ENIGMA AIR ENCLOSURE
S
HOWER
IMPORTANT
DreamLine
reserves the right to alter, modify or redesign products at any time without prior notice.
®
For the latest up-to-date technical drawings, manuals, warranty information or additional details please refer
to your model's web page on DreamLine.com
Right - Hand return panel installation shown
For more information about DreamLine
ENIGMA AIR ENCLOSURE manual Ver 1 Rev 2 06/2017
E
I
NCLOSURE
Shower Doors, Tub Doors & Enclosures, please visit DreamLine.com
®
NSTALLATION
I
NSTRUCTIONS
MODEL #s
SHEN-6434480-##
SHEN-6434600-##
##=finish
07- Brushed Stainless Steel
08- Polished Stainless Steel
©2017 DreamLine. All Rights Reserved
Advertisement
Related Manuals for Dreamline Enigma SHEN-6434480
Summary of Contents for Dreamline Enigma SHEN-6434480
- Page 1 08- Polished Stainless Steel Right - Hand return panel installation shown For more information about DreamLine Shower Doors, Tub Doors & Enclosures, please visit DreamLine.com ® ©2017 DreamLine. All Rights Reserved ENIGMA AIR ENCLOSURE manual Ver 1 Rev 2 06/2017...
- Page 2 Right-Hand return panel Left-Hand return panel NOTE: This door is reversible for right or left-hand installation. The right-hand return panel installation is shown as an example throughout this manual. For the left-hand return panel installation, simply begin on the opposite wall and reverse the orientation of the steps shown. ENIGMA AIR ENCLOSURE manual Ver 1 Rev 2 06/2017...
- Page 3 This model is treated with DreamLine’s exclusive ClearMax Glass technology. This is a specially formulated coating that prevents the build up of soap and water spots. Install the surface with the ClearMax label towards the inside of the shower. Please note that depending on the model, the glass may be coated on either one or both surfaces.
- Page 4 Reinforcement for Enigma Series Heavy Glass frameless sliding shower door Install studs OR install 2”x 6” wood blocking between the studs where the Guide Rail Brackets will attach to the wall ” 2 ” S t u ” 2 ” measured from threshold* (see list below)
- Page 5 Please note that DreamLine will not replace any damaged products or missing parts free of ® charge after 3 business days or if the product has been installed. Contact DreamLine if you have any ® questions, and please provide an order number, job name or other proof of purchase to help us identify your original order.
-
Page 6: Tools Required
Before discarding the carton, check for small hardware bags that may have fallen to the bottom of the box. If any parts are damaged or missing, please contact DreamLine for replacement. The shipping boxes may contain extra parts not used in ®... -
Page 7: Parts List-A
Detailed Diagram of Shower Door components The glass surface with the ClearMax™ label must be installed facing the inside of the shower Parts List-A Part# Item Part# Item U-channel Guide Block 2PCS Stationary Glass Anti-water side strip Door Glass Bumper seal strip Guide Rail Handle 1set... -
Page 8: Parts List-B
Detailed Diagram of Return Panel components The glass surface with the ClearMax™ label must be installed facing the inside of the shower Parts List-B Part# Item Part# Item U-channel Stationary Glass Connector Ø5/16"(8mm) plastic wall anchor Bottom Bracket ST4.2×40 Countersunk screw ST4.2×55 Truss Head screw 4PCS Return Panel Glass... - Page 9 SHOWER ENCLOSURE PLAN Overall outside dimensions of the installed enclosure nished wall 34-3/4” 2-1/4” minimum threshold required nished wall 44-3/8”” min. to 48-3/8” max* (SHEN-6434480) *measured from the finished wall to the outside surface of the return panel glass nished wall 34-3/4”...
-
Page 10: Installation Steps
Installation steps Check both of the finished walls for plumb and the threshold for level. Check your threshold against the minimum threshold requirement of 2-1/4” for this unit. Compare the overall (outside) dimensions of the enclosure against the threshold to ensure that it will fit. (Fig 1) NOTE: This model does not allow for out-of-plumb adjustment. - Page 11 Align the outside edge of the U-Channel (#01) to the inside of the mark from the previous step on the return panel side of the unit. Level the U-Channel (#01) vertically (plumb), mark the position of the U-Channel (#01) on the wall, and mark the four holes for drilling through the pre-drilled holes in the u-channel.
- Page 12 Attach the Stationary Glass Connector (#23) to the top of the Return Panel Glass (#22). Attach the Bottom Bracket (#24) to the bottom of the Return Panel Glass (#22). Use the supplied gaskets to protect the glass. (Fig 5) outside Fig 5 Place the Return Panel Glass (#22) onto the pre-installed shower base or threshold.
- Page 13 Outline the position of the Bottom Bracket (#24) on the shower base or threshold. (Fig 7) inside Fig 7 Carefully slide the Return Panel Glass (#22) out of the U-channel and set it aside. Remove the Bottom Bracket (#24) from the Return Panel Glass (#22). (Fig 8 and Fig 9) Fig 8 ENIGMA AIR ENCLOSURE manual Ver 1 Rev 2 06/2017...
