiport aggregate device (page 259) Unbalanced multiport aggregate device (page 259).
  • Page 259 SYSTEM SYNC LOSS Rear view Coax cable Alarm/mgmt Power supply connectors connectors switches (not supported) PPT 2990 001 AB Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 260: Multiport Aggregate Device Connections And Cabling

    (LOS) condition on the link between the device and the FP. The SIG LED on the rear of the device is lit when the device is receiving a signal from Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 261: Multiport Aggregate Device Alarms

    Multiport aggregate device alarms If a power supply for the multiport aggregate device fails, it reports the condition to the Nortel Networks Multiservice Switch node, and the node raises the alarm. E1 alarms from customer equipment are reported to the node through the E1 signal.
  • Page 262: Dimensions Of The Termination Panels

    NEBS 2000 frame, each panel requires adapter brackets from the kit NTHW14. The installation procedure of each termination panel explains how to install the brackets, see NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade.
  • Page 263: Understanding Sparing Panel Replacement

    Measure only the panel sides. For frames with one switch, the sparing or fanout panels must be installed on only the rear uprights. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 264 FPs and the other end of the FP connection can safely accommodate the density of cables. Choose an optimum access and the least congested route. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 265: Cables And Cable Management

    Managing telecom cables Managing telecom cables usually means installing the hardware and then connecting cables to it. With a Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000, there is optional hardware that facilitates easier, quicker, safer, more efficient, and more organized methods of cabling. For...
  • Page 266: Basic Cable Management Brackets For Low-Density Cabling

    When a prefabricated interface cable from Nortel Networks is connected between a DS3 FP and a Nortel Networks termination panel, the connection is grounded. The cable management hardware and method involved in managing telecom cables includes: •...
  • Page 267 FPs management channel Power cable opening from under frame Power cable channel Kickplate from floor PPT 2819 019 AB Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 268 8W8 cables Channel for fiber cables Notch to accomodate Rib for tie-wraps screw heads MSS 3087 004 AA2 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 269: Cable Management Brackets For High-Density Cabling

    The location, and quantity of FPs in one or two nodes, determine if the FP cables must be routed to the left or right side of the frame, and up or down the side of the frame. For more information, see NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade, the section on choosing card slots.
  • Page 270: Very High-Density Cable Management Brackets

    Each high-density cable management bracket (part number P0937935) accommodates fiber or mini-coax cables, or both. Document NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade indicates how many cables of each kind fit through each bracket, and how to calculate how many your node(s) in a NEBS 2000 frame, need.
  • Page 271 PPT 2820 050 AD The extended cable management brackets accommodate only standard coax or the proprietary 8W8 mini-coax cables from Nortel Networks. A bracket for the left side of the frame (while facing the front of the node) has part number...
  • Page 272 • NTRU0366 for cable covers (front or rear panels) To ensure that cable extension brackets fit between two Nortel Networks frames and allow space for the addition or removal of FP cables, the minimum distance between the frames is determined by adding optional joining brackets.
  • Page 273: Hardware To Manage Fiber Cable Slack Near The Node

    Hardware to manage fiber cable slack near the node Fiber cable slack can be managed near a Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000 node by installing one or more optional dual-drawer fiber management units in a NEBS 2000 frame or equivalent close to the node.
  • Page 274 A dual-drawer fiber management unit NTHW50 Sliding drawer Mounting Sliding latch Openings for fiber cables PPT 3035 001 AB Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 275: Location Of Specific Fp Cables In A Bundle

    When the extended cable management brackets are used on both sides of a NEBS 2000 frame, up to 700 cables can be routed from two Nortel Networks Multiservice Switch 15000 nodes fully provisioned with 12-port FPs. When...
  • Page 276 Note: slot 1 of the shelf may contain a CP instead of an FP. (2 of 2) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 277: Cabling A Card With Or Without A Termination Panel

