- Page 1 User Manual...
- Page 2 The reproduction, even partially, of this document is forbidden. No part may be copied in any form, and it may not be used, edited nor transmitted by any electronic means (photocopy, photography, magnetic supports or other recording processes), without the written authorisation of Eversys S.A. All rights and particularly reproduction, translation, edition, distribution and also industrial property and recording are reserved.
-
Page 3: Table Of Contents
6. Troubleshooting ......................27 6.1. FAQs ........................27 6.1.1. Cups on the cup heater are not warm enough ..........27 7. Options .......................... 28 7.1. List of options for E'cup heater machines ............... 28 02.01.2023 Page 3 of 34 © Eversys S.A. - Page 4 8.4.1. Warning ....................33 8.4.2. Note ......................33 8.4.3. Notation ....................33 9. Appendix ........................34 9.1. Equipment list of cup heaters | cup warmers ............34 9.2. Spare parts ordering .................... 34 © Eversys S.A. Page 4 of 34 02.01.2023...
-
Page 5: For Your Safety
This machine complies with all applicable European Community Directives and associated harmonised standards. For more information refer to our Declaration of Conformity (scan the QR code below) or contact your service organisation. 02.01.2023 Page 5 of 34 © Eversys S.A. -
Page 6: General Safety Instructions
The cup warmer panel could reach 90 °C, contact may cause burns in less than a second. It is imperative to use only the products, accessories, spare parts and software specified in manuals (e.g. User Manual). © Eversys S.A. Page 6 of 34 02.01.2023... - Page 7 Eversys service organisations may only connect the machine to existing prepared connection points. Eversys appointed service organisations are neither authorised, nor responsible for carrying out any on-site installation work prior to connection. The requirement prior to initial commissioning checklist is available under the e'Support center (https://support.eversys.com/hc/en-us).
-
Page 8: Information For Disposal
Refer to method and frequency under Care (page 24). Only use original Eversys cleaning products. Use of products that are not explicitly recommended by Eversys could damage the machine or void warranty. It is forbidden to clean the machine with a water jet or a water spray. -
Page 9: Decommissioning And Disposal
1.7.1. Signs on cup heaters | cup warmers The following signs can be found on cup heaters. Associated warnings are explained in the table. 02.01.2023 Page 9 of 34 © Eversys S.A. - Page 10 (page 23) Burning - Danger HOT SURFACE Contact may cause burns Do not touch! Main switch Power ON Main switch Power ON Main switch Power OFF Protective earthing © Eversys S.A. Page 10 of 34 02.01.2023...
-
Page 11: Packaging Signs For Cup Heaters | Cup Warmers
Maximum and minimum humidity limit Maximum and minimum temperature limit Stacking limit by number Not to be vertically stacked higher than the specified number of items «n» Phytosanitary treatment of the pallet Serial Number 02.01.2023 Page 11 of 34 © Eversys S.A. -
Page 12: Description
For any further information, please consult your local distributor or the manufacturer. 2.1.1. Key features of cup heaters | cup warmers Model C'cup heater/Classic E'cup heater/Classic E'cup heater/ST Setup on the right or on the left side of the coffee machine... -
Page 13: Correspondence Table On Machine Types And Article Numbers Of Enigma And Shotmaster Accessories
E'choco/ST E'choco-2021 AE50000002 E'cup heater/ST E'cuph-2021 AE50000006 E'fridge/ST E'fridge-2021 AE50000004 2.1.4. Rating plate of E'cup heater machines The rating plate (type plate) is located on the back panel in the first level. 02.01.2023 Page 13 of 34 © Eversys S.A. - Page 14 (Commercial C 09/22 Manufacture Date (WW/YY) Eversys S.A. | Ecoparc de Daval A2 | 3960 Sierre | Switzerland Made in Switzerland Tel.: +41 (0)27 3052121 / www.eversys.com Please copy the following information from the identification label in the fields below:...
