BleBox wLightBox v3 User Manual page 4

You can add the controller to your home WiFi network to control it through
this home network or from anywhere in the World. To do this, in the "Connect"
settings section, select a network name from the list and press "Connect". If
is required, enter the WiFi network password. During the connection of the
controller to your home network, the phone / tablet may disconnected from
the network. In this case, you will need to reconnect your phone / tablet to
the controller network.
Please remember that in order to control the device outside the local WiFi
network, from anyplace in the World by using the wBox application, the
option "Remote access enabled" in the controller settings must be set to
"Yes".
Once you've finished configuring the WiFi network, you can disconnect your
phone/tablet from the controller network and connect your mobile device
directly to your home WiFi network. The control from the wBox application
will work the same way as when the phone / tablet is connected to the
controller network. If the user leaves the local network, for example, leaving
home or using the mobile data, the wBox application will signal this state as
"Remote mode". In this case, the devices can be controlled, but for security
reasons settings are not available.
TECHNICAL SPECIFICATIONS
supply voltage
energy consumption
maximum current
maximum voltage
maximum load
supported switches
number of inputs
inputs type
number of outputs
type of outputs
color mode
mounting method
housing
dimensions
protection level
controller operating temperature
protection
API
communication standard
transmission type
12 - 24V
< 1W
15A (3A /channel)
24V
360W
monostable (push-button),
not-illuminated
1
low voltage, logical,
push-button, short circuited to GND
5
open-drain, PWM,
low side control
RGB / RGBW / RGB or W / RGBCCT /
CCT / 2x CCT / 5x MONO
in the flush-mounted box, on the lamp
housing, directly connected to the LED
strip, e.g. furniture
made of polyurethane composition not
containing halogens, self -extinguishing
for thermal class B (130 °C)
43 x 37 x 22mm
IP20
from -20°C to +50°C
inverted polarization, ESD
open
μWiFi, compatible with WiFi, 802.11g
bidirectional, encrypted
supply voltage
radio frequency
mode
encryption
compatible devices and systems
ADDITIONAL INFORMATION
LOCATION AND TIME
OF THE DEVICE, SCHEDULE
The controller has the ability to work according to a given schedule. To
make this possible, set the device's time. Go to settings in the "Device time"
section, click "Change timezone". Then select your region and location from
the list, confirm your selection clicking the "Save" button. The device will
synchronize its time with the server time (if the controller is in a WiFi network
with access to Internet) or it will download time from the phone / tablet. It
is recommended that the controller is always connected to a WiFi network
with Internet access so that it can automatically synchronize its clock.
To be able to control devices using the local sunrise and sunset, you must
also select the location of the controller. You can specify the location of
the device using a smartphone or tablet. In the section "Device location",
click "Set locations". Browser will ask whether to share locations - allow. In
the "Coordinates" field,should appear the approximate coordinates of your
location. If the "Set locations" button blinks red with the word "Error", or
the "Coordinates" field did not change the value from "Not set" to numeric
data, a failurehas occurred during the location download. You should make
sure that the phone / tablet has a GPS module and that the sharinglocation
service is enabled on the phone.
Adding schedule entries can be performed by clicking the "Add item" button
in the "Schedule" section of settings. You can select the days in which the
task will be performed, the type of entry (at a specific time, or relative to
sunrise / sunset - only having a correctly set location) and set the parameters
of the task. The set tasks will be visible as a list, individual entries can be
edited or deleted.
SOFTWARE UPDATE
To update the software in the controller, connect it to your home WiFi
network (see "Access Point and WiFi Network Settings" section) which is
connected to the Internet. Go to "Settings" (icon at the top-right corner of
the screen) and click the "Get new firmware" button in the final section on
settings. Wait about 1 minute, do not close the interface and don't perform
other actions. The device will download the latest software. The software
version number, hardware version and device identifier can be read at the
bottom of the settings screen.
for more information visit our website
www.blebox.eu
or send us an email to: info@blebox.eu
support is available at support@blebox.eu
made in Europe
12 - 24V
2.4 GHz
direct connection (as Access Point),
Wi-Fi connection via a standard router,
connection with access from any
location in the world (re- quires only
access to the Internet)
WPA2-PSK and authenticated
encryption with associated data (AEAD)
Apple iPhone, Apple iPad, iPad Mini,
Android, computers and mobile devices
supporting HTML5
