7. Installation Procedures
7.1 DIN Rail Installation
Attach the DIN Rail Bracket (if not fitted) to
the switch case using the screws supplied
7.2 Wall Mount Installation
Attach the Wall Mount Bracket (if not fitted)
to the switch case using the screws supplied
Clip the upper edge of the bracket onto the
DIN Rail and push to latch the bottom strip
Mount the switch to the required surface
using appropriate fixings