    In general, cabling a Nortel Networks Multiservice Switch card port to a termination panel port means doing Tx-to-Tx and Rx-to-Rx connections for the entire end-to-end connection path. You can also determine the...
  • Page 278: Preparing Oc Or Stm Fiber Distribution Cables

    The fiber distribution cables connect the ports on the function processors (FPs) to a termination port. The customer must supply the fiber distribution cables for a Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000 node. The fiber cable connectors for Multiservice Switch 15000 or Multiservice Switch 20000 FPs are the LC, MT-RJ, or SC type.
  • Page 279: Lc Fiber Cables And Connectors

    Remove any cable slack resulting from cautious cable cutting before fastening the second connector to the cable. Otherwise, install and cable a fiber management unit NTHW50 as described in NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade.
  • Page 280: Mt-Rj Fiber Cables And Connectors

    SC connector (page 280). Ensure that the manufacturer of the cable identifies which SC connector is to transmit and which is to receive. Handling fiber cables is described in NN10600-130 Nortel Networks Multiservice Switch 15000/20000 Hardware Installation, Maintenance, and Upgrade.
  • Page 281: Preparing Coax Distribution Cables

    Preparing coax distribution cables Cards requiring coax connections at the faceplate of FPs or a termination panel can be provided by Nortel Networks in prefabricated cable assemblies or must be provided by you. To custom make your own cables for a specific...
  • Page 282 Labels of mini- coax and BNC cable connections on an NTHR58 cable assembly (page 283) to label the cables at the FP end and at the BNC end. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 283: Preparing Control Port Cables

    PPT 2950 001 AA2 Preparing control port cables For the hardware configurations involving sparing panels, the control port cables are available from Nortel Networks in prefabricated assemblies. Refer to the table Prefabricated FP control port cables for connecting to a sparing panel (page 281).
  • Page 284: Handling Alarm Cables

    Cables and cable management Handling alarm cables A Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000 node has internal alarm cables installed at the time of shipping, and can have had external alarms added for the site. Internal alarm cables connect the...
  • Page 285 1, while the pin furthest from the cluster is numbered 8. See the figure Pinouts of mini-coax and BNC cable connections of an NTHR58 (page 286). Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 286 NTHR58 Mini-coax label cable cluster Pin A8 Orientation space Pin A1 Cable Heat label shrink PPT 2950 001 AA2 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 287: Using Status Indicator Leds And Sounds

    Using status indicator LEDs and sounds The status of hardware equipment in a Nortel Networks Multiservice Switch nods is indicated by a system of colored and shaped LEDs. A lit LED indicates one status in one color. On the same type of part or assembly, the LED is always in the same position relative to its mates.
  • Page 288: Follow-Me Leds

    What to do when a lit amber LED is detected (page 288) • Hierarchy of LEDs and sounds (page 289) The procedures in NN10600-520 Nortel Networks Multiservice Switch 7400/ 15000/20000 Fault and Performance Management: Troubleshooting can help with determining why a LED may not be green.
  • Page 289: Hierarchy Of Leds And Sounds

    FP, because reduced capacity is less important than maintaining the backups that impact greater portions of the node or its service performance Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 290: Status Leds Of A Bip Alarm Module

    • there is a problem with one of the power feeds to the BIP, but this also means that a series of hardware LEDs should not be lit Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 291 When the BIP is the power distribution unit for a Nortel Networks Multiservice Switch 15000 node, pressing the LED test button verifies the operation of the LEDs on the alarm module. When the BIP is the power distribution unit for a Multiservice Switch 20000...
  • Page 292: Status Leds Of A Bim

    What to do when a lit red LED is detected (page 288). Location of BIM status LEDs BIM status LEDs PPT 2819 022 AA Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 293: Status Leds Of A Pim

