Technical data EDC-module
wM-Bus
wireless M-Bus
unidirectional,
Transmission
from firmware 1.74:
rate
C1up to firmware
1.74: T1
AES-128
Encryption code
Encryption mode 5
typically 20 s;
Transmission
other configura-
interval
tions possible
Transmission
25 mW
power
Frequency 868 MHz
6. M-Bus module
The EDC-module as M-Bus module is used for inte-
gration of water meters in wired M-Bus networks.
The EDC-M-Bus module which is mounted on the
water meter enables the reading of the water meter
via Bus.
Cable assignment (polarity protected)
Brown
White
Technical data M-Bus interface
Power supply
M-Bus telegram
Operating
temperature
Protection class
Cable assignment
Supported baud rates
(configurable)
Cable length
Elektro-magnetic
compatibility
7. Pulse modules
The pulse modules can be delivered in three differ-
ent versions.
Mode U will be delivered as a standard.
LoRaWAN®
LoRaWAN®
bidirektional
(class A)
AES-128
Szenario 201
(monthly)
Scenario 202 (daily)
25 mW
868 MHz
M-Bus 1
M-Bus 2
Lithium long-life battery (lifetime
up to 15 years depending on
environmental conditions)
M-Bus (EN 13757-3)
> 0 °C to + 55 °C
IP 68
reverse polarity protection
300, 2400 (standard ex works),
9600
1.5 m
complies with the Directive
89/336 / EEC
Technical data pulse module
Number of conductors
Cable length
Output type N-channel
Max. output voltage
Max. output current
Pulse length
Output resistance (open)
Output capacitance
(closed)
Elektro-magnetic
compatibility
Pulse value for all meters
with modulator disc
Cable assignment
green
yellow
grey
EDC-Pulse Output 1
Mode U
balanced* pulses
Mode B1 Forward pulses
Forward and reverse
Mode B2
pulses
Forward and reverse
pulses
Mode B3
(Output 1 before
Output 2)
* Reverse pulses are reduced by the corresponding number
of forward pulses. Function of the pulse modules output
according to ISO 22158
The adjustment of the modes is possible with the
ZENNER-MSS Software by use of a ZENNER
MinoConnect bluetooth or USB and the combined
ZENNER IrDA optical. Alternatively, the ZENNER
Device Manager Basic app can be used instead of the
MSS software.
8. Combined M-Bus and pulse module
The combined M-Bus and pulse module has been
developed specifically to enable the simultaneous
readout by two different users. In this case the pulse
version will be delivered by standard as Mode
3
1.5 m
open-drain
(equivalent to open-collector)
24 VDC
50 mA
125 ms
110 Ώ
1 nF
conforms
the directive 89/336/EWG
DN15-40, 1 l/pulse
DN50-125, 10 l/pulse
DN150-200, 100 l/pulse
Output 1
Output 2
Ground (GND)
Output 2
Dismounting module
alarm resp. cable break
detection (normal state
= closed)
Reverse pulses
Flow direction
(open = forward)
Forward and reverse
pulses
(Output 2 before
Output 1)
U.
