- Page 1 - PA768 - User Manual Version 1.9 © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
- Page 2 Update Relevant Battery Information V1.9 © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 3: Preface
© 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... - Page 4 Use of other accessories may not ensure compliance with FCC RF exposure guidelines. European Conformity Statement Unitech Electronics co., Ltd herewith declares that the Unitech product is in compliance with the essential requirements and all other provisions of the RED 2014/53/EU directive.
-
Page 5: Ce Mark Warning
ICNIRP exposure guidelines. CE Mark Warning © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 6: Rohs Statement
Waste electrical and electronic equipment (WEEE) Unitech has set up a policy and process to meet the 2012/19/EU concerning electronic waste disposal. For more detailed information of the electronic waste disposal of the products you have purchased from Unitech directly or via Unitech’s resellers, you shall either... -
Page 7: Taiwan Ncc Warning Statement
MSS operations. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 8: Laser Information
Laser Information The Unitech product is certified in the U.S. to conform to the requirements of DHHS/CDRH 21CFR Subchapter J and to the requirements of IEC 60825-1. Class II and Class 2 products are not considered to be hazardous. The Unitech product contains internally a Visible Laser Diode (VLD) whose emissions do not exceed the maximum limits as set forth in the above regulations. -
Page 9: Battery Notice
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 10: Maintenance And Safety
Dip the cotton part of a cotton-tipped applicator in isopropyl alcohol. viii © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 11: Battery Safety Guidelines
Do not put the battery in a microwave or dryer. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 12: Product Operation And Storage Notice
Unitech product for charging. Please remove the power adapter when the battery is fully recharged. The bundled power adapter that comes with your Unitech product is not meant to be used outdoors. An adapter exposed to water or rain, or a very humid environment can cause damage to both the adapter and the product. -
Page 13: Hearing Damage Warning
To prevent possible hearing damage, do not listen at high volume levels for long periods. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 14: Worldwide Support
Worldwide Support Unitech’s professional support team is available to quickly answer questions or assist with technical-related issues. Should an equipment problem occur, please contact the nearest Unitech regional service representative. For complete contact information please visit the Web sites listed below: Taipei, Taiwan –... -
Page 15: Warranty Policy
The warranty period is varied from each country. Please consult with your supplier or Unitech local office for actual length of warranty period to your purchased product. Warranty becomes void if equipment is modified, improperly installed or used, damaged by accident or neglect, or if any parts are improperly installed or replaced by the user. -
Page 16: Table Of Contents
2.14 Network Time Protocol (NTP) Server ..........55 © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... - Page 17 3.5 Software Update ................... 67 3.6 StageGO....................69 © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 18: Chapter 1 - Overview
PA768 User Manual EA520 User’s Manual Chapter 1 - Overview 1.1 Package Please make sure the following contents are in the PA768 gift box. If something is missing or damaged, please contact your Unitech representative. The Package Contents PA768 Rugged Handheld Computer ... -
Page 19: Product Detail
9. Scanner Trigger Key 5. Volume Key © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... - Page 20 20. USB Type-C Hole 15. NFC © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 21: Specifications
Support: ISO14443A/B, ISO15693, Mifare, Felica (ISO/IEC18092) © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... - Page 22 Operating temperature -4°F to 131°F (-20°C to 55°C) © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
- Page 23 ES SE UK NO CH TR © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 24: Getting Started
You may put in 2 SIM cards or one SIM card and one SD card at a time. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 25: Remove The Battery
2. Push the battery against the front and lift to remove. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 26: Install The Battery
3. Press down the battery to secure in place © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 27: Charging The Battery
To charge the PA768, please use the USB charging cable or the cradle. Connect the type C USB cable to the USB port on PA768 and the other end of the USB cable connect to AC power adapter into the electrical outlet on the USB plug. -
Page 28: Battery Info
Please go to Settings → BatteryInfo for more detailed battery information. 1.4.5.1 BatteryInfo Health Service BatteryInfo health service information will display on both PA768 lock screen and the notification bar. ￭ When the battery health is higher than 80% : ©... - Page 29 Settings → Battery → Battery Care, as shown below to configure the charging limit. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
- Page 30 50% state of charge if you’re planning to store them long-term. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
- Page 31 EA520 User’s Manual 1.4.6 Turning on the PA768 for the first time It is recommended to fully charge PA768 before first use. You can now start up your device to set up the languages, WLAN setting, and date and time.
-
Page 32: Checking The Led Status
© 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 33: Chapter 2 - Installation & Operation
Or from the notification bar to tap ScanService. You now enter the Unitech scan service application. 2.1.1 Settings After you enter the Unitech scan service application, please tap the screen to see all the settings of USS. © 2024 Unitech Electronics Co., Ltd. All rights reserved. -
Page 34: Barcode Scan
Save / Load Settings, and Factory Default. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... - Page 35 The saved data is stored in Files →Documents © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
- Page 36 3.1 USS (Unitech scan service) © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 37: Hf Setting
2.Tap Connection Preferences to enable NFC © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... - Page 38 EA520 User’s Manual Make sure that both devices are unlocked and have NFC turned on. Also make sure that the NFC antenna area of PA768 and the other phone's NFC area are close to one another. Slightly moving the phones until a connection is made.
