Dreamline PRISM SHEN-2134340 Series Installation Instructions Manual

Shower enclosure

Advertisement

Quick Links

S
HOWER
PLEASE REVIEW THIS ENTIRE MANUAL PRIOR TO INSTALLATION
Left-hand door
installation shown
IMPORTANT!
DreamLine
reserves the right to alter, modify or redesign products at any time without prior notice for the
®
purpose of product improvement and customer experience. Please refer to the model's web page on
DreamLine.com for the latest technical drawings, installation manuals, warranty information or additional
product details.
Do Not Return Product to the Store. Contact DreamLine® with any questions
Please contact DreamLine Customer Support
See DreamLine.com for hours of operation
Prism neo angle shower enclosure manual Ver 2 012025
PRISM
E
NCLOSURE
I
NSTALLATION
I
NSTRUCTIONS
Model #s
SHEN-2134340-##
SHEN-2136360-##
SHEN-2138380-##
SHEN-2140400-##
## = Finish
01= Chrome
04= Brushed Nickel
06=Oil Rubbed Bronze
09=Matte Black
1-866-731-2244
© 2025 DreamLine® All Rights Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRISM SHEN-2134340 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Dreamline PRISM SHEN-2134340 Series

  • Page 1 ® purpose of product improvement and customer experience. Please refer to the model’s web page on DreamLine.com for the latest technical drawings, installation manuals, warranty information or additional product details. Do Not Return Product to the Store. Contact DreamLine® with any questions Please contact DreamLine Customer Support See DreamLine.com for hours of operation...
  • Page 2 For best results, squeegee the glass after each use and dry with a soft cloth. Record the following purchase information for your records or in the event you need to contact DreamLine ® Purchase Order...
  • Page 3: Table Of Contents

    Table of Contents Section Title Page # ® ClearMax Coating Information — Dimensions Guide Warnings and General Preparation Model Specific Preparation Tools Detailed Diagram of Components Parts List Installation Steps 9-18 Product Maintenance Troubleshooting Factory Parts Information Symbol Legend CORRECT - Average Installation Time TIP - for ease of installation.
  • Page 4: Dimensions Guide

    Checking Dimensions NOTE: This enclosure must be installed at the model size dimensions shown in Table A on page 2 and page 9. Be sure that the correct size shower enclosure has been ordered to fit the finished dimensions of the base or threshold where the enclosure will be installed.
  • Page 5: Warnings And General Preparation

    IMPORTANT GENERAL PREPARATION • DreamLine® reserves the right to alter, modify or redesign products any time without • After opening all boxes and packages, read this introduction carefully. Check that all the prior notice for product improvement and customer experience. Please refer to the items are included in the package by marking off the components on the “Detailed...
  • Page 6: Model Specific Preparation

    Model Specific Preparation REQUIRED: ±0.0 ±0.0 ±0.0 ±0.0 1-3/8” minimum threshold ±0.0 ±0.0 ±0.0 ±0.0 DO NOT install the towel bar handle onto the door glass until instructed. DO NOT lift the glass using the towel bar handle. This could result in damage to the glass and/or serious personal injury.
  • Page 7: Tools

    Diagram on page 6 and packing list in this manual as a reference. Before discarding the carton, check for small hardware bags that may have fallen to the bottom of the box. If any NOTE parts are damaged or missing, please contact DreamLine for replacement. The shipping ®...
  • Page 8: Detailed Diagram Of Components

    Detailed Diagram of Prism Neo-Angle Enclosure Components PANEL DOOR © 2025 DreamLine® All Rights Reserved...
  • Page 9: Parts List

    Parts List BOTTOM 1 pair 1 pair Prism neo angle shower enclosure manual Ver 2 012025...
  • Page 10 Parts List Prism neo angle shower enclosure manual Ver 2 012025...
  • Page 11: Installation Steps

