FITTING INSTRUCTIONS

Document Title:

FI-290

Application:

Ford Ranger MY22

Ford Everest MY22

Model Number:

StealthBar

SA290AA290 Standard / Non-Parking Sensor

SA290AA291 Winch / Non-Parking Sensor

SA292AA290 Standard / Parking Sensor

SA292AA291 Winch / Parking sensor

Fitting Time:

Minimum 4.5 Hours

Revision:

I (08 December 2022)

PROUDLY

AUSTRALIAN MADE

Congratulations on your purchase of a StealthBar.

Additional Kits:

-SA290CRK (Camera Housing/Radar Kit) 30 min.

-SA290RHK (Radar Housing Kit) 15 min.

-SA290FLK (Fog Light Kit) 30 min.

Warning:

•

Do not attach VFPS to the vehicle using anchorages not intended for this purpose (e.g.

engine mounting bolts).

•

Do not use this product for any vehicle make or model, other than those specified by the VFPS

manufacturer.

•

Do not remove the plaque or label from the VFPS (StealthBar).

•

Do not modify the structure of the VFPS in any way.

Note:

•

Left and Right hand sides of the vehicle and StealthBar are from the view of being in the

drivers seat looking forward.

•

Please take the time to read the instructions thoroughly before proceeding with fitment of the

StealthBar.

•

Ensure all components, as listed in the bill of materials on the back page, are received prior to

commencing the fitment. Please retain all hardware until fit-up is complete.

•

All wiring should be completed by a qualified auto electrician. SmartBar bears no

responsibility for any electrical failure caused by the incorrect fitment of the lamps.

•

Ensure these fitting instructions are passed onto the vehicle owner and/or operator.

•

We recommend the use of anti-seize on all threaded fittings.

CAUTION A torque specification is required for the bolts into the StealthBar nutserts.

THESE MUST NOT BE OVERTIGHTENED.

W. www.smartbar.com.au

E. info@smartbar.com.au

SRS

AIRBAG

4876.1

-SA290ALK (Aerial Mount Left Kit) 5 min.

-SA290ARK (Aerial Mount Right Kit) 5 min.

-SAHLJ1 (High Lift Jack Point) N/A

P. +61 8 8384 0292

ADR

- 48

Need help?

Do you have a question about the SA290AA290 and is the answer not in the manual?

