PCB
Troubleshooting
All SuperVisorTLs are thoroughly tested prior to shipment. However, should you encounter a problem during installation or during the life
of the product, follow the guide below for information on repair and troubleshooting. Additional information may be obtained from the factory
technical help line at 314-996-2800.
Follow the guide below for information on repair and troubleshooting.
Note: LED modules must be replaced as a module. There are no user serviceable parts.
PROBLEM
LED module not
operating when
powered.
Directional module Flash Pattern - Table 2
CycleFlash (DEFAULT)
NFPA QuadFlash75
Steadyburn
ModelFlash
ActiveFlash
FiveFlash70
QuadFlash70
TripleFlash70
DoubleFlash70
SingleFlash75
Flash Pattern Header for OPTIX/LEDX
TROUBLESHOOTING GUIDE
QUESTIONS
a. Bad power/ground
N/A
connection.
b. Defective module.
Quad Pop Flash75
Triple Pop Flash75
SingleFlash375
SingleFlash250
SingleFlash150
FiveFlash150
QuadFlash150
DoubleFlash150
TripleFlash150
Momentarily short and release
to change patterns
J1
POSSIBLE CAUSE
7
SOLUTION
a. Fix connection.
b. Replace module