    Status LEDs of a PIM Each power interface module (PIM) in a Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000 receives power from either the A or B feed, depending on where it connects to the shelf assembly. The LED labelled A indicates the incoming power from power feed A through the BIP, and B indicates the same for power feed B.
  • Page 294 - 294 - Using status indicator LEDs and sounds Location of PIM status LEDs for feeds A and B PPT 3065 002 AA Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 295: Status Leds Of A Fabric

    Fabric card LEDs are described in: • Status LEDs of fabric cards in a Multiservice Switch 15000 (page 295) • Status LEDs of fabric cards in a Multiservice Switch 20000 (page 296) Status LEDs of fabric cards in a Multiservice Switch 15000 During normal operation the circular lit LED is solid green.
  • Page 296: Status Leds Of Fabric Cards In A Multiservice Switch 20000

    - 296 - Using status indicator LEDs and sounds Location of fabric card status LEDs in a Multiservice Switch 15000 Rear (lower) ESD jack cooling unit Fabric status Fabric cover LEDs Access panel Fabric lever to diagnostic connector (For Nortel...
  • Page 297 What to do when a lit red LED is detected (page 288) What to do when a lit amber LED is detected (page 288). Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 298 LEDs Captive screw of fabric lever Fabric lever Captive screw ESD jack Air filter cover PPT 3087 009 AB Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 299: Status Leds Of A Cp Or An Fp Card

    Status LEDs of a CP or an FP card The control processors (CPs) and function processors (FPs) on the front of a Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000 node, each have a column of three LEDs. The sequence from top to bottom is red (circle), amber (triangle), and green (rectangle).
  • Page 300: Status Leds Of A Cp

    Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 301: Status Leds Of An Fp

    (an inactive spare) or the FP is ready to be put into service by the software Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 302: Status Leds Of The Ethernet Ports On An Nthw49

    • When one LED is lit and the other is not, the LED itself has failed. Traffic will continue to flow through that portion of the port. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 303 To determine the operational status of the Ethernet port, especially if a LED is unlit, see the procedures in NN10600-550 Nortel Networks Multiservice Switch 7400/15000/20000 Common Configuration Procedures, to display the status of an installed SFP module.
  • Page 304: Status Leds Of A Sparing Panel

    In a startup mode after installation and powering up, the LED for each cabled FP cycles from solid red to solid green. If the software configuration is not completed for each FP connection on the sparing panel, the LEDs remain red. Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005...
  • Page 305 LEDs connector Monitor port Display indicating Screw selecting selected monitor buttons ports PPT 2819 025 AA Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 306: Status Leds Of A Cooling Unit Fan

    (lower) fans can be determined easily. The rear cooling unit’s LEDs are duplicated at the front and back of a Nortel Networks Multiservice Switch 15000 or Multiservice Switch 20000. The LEDs are labeled with G and R to distinguish between green and red.
  • Page 307: Turning Off The Audible Alarm

    Turn off an audible alarm by pressing the ACO button on the alarm module. See the figure Location of the alarm module status LEDs (page 291). Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks...
  • Page 308: Field Replaceable Units

    Nortel Networks manufacturer are indicated. Service replaceable units (SRUs) are included in the lists as FRUs. The PECs or part numbers that are shared by a Multiservice Switch 15000 and Multiservice Switch 20000, or are unique to either switch, are listed together in tables under the same equipment groups.
  • Page 309: Frus That Plug Into Or Get Screwed Onto A Switch Or Frame

    All other plug-in or screw-on parts for a Multiservice Switch 20000 (page 320) • All other plug-in or screw-on parts for a Multiservice Switch 15000 or Multiservice Switch 20000 (page 321) • Interface cables for interworking between an EdgeLink 100 and a...
  • Page 310: Fp Cards, Sfp Modules, And Termination Panels

    (IR) with MT-RJ connectors • NTHW30, VPN extender card • NTHW31, OC3/STM-1, 16-port, ATM single-mode (SM) intermediate reach (IR) with LC connectors Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 311 (IR-1) cables up to 15 km (9.3 mi) • NTTP05EF SFP in an NTHW46 with single-mode (SM) long reach (LR-1) cables up to 40 km (24.8 mi) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright ©...
  • Page 312: Control Processor (Cp) Cards