    Installation steps Apply clear 100% silicone into the Glass Profiles (#01) and firmly attach the Glass Profiles (#01) to the correct edge (see note) of the Panel Glass (#03). (Fig 1a) Carefully set these assemblies aside when you are done. Fig 1a The holes (for the pivot bars) should be on NOTE...
  • Page 12 Mark the wall at the threshold according to the dimensions for the model size shown in Table 1 below. Place the Wall Profiles (#02) against the walls and aligned with the new reference marks on the threshold. Use a level to plumb each wall profile. (Table 1, Fig 2a and Fig 2b) inside inside The inside edge of each wall...
  • Page 13 Make sure each Wall Profile (#02) is plumb. Mark the holes for drilling on the wall through the predrilled holes in the Wall Profile (#02). Drill the holes in the wall at each position you have marked. Run a bead of waterproof silicone along the back of the Wall Profiles (#02) and around the holes in the wall.
  • Page 14 For best results and ease of installation, be sure the silicone used to install the Panel Glass (#03) into the Glass Profiles (#01) has had time to set/cure before handling. Insert each assembled Panel Glass (#03) and Glass Profile (#01) into the installed Wall Profiles (#03) and check the panels for plumb.
  • Page 15 pivot holes Examine the Pivot Bars (#05) and notice that there are holes for the top and bottom pivot assemblies on one end. Attach the top and bottom Pivot Bars (#05) (with the pivot holes on the correct side for the swing of the door) through the holes in the Panel Glass (#03).
  • Page 16 Before installing the door glass, attach the longer Magnetic Strike Vinyl (#12) to the strike edge of the Panel Glass (#03) (the panel that the door will close against) to protect the edge of the door glass from making contact with the panel glass during installation. (See Step 8, Fig 8.4) The Pivot Assemblies (#07) will come with a total of 4 vinyl gaskets per assembly.
  • Page 17 Make any final adjustments using the adjustable wall profiles so that the door opening is square. (Fig 7a) Fig 7a Drill through the predrilled holes in the Wall Profiles (#02) into the first layer of the Glass Profiles (#01) using an Ø1/8” drill bit. Use the Pan Head Screws ST4.2×10 (#10) and washers to secure the Glass Profiles (#01) inside the Wall Profiles (#02).
  • Page 18 inside Push the Hinge-Side Vinyl Seal (#14) onto the pivot edge of the Door Glass (#04) with the soft fin facing inside of the shower so door that it overlaps the Panel Glass (#03) when the door is closed. outside Fig 8.1 outside Cut the Sweep Vinyl Seal (#13) to fit from the bottom pivot to...
  • Page 19 Install the Handle (#06) onto the outside of the Door Glass (#04). Make sure to place a gasket on each side of the glass and inside of each hole in the glass to avoid any glass-to-metal contact. (Fig 9) knob NOTE Put the knob on the magnet/strike side of the door.
  • Page 20 Apply a good quality mildew-resistant silicone along the interior edges of the Panel Glass (#03), Wall Profiles (#02) and bottom Pivot Bar (#05) to seal against the walls and threshold. (Fig 10) Allow a minimum of 24 hours for the silicone to cure before using the shower Fig 10 Tools Needed...
  • Page 21: Product Maintenance

    To maximize the life of your door, it is important to regularly inspect NOTE the glass and other hardware for misalignment, proper attachment, and/or damage. Contact DreamLine with any questions or concerns. ® Prism Maintenance Checklist ◻...
  • Page 22: Troubleshooting

    Suggested Solution •Check all shipping/packaging material for missing parts/components. Missing Parts •If not found, contact DreamLine Customer Support [1-866-731-2244] to order factory part replacement. •Confirm bottom edge of Panel Glass and bottom Pivot Bar are flush on the threshold and confirm wall profiles are flush against the walls.
  • Page 23: Factory Parts Information

    BOLD digit indicates finish color: 1 = Chrome 4 = Brushed Nickel 6 = Oil Rubbed Bronze 9 = Matte Black Contact Support@DreamLine.com for Part replacement, installation assistance or additional information. Complete Warranty information is available on DreamLine.com. © 2025 DreamLine® All Rights Reserved...
  • Page 24 NOTES Prism neo angle shower enclosure manual Ver 2 012025...
  • Page 25 NOTES Prism neo angle shower enclosure manual Ver 2 012025...
  • Page 26 TEL: 866-731-2244 FAX: 866-857-3638 DREAMLINE.COM For more information on DreamLine Shower Doors and Enclosures please visit DreamLine.com ® © 2025 DreamLine® All Rights Reserved...