Questions and answers

Summary of Contents for ARB SA290AA290

Page 1 Document Title: FI-290 Application: Ford Ranger MY22 Ford Everest MY22 Model Number: StealthBar SA290AA290 Standard / Non-Parking Sensor SA290AA291 Winch / Non-Parking Sensor SA292AA290 Standard / Parking Sensor SA292AA291 Winch / Parking sensor Fitting Time: Minimum 4.5 Hours Revision: I (08 December 2022)
Page 2 Tools Required Drill and Phillips Phillips Head Socket Drive Ring Spanner 16mm Small Flat Head Socket Extension Head Drill Bit Screw Driver Torque Wrench Rachet Spanner 16mm Screw Driver (20-80Nm) Rachet Spanner 18mm Tape Measure Socket 8, 10, 12, Masking 13mm Drill Bit Marker T20 &...
Page 3 Step 1: Vehicle Disassembly Note: Do not discard removed hardware and components until the installation is complete. Remove Scrivets shown to remove the top cover from the vehicle. Remove number plate and number plate retainer from the vehicle. Note: Keep the number plate in a safe and secure place for re-installation.
Page 4 Remove front skid pan by removing bolts shown. Everest Shown for reference Remove the top 2 bolts that secure the grille to the vehicle. Repeat on other side. RHS Shown Gently unclip and remove Grille from vehicle. Note: Set grille aside on a soft surface to avoid damage.
Page 5 Washer hose Coax camera cable Top of the grille shown Check if the scale on the trim template is correct. If not, contact your nearest ARB store. Cut the bumper trim template out. 1.10 Cover area with masking tape. Align 1.10...
Page 6 1.12 Remove the lower part of the trimmed 1.12 bumper from the vehicle. Note: Ensure that all wiring and hardware has been disconnected from the vehicle. 1.13 Label and remove parking sensor/fog 1.13 light harness from the vehicle. Note: Sensors must be labelled correctly to successfully re-install later.
Page 7 1.16 Apply pinch weld to bumper and flare. 1.16 Trim away excess pinch weld as shown. Note: Recomended to cut 2cm section on the back of the pinch weld, as shown. Repeat on right hand side. Outside of Pinch Bumper Inside edge of pinch weld. Weld Retaining LHS Shown barb on...
Page 8 1.20 Remove radar from bracket by gently 1.20 unclipping radar from ball point mounts as shown. DO NOT DAMAGE THE RADAR Note: Store radar in a safe and safe place for re-installation. 1.21 Remove from crash beam from the vehicle. 1.21 OE Bolts X6 1.22a Cut the OE radar bracket as shown.
Page 9 1.22c Cut the OE radar bracket off the crash 1.25 1.22c beam along the cut lines shown. Cut flushed to this edge Cut Line Behind crash beam 1.23 The cut radar bracket should now 1.23 appear as shown. Touch up the cut surface with rust preventative paint (not supplied). Put the cut bracket aside for re-installation in later steps.
Page 10 Ford Everest MY22 Only Before After 1.25b 1.25b Measure, mark and drill a hole in the lower slot of the intercooler cover as shown. ⌀ LHS Towpoint Shown 1.26 Cut Airdam as shown and repeat on 1.26 left hand side. Remove Cut Line RHS Shown...
Page 11 Underside LHS chassis shown If installing recovery point skip this step 1.30 and refer to step 2.5. 1.30 If not installing an ARB Recovery Point, OE Rubber Grommet remove original rubber grommets from the base of the intercooler. Repeat on the left hand side.
Page 12 Step 2: Bracket Installation Standard Kit (Non-Winch) 290BK Winch Kit 291BK Standard Kit Only. Leave all hardware loose until specified Chassis 290-CL M8X20 Bolt X5 Slide 290-CL over the chassis using the M8 Round Washer X5 hardware shown. Only finger tighten. Repeat on right hand side. M8 Lock Nut X2 LHS shown Winch Kit Only Chassis...
Page 13 NOTE: If not fitting to ARB recovery points, attach to OE tow points instead. M6x20 X2 M6 Washer M6 Lock Nut X2 ARB Recovery Points shown for reference only SmartBar - Fitting Instructions FI-290-I © Copyright W. www.smartbar.com.au E. info@smartbar.com.au P. +61 8 8384 0292 - 48...
