X300 Quick Start Guide
LOG INTO THE GATEWAY
Note: The DHCP client must be enabled on your computer to obtain a
valid IP address from the gateway. Refer to your computer's operating
system documentation if you need details.
To connect using Wi-Fi: In the computer's Wi-Fi network settings, select
the gateway's Wi-Fi access point SSID and click Connect. Enter the default
WPA/WPA2 key when prompted.
To connect using Ethernet: Attach one end of a Cat5 cable to the unit's
LAN port and the other end to the computer's LAN port.
1.
To log into the Web Admin interface, open a web browser and type
the unit's LAN IP address, 192.168.1.1, in the URL field.
2.
On the first login, enter the root user name and password. It will
prompt you to change all passwords at once.
Note: Change the initial password for both the root and admin users
before configuring the gateway.
QUICK SETUP
To configure the network interface:
1.
Log into the Web Admin interface and click the Quick Setup menu.
2.
Click the Quick Setup button to display the Network Setup page,
where you can configure the LAN and Wireless network interfaces.
3.
Click Save & Apply.
Note: If you changed the LAN IP address, select Apply unchecked to
avoid roll back of the configuration.
ACTIVATE YOUR LANTRONIX SERVICES
1.
Open the camera app on your smartphone and point
it at the QR code.
2.
Tap the notification to open the link associated with
the QR code.
3.
Complete the enrollment form to register the device.
© 2023 Lantronix, Inc. Lantronix is a registered trademark of Lantronix, Inc. All other trademarks are the property of their respective
owners. Specifications subject to change without notice. 895-0053-00 Rev. A
Default Credentials
Access Point SSID
Parameter
Default Value
SSID
Lantronix-<model>-<serial-number>
WPA/WPA2 Key
W1rele$$
Web Admin Console
User name
Default Password
admin
admin
root
L@ntr0n1x
For support links and the latest firmware
https://www.lantronix.com/technical-support
2
IoT Cellular Gateway
Lantronix Support
and documentation, visit