- Page 14 Replace the bottom bracket base back to its marked position and then mark the drilling hole on the threshold. Drill a hole in the shower base or threshold using: ◾ Ø1/8” drill bit for an acrylic base or ◾ Ø5/16” drill bit for an anchor for a tile threshold. Mount the Bottom Bracket (#24) to the threshold using the Truss Head Screw ST4.2×55 (#25).
- Page 15 Place the Return Panel Glass (#22) back into the U-channel (#01) and assemble the Bottom Bracket (#24) to the Return Panel Glass (#22). (Fig 11) outside Fig 11 Measure the distance from the finished wall to the inside surface of the installed Return Panel Glass (#22) (measure to the surface of the glass, not to the surface of the installed bracket).
- Page 16 Using a Chop-saw or a Hack-saw, cut the Guide Finished opening (L) - 1” = finished cut length Rail (#04) to fit the finished opening. Measure the finished opening width at the position Guide Rail with the Guide Rail of the Guide Rail (#04) for the model height: brackets attached The Guide Rail (#04) is 1“...
- Page 17 Drill the holes in the wall using a Ø5/16” drill bit and insert the Ø5/16“ Plastic Wall Anchors (#16) into the holes. Apply silicone to the back of the channel, screws and screw holes. Mount the U-channel (#01) to the wall using the Countersunk Screw ST4.2×40 (#17). (Fig 15) Ø5/16"...
- Page 18 Hold the Guide Rail Bracket (#06) in the marked position and using a center punch or small pencil, mark the wall through the hole for drilling in the Guide Rail Bracket (#06). (Fig 17) Note: Check the threshold for level. If the threshold rises or falls more than 1/16”...
- Page 19 Insert the Stationary Glass (#02) into the installed U-Channel (#01). Use Caution not to bang the glass into the U-channel or threshold. (Fig 19) Fig 19 Make sure the Stationary Glass (#02) is parallel to the front edge of the threshold and mark it. Slide the Guide Block (#12) into the notch of the Stationary Glass (#02).
- Page 20 Remove the Stationary Glass (#02) from the U-Channel (#01) and carefully set it aside. (Fig 21) Fig 21 To install the Guide Block (#12): loosen the set screw on the side and remove the Guide block face plate (Fig. 22.1). Apply silicone to the underside of the Guide Block (#12) and screw the Guide Block (#12) to the threshold as described below: *NOTE: ◾For installation into an acrylic threshold:...
- Page 21 TIP: Bring the door glass into the shower before permanently installing the stationary panel glass and guide rail. After the Stationary Glass (#02) and Guide Rail (#04) are installed, it may not be possible to easily get the door glass into the shower. Always use padding to protect the glass and shower surfaces.
- Page 22 Align the panel side Guide Rail (#04) with the installed Guide Rail Wall Bracket (#6b). Slide the Guide Rail Bracket (#6a) over the Guide Rail Wall Bracket (#6b) and tighten the set screws. (Fig 25) NOTE: Be careful not to scratch the guide rail while sliding the brackets.
- Page 23 Level the Guide Rail (#04) across the opening. Use the set screws on the Guide Rail Bracket (#06) to adjust the level of the Guide Rail (#04) as necessary. (Fig 27) Fig 27 ENIGMA AIR ENCLOSURE manual Ver 1 Rev 2 06/2017...
- Page 24 Measure the distance from the edge of the Guide Block (#12) to the wall. This distance will be (L). Cut the Anti-Splash Guard (#11) to the size of: (L). (Fig 28) Fig 28 Apply silicone to the bottom of the Anti-Splash Guard (#11).
- Page 25 Attach the Rollers (#08) to the Door Glass (#03) with the wheels facing out. NOTE: The roller hardware disk can be rotated to tilt the door glass slightly to create a tight seal with the hold the disk in place with a small return panel glass.
- Page 26 Install the Roller Guards (#09) onto the Door Glass (#03) so that the longer section extends beneath the Guide Rail (#04). Use a small allen wrench to hold the shorter inside part of the roller guard and rotate the larger section so that there is approximately 1/16” of clearance between the Roller Guards (#09) and the Guide Rail (#04).
- Page 27 To position the Stoppers (#05), remove the set screws from the Stoppers (#05) and apply Thread Lock Adhesive (#20) to the threads. Re-insert the set Stopper screws into the Stoppers (#09) and screw them tightly to the Guide Rail (#04). (Fig 34) NOTE: The Stoppers (#05) must be positioned correctly to prevent...
- Page 28 NOTE: To maximize the life of your door, it is important to regularly inspect the glass and other hardware for misalignment, proper attachment, and/or damage. Contact DreamLine with any questions or concerns. ®...
- Page 29 TEL: 866-731-2244 FAX: 866-857-3638 DREAMLINE.COM For more information on DreamLine Shower Doors and Enclosures please visit DreamLine.com ® ©2017 DreamLine. All Rights Reserved...