    NTHW06, CP3 with DS1 BITS interface (Multiservice Switch 15000) • NTHW06CA, CP3 with DS1 BITS interface (Multiservice Switch 20000) • NTHW08, CP3 with E1 BITS interface (Multiservice Switch 15000 or Multiservice Switch 20000) CP and FP signalling cable assemblies and mounting equipment Order code...
  • Page 313 NTHR57 cooling unit alarm cable assembly, lower or upper NTHR66 cooling unit power cable assembly, lower or upper (1 of 2) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 314 NTPN81 kit to convert NTPN13 to an E1 unbalanced version, includes cable assembly and balun adapter 460 (2 of 2) Spare parts kit NTQS29AA for a Multiservice Switch 15000 Order code Part description A0778937 air filter, medium arrestance @ 25 ppi...
  • Page 315 (BIM), 25-amp, for BIP AP6C67 or AP6C68 NT6C60PB alarm module for BIP AP6C67 or AP6C68 (1 of 2) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 316 NTCC8938 temperature sensor assembly, upper or lower (or A0647397) cooling unit (Rotron Maltese 24 V dc) (1 of 2) Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 317 NTHR68AB or an NTHR51AB A0521940 temperature sensor on an NTHR10AB in an NTHR51AB See also the table Spare parts kit NTQS29AB for a Multiservice Switch 15000 (page 314). BIP parts for a Multiservice Switch 15000 Order code...
  • Page 318 NTHR15 power interface module (PIM) in shelf assembly Note: See also these tables: • Spare parts kit NTQS29AA for a Multiservice Switch 15000 (page 314) • Spare parts kit NTQS29AB for a Multiservice Switch 15000 (page 314) • all those in...
  • Page 319 NEBS 2000 P0887704 BIM filler for a BIP Anchor kits NTRU0302 and NTRU0328 are intended to replace kits NTRU0325 and NTRU0327. (2 of 2) Shelf assemblies for a Multiservice Switch 15000 Order code Part description NTHR50 shelf assembly NTHW99...
  • Page 320 NTPN11, the MAC address module NTPN12 or NTPN13, the alarm/BITS module NTPN15, the power interface module (PIM) All other plug-in or screw-on parts for a Multiservice Switch 15000 Order code Part description NTHR11 MAC address module...
  • Page 321 NTHW85 adaptor bracket kit for mounting a SER 5500 into a NEBS 2000 frame A0378999 wrist strap, antistatic Interface cables for interworking between an EdgeLink 100 and a Multiservice Switch 15000 or Multiservice Switch 20000 Type Part number Length Type of connector at...
  • Page 322: Frus For An Mfa150 System Of Ac Rectifiers

    Field replaceable units FRUs for an MFA150 system of ac rectifiers The following tables list the field replaceable units (FRUs) for an MFA150 system of ac rectifiers to power a Multiservice Switch 15000 or Multiservice Switch 20000: • Relay racks for an MFA150 power system (page 322) •...
  • Page 323 Control and distribution panel Circuit breakers on the controller of an MFA150 Current rating (Amperes) Mid-trip version P0743232 P0878236 P0878240 Nortel Networks Multiservice Switch 15000/20000 Hardware Description NN10600-120 sPCR6.1S1 Standard sPCR6.1 February 2005 Copyright © 2005, Nortel Networks Nortel Networks Confidential...
  • Page 325 Document status: Standard Document issue: sPCR6.1S1 Document date: February 2005 Product release: sPCR6.1 Job function: Product Fundamentals Type: NTP Language type: U.S. English NORTEL, NORTEL NETWORKS, the globemark design, and the NORTEL NETWORKS corporate logo are trademarks of Nortel Networks.

This manual is also suitable for:

2000

Table of Contents
