- Page 1 Eaton® PDI Revit Model Instructions Power Distribution Units Remote Power Panels Static Transfer Switches Floor Stands PowerWave 2 Bus Systems p/n: P-164001110 Revision 01...
-
Page 2: Dear Customer
ToughRail Technology, and WaveStar are registered trademarks of Power Distribution Inc. All other trademarks are held by their respective owners. All other trademarks are property of their respective companies. ©Copyright 2023 Eaton, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Eaton. - Page 3 5 5 W W a a r r r r a a n n t t y y a a n n d d E E n n d d U U s s e e r r L L i i c c e e n n s s e e A A g g r r e e e e m m e e n n t t ........................................2 2 1 1 Eaton PDI Revit Model...
- Page 4 Table of Contents Eaton PDI Revit Model P-164001110—Rev 01...
- Page 5 Tap-Off Box — Dimensional Constraint ..................... 18 Figure 23. Tap-Off Box Clearances ......................... 18 Figure 24. PowerWave 2 Bus System Model with Clearances turned Off ............... 19 Figure 25. PowerWave 2 Bus System Model with Clearances turned On ............... 20 Eaton PDI Revit Model P-164001110—Rev 01...
- Page 6 List of Figures Eaton PDI Revit Model P-164001110—Rev 01...
- Page 7 • Floor Stands (optional features for many Eaton products) • PowerWave 2 Bus Systems Eaton Revit models can be downloaded from the Eaton website for a specific product category or as as complete Revit library. https://www.eaton.com/us/en-us/catalog/low-voltage-power-distribution-controls-systems/eaton-pdi-busway. resources.html Consult with your local or regional sales representatives for help in selecting the correct Revit models for you installation.
- Page 8 Introduction Eaton PDI Revit Model P-164001110—Rev 01...
- Page 9 C C h h a a p p t t e e r r 2 2 S S p p a a c c e e R R e e q q u u i i r r e e m m e e n n t t s s f f o o r r P P D D U U s s , , R R P P P P s s , , a a n n d d S S T T S S s s Eaton Revit models allow you to plan and layout space requirements for Eaton equipment. Many PDU, RPP, and STS configurations are available.
- Page 10 Power Distribution Unit Right Clearance Clearances may also be turned on or off for display purposes only by toggling the corresponding box in the properties tab. The clearance remains in effect whether or not it is displayed. Eaton PDI Revit Model P-164001110—Rev 01...
- Page 11 If the unit has conduit landing areas, they are automatically displayed in the model. The Static Transfer Switch model shown below has conduit landing areas on both the top and bottom of the enclosure. Eaton PDI Revit Model P-164001110—Rev 01...
- Page 12 Space Requirements for PDUs, RPPs, and STSs Figure 4. Static Transfer Switch Conduit Landing Areas (Top and Bottom) Top View Conduit Landing Areas Bottom View Conduit Landing Areas Eaton PDI Revit Model P-164001110—Rev 01...
- Page 13 C C h h a a p p t t e e r r 3 3 S S e e l l e e c c t t i i n n g g F F l l o o o o r r S S t t a a n n d d H H e e i i g g h h t t i i n n R R e e v v i i t t M M o o d d e e l l s s Most Eaton PDU’s, STSs, and RPPs have optional floor stands, which have a range of available heights. The height of the floor stand can be selected or changed in either a Revit Family Window or in a Revit Project.
- Page 14 C C h h a a n n g g i i n n g g t t h h e e F F l l o o o o r r S S t t a a n n d d H H e e i i g g h h t t i i n n a a R R e e v v i i t t P P r r o o j j e e c c t t Import the Floor Stand model into a Project. Highlight the Floor Stand model and click on Properties. In the Properties tool bar, select the Floor Stand drop down. Eaton PDI Revit Model P-164001110—Rev 01...
- Page 15 Figure 7. Revit Project —Floor Stand Drop Down The drop down list displays all of the available heights of the Floor Stand model within Revit. Select a height and the Floor Stand model will automatically adjust to that height. Eaton PDI Revit Model P-164001110—Rev 01...
- Page 16 Selecting Floor Stand Height in Revit Models Figure 8. Revit Project — Floor Stand Available Height List Eaton PDI Revit Model P-164001110—Rev 01...
- Page 17 S S t t a a n n d d a a r r d d E E n n d d F F e e d d Begin by importing the standard End Feed model for your bus run’s amperage. There are two model choices: Standard End Feed with Monitoring and Standard End Feed without Monitoring. Eaton PDI Revit Model P-164001110—Rev 01...
- Page 18 Place the Standard End Feed anywhere in the project space. Clearances: The Standard End Feed’s front clearance is shown by dashed lines of by dashed lines with transparent red shading. Figure 11. Standard End Feed Front Clearance Eaton PDI Revit Model P-164001110—Rev 01...
- Page 19 The length of the Starter Rail can be adjusted in Revit to fit your needs, as follows: Highlight the Starter Rail. Select the Properties tab. Click on the Starter Rail drop down menu located at the top of the Properties tab. Eaton PDI Revit Model P-164001110—Rev 01...
- Page 20 Click to place as many Standard Rails as you need. (Rails are joined by Couplers. While Couplers are essential parts of the bus run, a Coupler does not change the length of the bus run and is automatically included with each Standard Rail.) Eaton PDI Revit Model P-164001110—Rev 01...
- Page 21 Align the middle axis of the End Cap with the middle axis of the Standard Rail and constrain the end of the Standard Rail with the end of the End Cap (use Starter Rail in a 1–rail system.) Figure 17. Middle Axis Alignment — End Cap to Standard Rail Eaton PDI Revit Model P-164001110—Rev 01...
- Page 22 Click to place as many Hangers as needed on the top face of the rails. Figure 19. Hanger Placement Align the Hangers from the ends of the rails by either sliding them into place, or by placing a dimensional constraint. Eaton PDI Revit Model P-164001110—Rev 01...
- Page 23 Align the middle plane of each Tap-Off Box with the middle place of the rail. Figure 21. Middle Plane Alignment — Tap-Off Box to Rail In the Elevations South view, dimensionally constrain each Tap-Off Box to fit on its rail as shown below. Eaton PDI Revit Model P-164001110—Rev 01...
- Page 24 Figure 22. Tap-Off Box — Dimensional Constraint 0’ - 6” Each Tap-Off Box has a clearance that is displaced in the same way as for the Standard End Feed. Figure 23. Tap-Off Box Clearances Eaton PDI Revit Model P-164001110—Rev 01...
- Page 25 A A s s s s e e m m b b l l e e d d B B u u s s S S y y s s t t e e m m V V i i e e w w s s Your fully assembled PowerWave 2 Bus System model should look similar to the figures below. Figure 24. PowerWave 2 Bus System Model with Clearances turned Off Eaton PDI Revit Model P-164001110—Rev 01...
- Page 26 PowerWave 2 Bus System Models in Revit Project Figure 25. PowerWave 2 Bus System Model with Clearances turned On Eaton PDI Revit Model P-164001110—Rev 01...
- Page 27 C C h h a a p p t t e e r r 5 5 W W a a r r r r a a n n t t y y a a n n d d E E n n d d U U s s e e r r L L i i c c e e n n s s e e A A g g r r e e e e m m e e n n t t To view the warranty please click on the link or copy the address to download from the Eaton website: Eaton Product Warranty https://www.eaton.com/content/dam/eaton/products/backup-power-ups-surge-it-power-distribution/backup-...
- Page 28 P-16400111001 P-164001110 01...