-
Page 15: Overview
Symbol Description Manufacturer's reference (order number) Serial Number Date of manufacture (week + year) Manufacturer EC (CE) Mark (European Union) CMIM Mark (Morocco) EAC Mark (Russia) UKCA Mark (United Kingdom) 2.2. Overview 02.01.2023 Page 15 of 34 © Eversys S.A. -
Page 16: Overview Of E'cup Heater Machines
2.2.1. Overview of E'cup heater machines Cup heater panel (up to 56 espresso cups) Cup heater drawers (up to 40 espresso cups per drawer) For more information, refer to Options (page 28). © Eversys S.A. Page 16 of 34 02.01.2023... -
Page 17: Access To The Main Switch On E'cup Heater Machines
Main power switch (see Switch on a machine (page 22)) 2.3. Technical data 2.3.1. General technical data of E'cup heater machines (E’cup heater - 1 module) (E’cup heater - 2 modules) (E’cup heater - 3 modules) 02.01.2023 Page 17 of 34 © Eversys S.A. -
Page 18: Electrical Data And Power Overview Of E'cup Heater Machines
Setup on the right or on the left side of the Enigma or the Shotmaster 2.3.2. Electrical data and power overview of E'cup heater machines The power cord must be in accordance with local regulations. Adjustment of the frequency is automatic. No action is required. © Eversys S.A. Page 18 of 34 02.01.2023... -
Page 19: Environmental Conditions For Cup Heaters | Cup Warmers
Operating temperature 10 to 32 °C Storage & transport temperature -10 to 50 °C Relative humidity (RH), no condensing (storage, transport and 5 to 80 % RH operating) Transient over-voltage Category II 02.01.2023 Page 19 of 34 © Eversys S.A. -
Page 20: Commissioning
3.2. Requirement prior to initial commissioning A few preparations are necessary before your service engineer can set up your machine. The following preparations must be carried out by a professionally qualified person. © Eversys S.A. Page 20 of 34 02.01.2023... -
Page 21: Common For All Machines
• 25 kg (C'choco, C'fridge beneath, E'choco/Classic, E'cup heater/Classic) • 30 kg (C'cup heater, E'choco/ST, E'cup heater/ST) Table height min. 800 mm (31.5 in) Separate electrical lines for each machine Electrical mains protected by RCD or RCCB 02.01.2023 Page 21 of 34 © Eversys S.A. -
Page 22: Operation
Switch on (page 22) at the main power switch. Fill the cups storing surface (page 23). Enjoy your drink! 4.2. Switch on a machine • Start the machine at the main power (1), switch to «1» or «I» (ON). © Eversys S.A. Page 22 of 34 02.01.2023... -
Page 23: Fill The Cups Storing Surface
Shut down the machine at the main power (1), switch to «0» (OFF). 4.5. End of the day guidelines Procedure Clean according to the cleaning plan (page 25). Switch off (page 23) at the main power switch. Have a nice evening ahead! 02.01.2023 Page 23 of 34 © Eversys S.A. -
Page 24: Care
If care and cleaning of the machine is not carried out properly, dispensing milk beverages will constitute a food hygiene hazard point. All automatic cleaning operations are logged. For more information on the cleaning intervals, see Periodic cleaning (page 24). 5.2. Periodic cleaning © Eversys S.A. Page 24 of 34 02.01.2023... -
Page 25: Cleaning Plan For Cup Heaters | Cup Warmers
Drawers and inside of the cup heater | cup warmer (page 26) Housing (page 26) Beneath the machine (page 26) 5.2.2. Overview of cleaning on E'cup heater machines C = Clean Weekly Or as required 5.3. Cleaning procedures (standard) 02.01.2023 Page 25 of 34 © Eversys S.A. -
Page 26: Clean The Drawers And The Inside Of The Cup Heater | Cup Warmer
Clean beneath the machine. The height available under the machine (h) is greater than 76 mm in compliance with the standards in force. Put the feet covers back to their original position (machine option). © Eversys S.A. Page 26 of 34 02.01.2023... -
Page 27: Troubleshooting
• The cup heater is not intended to keep cups warm in a cold air flow (e.g. near an open window or door). • Contact your service engineer to verify the heating panel settings. 02.01.2023 Page 27 of 34 © Eversys S.A. -
Page 28: Options
Enigma logo (page 28) Standard Shotmaster logo (page 28) Without logo (page 28) Standard 7.2. Logo option (Enigma, Shotmaster and without) 7.2.1. Classic line Without logo (standard) • For more information, contact your service organisation. © Eversys S.A. Page 28 of 34 02.01.2023... -
Page 29: Super Traditional Line
Options Shotmaster logo (machine option) • For more information, contact your service organisation. 7.2.2. Super Traditional line Enigma logo (standard) • For more information, contact your service organisation. 02.01.2023 Page 29 of 34 © Eversys S.A. - Page 30 Options Shotmaster logo (machine option) • For more information, contact your service organisation. © Eversys S.A. Page 30 of 34 02.01.2023...
-
Page 31: Warranty And Generalities
(whichever comes first) from the date of installation. Eversys will repair or replace at its discretion part or all of the product not conforming to this warranty. Eversys’ responsibility under this warranty is limited to the repair or replacement of defective parts and not to wear and tear parts and maintenance products. -
Page 32: Glossary
• Use contrary to the instructions given in this manual or according to information other than the manufacturer’s original tips. Each machine is tested by Eversys S.A. before shipping. 8.3. Glossary The following terms and acronyms are used in this manual. -
Page 33: Typographical Conventions
• Cross-references and links: this style is used as bold (page 33). • Software buttons: text in bold style is used (e.g. OK, Save, Rinse). • List of numbers: text linked to an illustration (1, 2, 3). 02.01.2023 Page 33 of 34 © Eversys S.A. -
Page 34: Appendix
Description Quantity C'cup heater | E'cup heater Quick start guide and Cleaning sheet (QRC) General Safety Instructions 9.2. Spare parts ordering Please contact your local service organisation or connect to the Webshop. © Eversys S.A. Page 34 of 34 02.01.2023...
