PA768 Gun Grip

Quick Start Guide

Getting Start (Continued)

2. The black mylar on the pogo pin (for gun grip)

3. The hand strap and fixed arm

Package

Please make sure the following contents are in the

PA768 Gun Grip gift box. If something is missing or

damaged, please contact your Unitech representative.

The Package Content

• PA768 Gun Grip

• Wrist Strap

Getting Start

Please remove the following items from PA768

before using.

1. The Bottom Bumper

V1.0

Pogo Pin on PA768/Gun Grip

Pogo pin of gun grip:

connected with PA768

via pogo pin

Pogo pin for gun grip

Table of Contents

Need help?

Do you have a question about the PA768 and is the answer not in the manual?

Page 1 Package Please make sure the following contents are in the PA768 Gun Grip gift box. If something is missing or damaged, please contact your Unitech representative. The Package Content PA768 Gun Grip • PA768 Gun Grip • Wrist Strap Getting Start Please remove the following items from PA768 before using.
Page 2 Disassemble with Terminal Assemble with Terminal 1. Align PA768 with the gun grip and insert from Grab two protrusions on both sides of gun grip, about 45 degree angle. and bent outward while pushing PA768 upward, then you can remove it from the gun grip.