Page 14 Winch Kit Only Slide the 290-OL into place. Using M8 Lock Nut X2 hardware shown, secure the 290-OL bracket to the chassis. 290-CL Repeat on the other side. Slide in Note: 290-OL and 290-OR are not mirrored 290-OL parts, locate L and R on brackets for correct side.
Page 15 2.11 Using hardware shown, install the 2.11 M10 Lock Nut X2 290-TL to 290-LL. Leave hardware loose. 290-TL Repeat on right hand side. 290-LL NOTE: Ensure bolt heads are facing down for tightening later. M10X30 Bolt X2 M10 Round Washer X2 LHS rear shown Standard Kit only.
Page 16 Winch Kit Only 2.15 Rotate winch handle to front of vehicle 2.15 Rotate winch handle to forward facing Warn Winch Handle position of the vehicle. winch Other winches NOTE: Other winches may have different gearbox rotation. Front of vehicle Always consult the winch supplier instruction manual for correct handle Warn winch shown rotation procedure.
Page 17 Winch Kit Only 2.19 2.19 Install 291-WB using hardware to the 291-WB 290-CL as shown. M12 WASHER X3 Repeat on right hand side. Tighten Bolts to 78 Nm. 2.20 Wire winch to the vehicle per winch supplier’s installation manual. M12X30 BOLT X3 M12 Lock Nut X3 Note: The winch wires must be secured to the vehicle in maximum of 250mm spacing...
Page 18 Step 3: Parking Sensor Installation Non-Parking Sensor, skip to Step 4: Wiring Parking Sensor vehicles only. Note: Ensure that Parking Sensors have been labelled correct as per table in step 1.13 Rest harness on the back of the bar in the correct orientation as shown.
Page 19 Parking Sensor Vehicles Only. On the inner 2 parking sensors, ensure that the extension connectors are protruding through the rear of the bar, this will allow enough slack to fit the parking sensors. Clip the parking sensors into the parking sensor bezels provided. Be sure to orientate the sensors as shown.
Page 20 Parking Sensor Vehicles Only. 3.8a Inner Parking Sensor 3.8a Clip the parking sensor and bezel into the bar. Ensure that sensors are orientated as shown. Dot facing outwards LHS shown 3.8b Left Middle parking sensor shown, 3.8b Middle Parking Sensor repeat on right hand side.
Page 21 Parking Sensor Vehicles Only 3.10 3.10 Seal the parking sensor access holes by installing a split grommet on all holes as shown. Split Grommet Repeat on right hand side. 35mm Split Grommet LHS shown 3.11 Secure the parking sensor wiring 3.11 harness to the bar by using the provided christmas tree clips.
Page 22 Wire the fog lights supplied in the bar approximately 100mm to the vehicle fog light loom. Stealth fog light connector LHS OE fog light wiring Repeat on the other side. 100mm Solder here Check ‘vehicle fog light wiring table’ for wire colours and functions to ensure the correct Image shown for reference only.
Page 23 Front Camera Vehicles Only. Disconnect washer hose from the camera. Note: The hose needs to be off the vehicle. Disconnect Disconnect the OE coax cable from the camera. Note: The wiring needs to be off the vehicle. Set aside the camera for later steps. Remove and discard 5.5 Remove the 90° elbow connector from the washer hose as shown. Remove OE Washer connector...
Page 24 Front Camera Vehicles Only. Apply Split tube to group hose and Washer hose and coax cable connnection from car cable as shown. Washer hose connector extendsion hose and cable covered in split tube Coax cable connector RHS shown Install the front camera using the brackets and hardware shown.
Page 25 5.12 Connect Coax cable and washer hose 5.12 to camera. Securing clip 5.13 Connect Coax cable to camera. 5.13 ARB Coax Cable 6821439 5.14 Reattach radar to the trimmed OE 5.14 bracket. Install the OE bracket to the 290-CM bracket Reattach Radar using the hardware shown.
