  • Page 1 User Guide MP2663 Evaluation Kit (EVKT-MP2663)

  • Page 2: Table Of Contents

    3.4 Device Programming Instructions ....................8 3.5 Troubleshooting Tips ........................10 Section 4. Ordering Information ......................11 MP2663 Evaluation Kit User Guide rev 1.0 MonolithicPower.com 3/13/2019 MPS Proprietary Information. Patent Protected. Unauthorized Photocopy and Duplication Prohibited. © 2019 MPS. All Rights Reserved.

  • Page 3: Overview

    Overview Introduction The EVKT-MP2663 is an evaluation kit for the MP2663. This board is designed for the MP2663, which is a highly-integrated single-cell Li-Ion/Li-Polymer battery charger with a system power-path management function. The layout accommodates most commonly used capacitors. The default function of this board is preset for charger mode and the charge full voltage is preset to 4.095V for 1 cell Li-Ion battery.

  • Page 4: Features And Benefits

    Windows XP, 7, and later System Requirements Minimum 22.2 MB free GUI Software MP2663 V1.0 MP2663 Evaluation Kit User Guide rev 1.0 MonolithicPower.com 3/13/2019 MPS Proprietary Information. Patent Protected. Unauthorized Photocopy and Duplication Prohibited. © 2019 MPS. All Rights Reserved.

  • Page 5: Section 1. Hardware Specifications

    C capabilities. Together with MPS Virtual Bench Pro and I C GUI tools, it provides a quick and easy way to evaluate the performance of MPS digital products. For more details, refer to the EVKT-USBI2C-02 datasheet. Figure 3: EVKT-USBI2C-02 Communication Interface MP2663 Evaluation Kit User Guide rev 1.0...

  • Page 6: Section 2. Software Requirements

    Programming occurs through the MPS I C GUI. Follow the instructions below to install the software. Note: This software can be downloaded from the MPS website: 1. Download and extract the zip package of the “I C evaluation kit software for MP2663” to a directory of your choice.

  • Page 7: Section 3. Evaluation Kit Test Set-Up

    After connecting the hardware according to Section 3.1 and Section3.2, follow the steps below to use the GUI software: 1. Start the software. It will check the EVB connection automatically.  If connection is successful, both the USB and MP2663 DEMO board statuses are "connected". (See Figure 7). MP2663 Evaluation Kit User Guide rev 1.0 MonolithicPower.com 3/13/2019 MPS Proprietary Information.
  • Page 8 If connection is not successful, "Not Connected" will appear in red. Check connections between the EVB, communication interface, and PC. Re-plug the USB into the computer. 1) MP2663 DEMO Board “Not Connected" means that the evaluation board is not connected correctly.

  • Page 9: Device Programming Instructions

    MP2663 Evaluation Kit (EVKT-MP2663) 3.4 Device Programming Instructions The MP2663-xxxx is an OTP part. Follow the instructions outlined below to create and export customized configurations. 1. Using a computer, open the MPS GUI software. Make sure you have powered on the EVB.
  • Page 10 Figure 11: Various Export Locations Available 7. Send this file to an FAE and apply for the customized "xxxx" code. MP2663 Evaluation Kit User Guide rev 1.0 MonolithicPower.com 3/13/2019 MPS Proprietary Information. Patent Protected. Unauthorized Photocopy and Duplication Prohibited. © 2019 MPS. All Rights Reserved.

  • Page 11: Troubleshooting Tips

     Thermal Recovery If the MP2663 is in a shutdown state due to the die temperature exceeding the thermal protection threshold, the IC enters a power-on sequence when the die’s temperature decreases. MP2663 Evaluation Kit User Guide rev 1.0 MonolithicPower.com...

  • Page 12: Section 4. Ordering Information

    Includes datasheet, user guide, product brief, and GUI Order directly from MonolithicPower.com or our distributors. MP2663 Evaluation Kit User Guide rev 1.0 MonolithicPower.com 3/13/2019 MPS Proprietary Information. Patent Protected. Unauthorized Photocopy and Duplication Prohibited. © 2019 MPS. All Rights Reserved.
