Value Description
0 No reset
1 Reset counter
2 Reset alarm
3 Reset counter
4 Reset and disable counter
5 Reset firmware program (soft reset)
6 Reset Alarm info error bit
7 Reset Alarm info warning bit
·
Resetting alarms or the counter can be disabled by Reset Alarm Enable or Reset Counter Enable respectively.
·
Reset value 2 resets alarms on all three communication channels, unless resetting is disabled for 1 or more channels.
Wink
Type
Unsigned char [27]
Sending any decimal value between 1 and 9* to this parameter makes the status indication light flash white for that
number of seconds. This can be useful in order to identify a specific device in a large fieldbus network.
*) On Modbus the required number of seconds is represented by these values:
No. of Wink value
seconds
1 12544
2 12800
3 13056
4 13312
5 13568
6 13824
7 14080
8 14336
9 14592
Control Mode
Type
Unsigned char
Control Mode is used to select different control modes of the instrument and determines from which source(s) it accepts a
setpoint.
The following modes are available:
Value List option
0 Bus/RS232
2 FLOW-BUS slave
3 Valve close
4 Controller idle
7 Setpoint 100%
8 Valve fully open
9 Calibration mode
12 Setpoint 0%
18 RS232
20 Valve steering
22 Valve safe state
40
Access Range
W 0...9
Access Range
RW 0...255
Description
Normal operation
Acting as slave instrument on FLOW-BUS
Controller disabled, valve closed
Controller disabled, valve frozen in current position
Setpoint fixed at 100 %
Controller disabled, valve fully open
Calibration mode enabled
Setpoint fixed at 0%
Controlling, default/safe state
Controller disabled, setpoint redirected to Valve Output
Instrument in
Instruction Manual FLEXI-FLOW™ Compact
Bronkhorst®
FlowDDE FLOW-BUS
1 0/0
FlowDDE FLOW-BUS
12 115/1
20
disabled
20
default/safe state
Modbus
0x0000/1
Modbus
0x0024/37
Setpoint source
Fieldbus
FLOW-BUS master
Fieldbus
9.17.158D