- Page 39 The saved data is stored in Files →Documents © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 40: Wwan Setting
For the instruction, please refer to 1.4.1 Inserting the Micro SD/Nano SIM Card 2. Turn on the PA768, LTE signal will show at the top of the screen. 2.3.1 Mobile Network Settings On the main screen, scroll the screen from bottom to top to reach the APPS, and tap Settings and then tap Network &... - Page 41 To switch between 2 SIMs, tap on data preference. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
- Page 42 To choose different network type, please tap Preferred network type. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 43: Wlan Setting
Tap Internet and turn WLAN ON to see available networks. Tap to choose available networks. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... - Page 44 © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 45: Wlan Advanced
Settings then WLAN Advanced. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... - Page 46 EA520 User’s Manual Tap on Advanced. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
- Page 47 AP. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 48: Other Options
Initialize is able to restore the default settings. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... - Page 49 2. Tap Internet and turn WLAN ON to see available networks, then tap to choose the available networks. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
- Page 50 When Wi-Fi is connected, tap “Share” icon to show QR code. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 51: Pan Setting
Tap Connection Preferences to enable Bluetooth © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... - Page 52 ON to choose the available device. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 53: Gps Setting
Tap ON/OFF for the permission to use your location information. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 54: Pc Setting
PA768 User Manual EA520 User’s Manual 2.7 PC Setting Connect PA768 to your computer with the USB type C cable. Your computer will recognize it is USB charging. Slide down from top, the system will show as follow picture, then you can tap on Android System Charging this device via USB. - Page 55 Then you can select File Transfer. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 56: Camera Setting
Scroll the screen from down to top to reach the APPS, and tap Camera. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... - Page 57 For the first time turn on, the screen will show a brief introduction about camera settings. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
- Page 58 © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
- Page 59 Once tap the record button, it will start recording. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 60: Uss Camera
1. Scroll the screen from down to top to reach the APPS, and tap USSCamera. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... - Page 61 2. Select the types of barcodes from the settings. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
- Page 62 © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
- Page 63 The icon will appear on the main screen. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
- Page 64 Note: To close the floating window, simply by not selecting the Scan to Key. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 65: Performing A Hardware Reset
EA520 User’s Manual 2.10 Performing a Hardware Reset You may have to perform a reset if the device freezes (i.e., the PA768 no longer responds to the buttons or tapping on the screen). Long press and hold the Power button around 10 seconds to restart the device. -
Page 66: Performing Factory Data Reset
Note: When you select Erase all data (factory reset) in the Reset Options, it will erase all folders. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 67: Keyremap
PA768 User Manual EA520 User’s Manual 2.12 KeyRemap The PA768’s keys can be programmed for users to be able to perform different functions or applications. Four options to use key remap functions: Volume_Up, Volume_Down, Programmable Key 1, Scanner Triger Key Left and Scanner Triger Key Right. -
Page 68: Export File
Note: The configuration file (keys_config.txt is saved in Files. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 69: Import File
2. Select Reset all settings © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 70: Split Screen
1. Tap Background APP button until you see those background apps on the screen. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... - Page 71 APPs to expand the app that you would like to keep in full screen. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 72: Network Time Protocol (Ntp) Server
Settings → System → Data & time. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... - Page 73 2. Tap set ntp (Network Time Protocol) Server. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 74: Chapter 3 - Introduction To Applications
© 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... - Page 75 EA520 User’s Manual Solution Introduction StageGO is a barcode-based device staging solution from Unitech that helps IT admins to swiftly set up a device by just a few barcode scans. StageGO For versatile functions of RFID command via integrating with Unitech RFID Readers.
-
Page 76: Uss (Unitech Scan Service)
APPS, and tap Settings and then tap USS ( Unitech scan service ). Or from the notification bar to tap USS ( Unitech scan service ). You now enter the Unitech scan service application. © 2024 Unitech Electronics Co., Ltd. All rights reserved. -
Page 77: How To Scan
1. After scanning the barcodes, the barcode information is shown as below. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... - Page 78 For more options and settings, please tap © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 79: Picklist Mode
3.2.3 Picklist Mode Picklist mode enables PA768 to decode only barcodes that are aligned under the laser crosshair or LED aiming dot. For picklist mode demonstration, please click on our Youtube channel for more information : https://www.youtube.com/watch?v=QjT2E6hxD_k... - Page 80 For more information about USS, please download the document from the below link: http://w3.tw.ute.com/pub/cs/manual/uss/USS-RA-1-MANUAL_en20210326.pdf © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 81: Enterprise Keyboard
© 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 82: Logger
No technical skills required. Simply use the Start-Stop buttons to start recording vital system and app logs as one snapshot or as a time-lapse, and then the logs can be automatically submitted to the unitech support team for analysis. - Page 83 3. Tap on settings to view more. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
-
Page 84: Software Update
Select the Apps to be updated, and click Update. © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 85: Software Update Settings
You can find the exported settings file in the Internal Storage: /Unitech/usus/usus_config.stxt © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners... -
Page 86: Stagego
StageGO helps IT admins to swiftly set up a device by just a few barcode scans. Features Swift and effortless device staging for Unitech Android Mobile Devices. Device staging becomes more accessible, time-efficient, and secure. Complete device control at your fingertips. - Page 87 PA768 User Manual EA520 User’s Manual © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
- Page 88 EA520 User’s Manual Step 3. Scan QRCode: © 2024 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd. All product and company names are trademarks, service marks, or registered trademarks of their respective owners...
