1. BEFORE YOU START

This is the manual for your Tecnotion motor. Please read this manual very
carefully. The information provided is important for a safe and warranted
installation and operation of the motor. Be sure to have this manual at hand
when installing or working with the motor.
1.1

About this manual

This manual describes the use of a Tecnotion torque motor system. These
motors can be applied in numerous application devices. This manual is
intended for technicians who construct a machine that includes a torque
motor system. It will give insight what aspects to consider for the design
and installation for a torque motor.
1.2

Intended use

A torque motor system is a permanent-magnet direct drive motor that
rotates along an axis. It is intended to be used wherever a rotary movement
is required. Only use this torque motor system as intended, every other use
is not-intended use and therefore not warranted.
1.3

Use of symbols

This symbol describes a tip to inform the user.
This symbol is a non-safety related important notice that the user
should be aware of.
These symbols warn about safety information that should be
respected.
©2021 Tecnotion BV - All rights reserved - The contents of this document are subject to change without prior notice.
1.4

Important notice

Tecnotion declines all responsibility in case of accident or damage due
to negligence or lack of observance of the instructions described in this
manual. Tecnotion also declines all responsibility in case of accident or
damage in conditions that differ from those indicated in the manual;
Tecnotion also declines all responsibility for damage caused by
improper use of the motor.
Handle the components of the motor with care, packed as well as
unpacked.
Do not expose the magnets to temperatures higher than 70° C. The
magnets may be demagnetized at higher temperatures.
Do not expose the stator to temperatures above 100 no curing° C. The
filler material or wiring may be damaged.
Unpack the motor and check its integrity. If there is any irregularity,
contact the dealer or Tecnotion, signaling the nature of the defects.
Make a note of the serial number. This facilitates the correspondence
with the supplier.
1.5

Safety warnings

Use of magnets
The used magnets show large attraction forces on all ferromagnetic
objects such as iron. These forces cannot be controlled by hand. They
may cause serious jamming danger. Do not bring any soft magnetic
objects (iron) nearer than 25 cm of the magnetic side of the magnets
of the rotor.