Page 26 5.15 Install bracket hardware as shown. 5.15 Radar M6 Lock Nut X1 M6X20 Bolt X1 290-CM 5.16 Install radar assembly to the 290-AB 5.16 bracket using the hardware shown. M10X20 BOLT X2 Ring spanner recommended. M10 WASHER X2 Note: Camera shown is only present in 290-CM vehicles equipped with a camera.
Page 27 When installing spotlights without aerial 6.1b mount. (290-AML not required) 6.1b If required, Install spotlights to the 290-AB using the light hardware as shown. 290-AB NOTE: Light bars cannot be mounted to the 290-AB bracket Spotlight shown for reference only When installing an Aerial Mount with 6.1c spotlights...
Page 28 Standard Kit Only Install Grille Cover to the bar using the hardware shown. Bend Facing 290-GC down X8 Stitch Screw NOTE: Ensure the bend of 290-GC is facing down. Install 290-GL using hardware shown. Repeat on right hand side. 290-GL Gold Stitch Screws X3 LHS rear of bar shown Install 290-HL using hardware shown.
Page 29 Winch Kit Only FORD RANGER, XL, XLS MY22 GRILLE ONLY If installing a winch with a control box mounted to the winch. Mark and cut the grille as required to allow re-fitment of the grille to the vehicle. 6.8a Grille trim for Bushranger REVO and Warn EVO Trim Line 6.8b Grille trim for Warn ZEON Trim Line SmartBar - Fitting Instructions FI-290-I ©...
Page 30 Winch Kit Only FORD RANGER XLT, SPORT MY22 GRILLE ONLY If installing a winch with a control box mounted to the winch. Mark and cut the grille as required to allow re-fitment of the grille to the vehicle. 6.9a Grille trim for Bushranger REVO and Warn EVO Trim Line 6.9b Grille trim for Bushranger REVO and Warn EVO Trim Line SmartBar - Fitting Instructions FI-290-I ©...
Page 31 Winch Kit Only FORD RANGER WILDTRACK MY22 GRILLE ONLY 6.10 If installing a winch with a control box mounted to the winch. Mark and cut the grille as required to allow re-fitment of the grille to the vehicle. 6.10a Grille trim for Bushranger REVO and Warn EVO Trim Line 6.10b Grille trim for Warn ZEON Trim Line 350mm...
Page 32 Winch Kit Only FORD RANGER XL, XLT, EVEREST PLATINUM MY22 GRILLE ONLY 6.11 If installing a winch with a control box mounted to the winch. Mark and cut the grille as required to allow re-fitment of the grille to the vehicle. 6.11a Grille trim for Bushranger REVO and Warn EVO Trim Line 6.11b Grille trim for Warn ZEON...
Page 33 FORD EVEREST AMBIENTE, TREND, SPORT. 6.12b FORD RANGER WILDTRACK ONLY. 290-GB 6.12b Mount the cage nuts to the underside M6 CAGE NUT X2 of 290-GB. NOTE: Ensure the bend on 290-GB is facing downward. Bend facing downward 6.13 Install the 290-GB to the centre grille 6.13 In front of Radiator mount using the hardware shown.
Page 34 Step 7 : StealthBar Install Important: Before installing the bar • Use Anti Sieze on all bolts in the following steps. • A maximum torque specification of 28Nm is required for M10 Bolts and 55Nm for M12 bolts being installed into the StealthBar. THESE MUST NOT BE OVER TIGHTENED. Install X2 Bolts to temporarily hang the bar to the brackets for installation.
Page 35 Align the StealthBar so that it follows the wheel arch line and has 20mm gap between the bar and bumper. 20-25mm Check on both sides of the vehicle. LHS shown Ensure that the headlight and grille infill are aligned with the vehicle with an even gap on both sides of the vehicle. LHS shown Once bar is aligned, tighten StealthBar and bracket hardware to specified torque as...
Page 36 Reconnect the radar connector plug as shown. Reconnect 7.10 Place a level in front of the radar. 7.10 90 ±1 degrees Ensure that the radar is vertical. The front from level ground. face should be 90 degrees level to the ground +-1 deg.
