PMBus interface. The mEZDPD4506A offers a complete power solution that achieves up to 6A continuous output current with excellent load and line regulation over a wide input voltage range. MPS’s proprietary, multi-phase constant-on-time (MCOT) control provides ultra-fast transient response and simple loop compensation.
USER GUIDE – mEZDPD4506A EVALUATION KIT (PKT-mEZDPD4506A) Features and Benefits The mEZDPD4506A is highly customizable. Users can program the power module via the MPS PMBus and multi-time programming (MTP) memory. ⚠️ Values written to the registers via PMBus will NOT be retained once the module is powered down unless they are written into the MTP memory.
PC, and its supporting accessories. Together with the eMotion System Virtual Bench Pro GUI tool, it provides a quick and easy way to evaluate the performance of MPS digital products. For more details, refer to the EVKT-USBI2C-02 datasheet.
The eMotion System Virtual Bench Pro GUI tool provides an easy way to access the registers, program the MTP memory, and monitor the key parameters of MPS power modules. Follow the instructions below to install the software: 1. Download the GUI installation file, “Virtual Bench Pro 3.0,” from the MPS website at: https://www.monolithicpower.com/en/virtual-bench-pro-3-0.html...
USER GUIDE – mEZDPD4506A EVALUATION KIT (PKT-mEZDPD4506A) 3.4 Device Programming Instructions The MTP memory of mEZDPD4506A can be custom programmed. Follow the instructions below to create and export customized configurations: 1. Connect the EVB to a PC following the steps in Section 3.3.
USER GUIDE – mEZDPD4506A EVALUATION KIT (PKT-mEZDPD4506A) 3.5 Troubleshooting Tips Note: USBI2C-02 and USBI2C-01 drivers are not compatible. USBI2C-02 uses USBXpress and USBI2C- 01 uses Cyusb3. USBI2C-02 is the recommended device for MPS PMBus and I EVKT-USBI2C-01 If the USBI2C-01 driver is not properly installed, manual installation is required.
Page 13
PC. Re-plug the USB into the computer and restart the GUI. No Output Voltage The mEZDPD4506A offers many protection features. If any of the protection functions are triggered, the power module may latch off. The indicator on the right panel indicates the specific fault. A red indicator signifies that a fault has been triggered.
It is based on the principles of I C operation. The mEZDPD4506A interface is a PMBus slave, which supports both the standard mode (100kHz) and fast mode (400kHz and 1000KHz). The PMBus interface adds flexibility to the power supply solution.
