6.3 Power Supply Connector

Model No
PDT-NSU-7005-MP-I
Note: All Power Supplies should provide over-current and short-circuit protection, and should have
a capacity rating to meet the required output current for the device plus any PoE powered device
requirements.

6.4 PoE Compatibility

Model No
PDT-NSU-7005-MP-I
The PoE output for this model is compatible with PoE and PoE+ Standards, as can be seen in the
table above.

6.5 PoE Power Budget

Supply Voltage
Total PoE Budget
The PoE Power Budget is dependent upon the input supply voltage, as shown in the above table.
V-
GND
IEEE 802.3af
●
+12VDC
60W
V+
+12-48VDC
IEEE 802.3at
●
+24VDC
90W
Power Input
IEEE 802.3bt
+48VDC
120W
