- Page 1 NIMBO-24 Loudspeakers Top Performance Cabinet Loudspeaker USER MANUAL 50-0435-0100 NIMBO-24...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PRECAUTIONS ........................3 1.1 Important Remark ..........................3 1.2 Important Safety Instructions ......................4 1.3 Cleaning ..............................4 PACKAGE CONTENTS ......................5 DESCRIPTION & FEATURES ....................5 3.1 Main Features ............................6 CONNECTIONS ........................6 4.1 Connections Diagram .......................... 7 4.2 Impedance Selector .......................... -
Page 3: Precautions
1. PRECAUTIONS 1.1 IMPORTANT REMARK The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. -
Page 4: Important Safety Instructions
1.2 IMPORTANT SAFETY INSTRUCTIONS Read these instructions. 12. Unplug the device during lightening sorts or when unused for long periods Keep these instructions. of time. Heed all warnings. Refer servicing qualified Follow all instructions. personnel. Servicing is required when Do not use this device near water. the device has been damaged in any Clean only with dry cloth. -
Page 5: Package Contents
Warranty card. 3. DESCRIPTION & FEATURES NIMBO-24 is a premium performance 2-way passive loudspeaker with 80W RMS power, in a compact size with extended low frequency response. Suitable for outdoor applications, with a cloud-inspired design, result of Ecler's engineering skills and the collaboration of architects and interior designers. -
Page 6: Main Features
3.1 MAIN FEATURES • 2-way passive loudspeaker for surface and ceiling mounting. • 2x 4" woofers with 4-layer voice coil improves power handling and low frequency response. 1" silk tweeter with neodymium magnet and ferrofluid. • • Glass-fibre reinforced ABS non resonant compact enclosure. •... -
Page 7: Connections Diagram
4.1 CONNECTIONS DIAGRAM... -
Page 8: Impedance Selector
(behind the logo) that allows to select its working mode without removing the grill. 5. EQ SETTINGS The Ecler NIMBO-24 EQ Settings file will be available on our website in the coming weeks, ready to import in EclerNet Manager software. 6. RECOMMENDED AMPLIFIER... -
Page 9: Positioning & Installation
7. POSITIONING & INSTALLATION 7.1 POSITIONING Consider following general rules. Place the speaker on a solid and firm surface. No obstacles should stand between the enclosures and the audience. The high frequencies are very directive compared to the low frequencies, so that any obstacle will impair their response. In case large audiences must be addressed, a better long distance sound propagation will be achieved if the enclosures are flown high enough. -
Page 10: Installation Diagram
7.3 INSTALLATION DIAGRAM Mounting the VEASY wall bracket. -
Page 12: Technical Data
8. TECHNICAL DATA 8.1 TECHNICAL SPECIFICATIONS NIMBO-24 SYSTEM Effective Freq. Range 62Hz-20kHz (-10dB) Coverage angle 165°x150° (HxV) Power handling 80 W RMS / 320 W Peak Sensitivity 84 dB (1W/1m) Maximum SPL 103 dB continuous / 109 dB peak Recommended amplifier power... -
Page 13: Mechanical Diagram
8.2 MECHANICAL DIAGRAM All measures in mm. - Page 15 NEEC AUDIO BARCELONA S.L. reserves the right to make changes or improvements in the design or manufacturing that may affect these product specifications. For technical queries contact your supplier, distributor or complete the contact form on our website, Support / Technical requests. Motors, 166‐168 -08038 Barcelona ‐ Spain‐(+34) 932238403 information@ecler.com www.ecler.com...
