Briggs & Stratton R020832 Operator's Manual

Briggs & Stratton R020832 Operator's Manual

Reconditioned pressure washer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Reconditioned Pressure Washer
Operator's Manual
R020832
Copyright © 2022. Briggs & Stratton
Milwaukee, WI, USA. All rights reserved.
(800) 743-4115
Manual No. 80110228 Rev B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R020832 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Briggs & Stratton R020832

Summary of Contents for Briggs & Stratton R020832

  • Page 1 Reconditioned Pressure Washer Operator’s Manual R020832 Copyright © 2022. Briggs & Stratton Milwaukee, WI, USA. All rights reserved. (800) 743-4115 Manual No. 80110228 Rev B...

  • Page 2: Table Of Contents

    Table of Contents Symbol Name Explanation Symbols and Meanings ......2 High-pressure water could cut Fluid through skin resulting in serious Assembly.

  • Page 3: Assembly

    Assembly Assemble Handle...

  • Page 4: Equipment Description

    Equipment Description Stay alert—watch what you are doing. Do not operate pressure washer when fatigued or under the influence of Read this manual carefully and become familiar alcohol or drugs. with your product. Know its applications, its Every effort has been made to ensure that information in limitations, and any hazards involved.

  • Page 5: Features And Controls

    Features and Controls Compare the illustrations with your pressure washer to familiarize yourself with the locations of various controls and product warnings.
  • Page 6 Spray Gun 7-in-1 Nozzle Spray Wand Engine Switch Automatic Cool Down System (on pump) Detergent Tank 7-in-1 Nozzle — Multiple patterns for various cleaning Spray Wand — Allows you to switch between nozzles and applications. optional accessories. Automatic Cool Down System — Prevents internal pump Spray Gun —...

  • Page 7: Operation

    Operation WARNING! Engine exhaust contains carbon monoxide, a poisonous gas that could kill you in minutes. You cannot smell it, see it, or taste it. Step 1: Safe Location Even if you do not smell exhaust fumes, you could still be Before starting the pressure washer, there are two equally exposed to carbon monoxide gas.
  • Page 8 Step 2: Oil and Fuel Operation Location to Reduce the Risk of Fire WARNING! Exhaust heat/gases could ignite Check Oil Level combustibles, structures or damage fuel tank CAUTION! Avoid prolonged or repeated skin causing a fire, resulting in death or serious contact with used motor oil.
  • Page 9 1. Slowly remove fuel cap to relieve pressure in tank. Check / Connect Gun and Hose 2. Slowly add fuel to fuel tank. Do not fill above bottom of 1. If spray gun trigger depresses without pressing fuel tank neck to allow for fuel expansion. trigger lock or if spray gun remains depressed when released, replace spray gun immediately.
  • Page 10 Step 4: Turbo and 7-in-1 Nozzles Check Water Inlet Screen / Connect Garden Hose 1. Inspect inlet screen. Remove debris or replace if 1. Select turbo nozzle or desired nozzle setting on 7-in-1 damaged. nozzle: High Pressure: Inlet Screen Low Pressure: Turbo: 2.
  • Page 11 Step 5: Start Up 7. When engine starts, move choke lever to RUN ( ) position. NOTICE Do not start engine without water supply NOTICE If engine starts but fails to run, see Low Oil connected and turned on. Shutdown in Features and Controls. 1.
  • Page 12 Step 7: Shut Down Usage Tips • For most effective cleaning when in high pressure, 1. Release spray gun trigger and let engine idle for one keep turbo or 7-in-1 nozzle 8 to 24 in (20 to 61 cm) minute. away from cleaning surface.

  • Page 13: Maintenance

    Maintenance Detergent Siphoning Check Ball The check ball in detergent siphoning system may become Maintenance Schedule stuck from dried soap or minerals in water. The check ball can be freed by performing the following: Follow the hourly or calendar intervals, whichever occurs first.
  • Page 14 Add Engine Oil Fastener Cover Fastener 1. Place pressure washer on level surface. Filter 2. Clean area around oil fill and remove yellow oil fill cap/ dipstick. 4. Using an oil funnel, slowly pour contents of oil bottle into oil fill opening. Checking oil level frequently, fill to point of overflowing.

  • Page 15: Storage

    Common Service Parts Protecting the Pressure Washer 4. Turn off water and purge system. Pump Saver™....... .6039 5.

  • Page 16: Troubleshooting

    Troubleshooting Problem Cause Correction 1. Inadequate water supply. 1. Provide adequate water flow. Pump has following 2. Clogged inlet hose screen. 2. Check and clean inlet hose screen. problems: failure to 3. 7-in-1 nozzle is obstructed. 3. Clean nozzles. See 7-in-1 Nozzle produce pressure, loss Maintenance.

  • Page 20: Warranty

    BRIGGS & STRATTON RECONDITIONED PRODUCTS WARRANTY POLICY January 2014 LIMITED WARRANTY Briggs & Stratton warrants that, during the warranty period specified below, it will repair or replace, free of charge, any part that is defective in material or workmanship or both. Transportation charges on product submitted for repair or replacement under this warranty must be borne by purchaser. This warranty is effective for and is subject to the time periods and conditions stated below.
