Summary of Contents for BAFANG BT F15.655.C

  • Page 1 8 DEALER MANUAL FOR BT F15.655.C/ BT F15.730.C CONTENT 8.1 Introductions 8.2 Operation 8.1.1 Battery 8.2.1 Installing the battery 8.1.1.1 Safety Instructions 8.2.2 Removing the battery 8.1.1.2 Battery Storage 8.2.3 Charging the Battery 8.1.1.3 Battery Wear 8.2.3.1 Safety Instructions 8.3 Specifications 8.1.1.4 Pedelec Riding Distance...
  • Page 2 ·Please carefully read manual before use. (Suzhou)Co.,Ltd When the battery gets hot keep yourself and Please only use the original BAFANG charger to others a safe distance away from the battery. In charge the battery. The battery is not fully case of damage or heat, you should avoid charged when it is delivered.
  • Page 3 metal objects. It is dangerous if the battery is put into sleep mode after a certain time. short-circuited. As it can lead to overheating, • Do not extend the battery to temperatures smoke, explosion or burning. below the permissible storage temperature Do not heat or burn the battery.
  • Page 4 Be sure to read the information • Use only the original Bafang charger that came about your charger before use! Unplug the with your pedelec. power plug before connecting the battery to the •...
  • Page 5 8.2 OPERATION 8.2.1 Installing the battery 4. Push the top part of the battery into the frame, until you hear the battery lock into For correct insertion, the battery must be position, and turn the limiting stopper to connected, ensuring all pins are correctly keep the battery from dropping.
  • Page 6 8.2.3 Charging the battery • Do not touch the power plug with wet hands. There is a risk of electric shock. Use only the original battery charger supplied to • Note: A sudden rise in temperature can you, as there is a risk of fire or explosion if the cause condensation in the battery.
  • Page 7 8.3 SPECIFICATIONS 8.3.1 Battery Primary Settings BT F15.655.C BT F15.730.C Nominal Voltage 36 Vdc 36 Vdc Nominal Capacity 18.2 Ah 20.3 Ah Min Capacity 17.5 Ah (1C Discharge) 19.25 Ah (1C Discharge) Energy 655 Wh 730 Wh Charging Time 7h with 3A Charger 8h with 3A Charger Storage (At 35% SOC &-10°...
