- Page 1 Armoire Version:09/28/2022 1/11...
- Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
- Page 3 Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size E x 31 A x 16 B x 16 D x 5 C x 20 6 x 35 mm 4 x 35 mm 3 x 10 mm...
- Page 4 4/11...
- Page 5 A x 12 6 x 35 mm Insert quickfit screw(A) into corresponding holes in No.5 and No.6 plate with a screwdriver. A x 4 6 x 35 mm Insert quickfit screw(A) into corresponding holes in No.3 plate with a screwdriver as shown.
- Page 6 C x 12 B x 12 8 x 30 mm 15 x 9 mm Connect No.5 and No.6 plate with No.3(x3) using wooden dowel(C), then turn cam lock(B) clockwise to tighten as shown. 180° C x 8 B x 4 D x 4 8 x 30 mm 15 x 9 mm...
- Page 7 E x 31 F x 1 O x 1 P x 1 3 x10 mm 4 x 14 mm Attach No.7 plate to the back using screw(E) as shown. Fix part(F) to No.7 plate with washe(P) and screw(O) as shown. G x 2 O x 16 H x 2...
- Page 8 I x 12 K x 2 L x 2 J x 6 4 x 14 mm 4 x 16 mm Please don't use an electric drill or use force to rotate, may cause crack. Fix hinge(J) to the No.8 and No.9 door plate respectively with screw(I) as shown.
- Page 9 If there is misalignment after you install, adjust the screw to the best condition. 9/11...
- Page 10 M x 16 Insert part(M) into No.5 and No.6 plate at first. Place No.2 shelves in as shown. 10/11...
- Page 11 N x 1 P x 1 D x 1 4 x 35 mm 6 x 30 mm For extra stability, it is recommended that you fix your item to the wall using the additional hardware(D,N,P), as shown. Should you choose not to affix the product to the wall,serious injury may be caused if the product tips over.