Page 37 290-CH to the radar bracket. 290-CH M6 BOLT X4 ARB Recovery Point Install Only 7.15 7.15 If installing an ARB Recovery Point, cut the underwing as shown. Trim Line Cut and Remove LHS Underwing shown 7.16 Secure the underwing to the vehicle by 7.16...
Page 38 7.17 Mark a line on wheel arch liner from 7.17 the underwing as shown and cut 10mm Cut line on wheel arch liner 10mm above the marked line. above the marked line. Discard offcut. Repeat on the other side. Discard Mark back of undering on wheel arch liner. LHS shown 7.18 Cut wheel arch liner along line shown.
Page 39 7.21 Align the underwing and mount to the 7.21 bar using hardware shown. Tighten underwing bolts (from step 7.18) to 25 Nm. Repeat on right hand side. LHS shown Black Tek Screws X4 7.22 Install the 290-UC panel using the 7.22 290-UC hardware shown and leave loose.
Page 40 7.25 Re-connect the wiring connector at 7.25 the top of the grille & secure as shown FORD RANGER XL, XLS, XLT, SPORT 7.26a Ford Everest Platinum Shown FORD EVEREST PLATINUM GRILLE ONLY. 7.26a Rest the grille in place and align with the 290-GX.
Page 41 Step 8 : Number Plate Install Standard Kit Only Mount the license plate to the bar. Black Stitch Screw X4 NOTE: Ensure that it is aligned centrally and is level to the bar. Winch Kit Only 290-NL X2 M6 Poly Washer X2 Number plate hinge bracket, supplied with winch kit .
Page 42 Winch Kit Only 290-NB If you are fitting a full-sized plate, proceed to step 8.7 If you are fitting a slim line plate, use the laser cut grooves as a guide. Carefully cut the lower section of the pivot plate (290-NB) and discard. Cut here 8.6 Use a file to remove any sharp edges, NOTE: Use matte black enamel paint to touch up the cut surface to prevent rust.
Page 43 Fitted Product Checks Important Checks once the StealthBar is fitted. • Ensure all bolts are tensioned correctly • All wiring is clear of sharp edges or moving surfaces and is secured correctly. • Check operation of winch if fitted • Check all wiring and connections to turn signal lamps, parking sensors, camera washers and any other functioning components that may have been altered during the installation.
Page 44 BOXED BAR CONTENTS SA290BL290 - Standard Kit, Non-Parking Sensor Bar SA290BL291 - Winch Kit, Non-Parking Sensor Bar Code Description Code Description SA290BLASSY 290 StealthBar Assy (Non-PS) SA290BLASSY 290 StealthBar Assy (Non-PS) BP80714 290-GC (ABS COVER PLATE) SA290URBL 290-UR (Underwing Right) SA290URBL 290-UR (Underwing Right) SA290ULBL...
Page 45 SA290BLASSY - Non-Parking Sensor Bar Code Description MK51058 SA290 Moulded Bar MM81154 290-MC (Mesh) BP80727 Badge ARB 77x35mm Lensed B130H BP1279 Screw 10X1G Phil Self Tap BP38781 Screw Stitch 8GX15mm Eco Black 141-LI Packed By Date SA292BLASSY - Parking Sensor Bar...
Page 46 SA290BKA (Standard Kit) COMMON COMPONENTS Code Description MM81136 290-BR (BAR BRACKET RHS) MM81137 290-BL (BAR BRACKET LHS) 290-CT MM81138 290-CR (CHASSIS BRACKET RHS) MM81139 290-CL (CHASSIS BRACKET LHS) 190-ABS 290-CR 290-CL MM81140 290-CT (CRUSH TUBE) MM81141 290-LR (LOWER SIDE BRACKET RHS) MM81142 290-LL (LOWER SIDE BRACKET LHS) 291 -AB...
Page 47 SA290HWK HARDWARE KIT SA290HWK STANDARD HARDWARE KIT Code Description BP80720 290-WCL Textured Side BP80721 290-WCR BP1024 12 X 30 M88ZPB HEX CAD BOLT 6152066 12 X 50 G10.9 M88ZPB HEX CAD BOLT MM1244 12X40X40X5ZPG SQUARE WASHER BP1140 12MSW M12 ZINC PLT SPRING WASHER BP1017 M10 X 30 M88ZPB HEX CAD BOLT BP80496...
Page 48 SA291HWK HARDWARE KIT SA291HWK HARDWARE KIT Code Description BP80720 290-WCL Textured Side BP80721 290-WCR BP1024 12 X 30 M88ZPB HEX CAD BOLT 6152066 12 X 50 G10.9 M88ZPB HEX CAD BOLT BP1094 12MZPW M12 WASHERS MM1244 12X40X40X5ZPG SQUARE WASHER BP1140 12MSW M12 ZINC PLT SPRING WASHER BP80313 M12 FLANGE W/LOCK NUT...
