Summary of Contents for Eaton Power Xpert XP2

  • Page 1 Power Xpert XP2 Power Xpert XP2 OHSAS 18001:2007 ISO 9001:2008 ISO 14001:2004 OHS 533652 FM 12680 No: EMS 566536 Installation Manual Installation Manual...
  • Page 2 Introduction This Installation Manual is designed to assist in the Safe Handling and Installation of the Eaton Power Xpert XP2. These instructions are in addition to normal safe working practices as required by the local health and safety regulations. These instructions do not in any way advocate a departure from these requirements.
  • Page 3: Installation

    Eaton recommend that the fi xing brackets must be mounted no more than 500mm from the centre of the joints. For vertical riser installation of sections greater than 2 metres it may be easier to lower the Busbar trunking from the fl...
  • Page 4 Eaton recommend the fi xing brackets be mounted no more than 1.5 metres apart. Ensure that each section of busbar has at least one set of fi xing brackets fi tted and that the Busbar is level and plumb before fi nal tightening of all joints.
  • Page 5 After inspecting the arrangement to ensure it is Step 3. securely installed the hanging support can be removed from the busbar. Attach Spring Hanger Brackets to Unistrut with M10 Hex Bolt and Lock Nut, tighten the bolts to 45Nm ±5Nm. EATON wb-xp2-en...
  • Page 6 Ensure the 2 sections of Busbar trunking are 275mm ±1mm apart and that the joint pack is centred between them. Expansion Rib b) Mount Busbar B fi rmly to the Unistrut®. c) Attach the rear joint pack cover to the Busbar B. EATON wb-xp2-en...
  • Page 7 This is on a visual inspection for any anomalies such as The Earth side plates should sit approx 2mm back from the foreign material etc. Now attach the front Joint Pack Cover to Expansion Rib when positioned correctly. the Busbar. EATON wb-xp2-en...
  • Page 8 EATON wb-xp2-en...
  • Page 9  A cover is required over unused tap off positions to increase the ingress protection (IP) level to the required standard.  When fi tting a new tap off, this cover is to be removed. The drawing opposite shows the removal of the cover Busbar EATON wb-xp2-en...
  • Page 10 Install the rear fi xing brackets as illustrated below. Tap off box Lock Handle Step 7. Megger test installation prior to re-energisation of busbar. Step 8. Before turning the Breaker “ON” , ensure the neutral link is connected and tightened. MCCB Secure rear fi xing brackets EATON wb-xp2-en...
  • Page 11 fi ne grade (240) abrasive paper. Re-install Step 7. When reconnecting the system prior to energisation, the joint and megger test.  If adverse overheating has occurred, please contact Eaton ensure correct Phase Rotation is achieved by testing prior to energising the supply.
  • Page 12 Eaton is a power management company with 2015 sales of $20.9 billion. Eaton provides energyeffi cient solutions that help our customers effectively manage electrical, hydraulic and mechanical power more effi ci- ently, safely and sustainably. Eaton has approximately 97 ,000 employees and sells products to customers in more than 175 countries.
