STEP 1:

Tub Backwall Installation Instructions

STEP 2:

Tub Door Installation Instructions

For more information about DreamLine

INFINITY-Z TUB DOOR & BACKWALL

& B

ACKWALL

Shower Doors, Tub Doors & Enclosures, please visit DreamLine.com

NSTALLATION

NSTRUCTIONS

Table of Contents

Need help?

Do you have a question about the INFINITY-Z SHDR-0960580 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Dreamline INFINITY-Z SHDR-0960580 Series

Page 1 DreamLine.com STEP 1: Tub Backwall Installation Instructions STEP 2: Tub Door Installation Instructions For more information about DreamLine Shower Doors, Tub Doors & Enclosures, please visit DreamLine.com ® ©2017 DreamLine. All Rights Reserved INFINITY-Z TUB DOOR & BACKWALL...
Page 2 QWALL TUB CRYLIC NSTALLATION NSTRUCTIONS IMPORTANT DreamLine reserves the right to alter, modify or redesign products at any time without prior notice. For the latest up-to-date technical drawings, manuals or any other details please refer to the support.BathAuthority.com web page.
Page 3: Tools Required
2. Please note that you should consult your local building codes with questions on installation compliance standards. Building and plumbing codes may vary by location, and DreamLine is not responsible for code compliance standards for your project. 3. This acrylic wall system is specially designed to be installed over any solid surface. If you are installing the acrylic walls over the existing tiles, remove all loose tiles before the installation.
Page 4 Before discarding the carton, check for small hardware bags that tend to fall to the bottom of the box. If any parts are damaged or missing, please contact DreamLine for replacement.
Page 5 Back Panel Installation Instruction 1. Measure the distance of the back wall of the tub (corner to corner) The distance is “W” See Fig. 1 for details. 2. Divide the W measurement by 2 (W/2). Place a mark on the back wall and draw a vertical line from top to bottom.
Page 6 3. Measure the side walls from the corner to the front point where the Side panel (01) is going to end. This distance is “D”. See Fig. 3 for details. D - 1” 1” 4. Verify on which side of your tub wall the fixtures will be installed.
Page 7 Attach the Center cover (05) vertically at the center point along the line and mark the Ø5/16” drilling holes through predrilled holes on the Center cover. Drill the holes using Ø5/16” drill bit and insert the Wall Anchors (06). See Fig. 6 and Fig. 7 for details. Rev 1.1...
Page 8 6. Attach the Corner cover (04) to the corner of the wall and mark drilling holes through the predrilled holes on the Corner cover. Drill the holes using Ø5/16” drill bit and insert the Wall Ø5/16” Anchors (06). See Fig. 8 and Fig. 9 for details Rev 1.1...
Page 9 7. Determine the position of both Back panels (02). W/2-1” NOTE: a) Narrow side of the Back panel W/2-1” cannot be trimmed and should face the center of the Back wall. b) Wide side of the Back panel can be trimmed to the size of the wall and should face the corner.
Page 10 8. Place the Back panel (02) on a flat piece of plywood or a particle board. Cut the side end of the Back panel by making a few deep scratches with a sharp industrial knife using a T-Square tool or a handheld jig saw.
Page 11 9. Mount the Center cover (05) to the center of the back wall using Countersunk screws ST4.2×30 (07). Do not tighten the screws. Leave the Center cover loose on the wall. See Fig. 13 for details. . 13 10. Apply the sealant to the back of the left Back panel (02).
Page 12 11. Slide the right edge of the left Back panel (02) all the way behind the Center cover (05) and push the Back panel against the wall. You can adjust the position of the Back panel before the sealant sets. Apply equal pressure to the whole surface of the Back panel from top to bottom.
Page 13 13. Align both Back panels at the top and tighten the screws on the Center cover (05) to secure this assembly in place. See Fig. 17 and Fig. 18 for details. . 17 . 18 Rev 1.1...
Page 14 14. Determine the position of both Side panels (01). D -1” D -1” NOTE: a) Narrow side of the Side panel cannot be trimmed and should face the corner of the side wall. b) Wide side of the Side panel can be trimmed size your...
Page 15 D -1” D -1” . 21 16. Place the marks on the Side panel (01) which is going to the side wall with the fixtures according to the taken measurements in Fig. 4. Drill the holes in the Side panel. Mind using the proper diameter saw bit or a handheld jig saw.
Page 16 . 23 17. Apply the sealant to the back surface of the Side panel (01). Apply the sealant around the drilled holes and to the whole back side of the Side panel. See Fig. 24 for details. . 24 Rev 1.1...
Page 17 18. Slide the edge of the Side panel (01) behind the Corner cover (04) and push the Side panel against the wall. Align the top of the Side panel with the Back panel before sealant sets. Apply equal pressure to the whole surface of the Side panel from top to bottom.
Page 18 19. Apply the sealant to the back surface of the Side panel (01) for another side wall installation. See Fig. 27 for details. . 27 20. Repeat Step 18 to install the second Side panel. See Fig. 28 and Fig. 29 for details.
Page 19 . 29 21. Fasten tight the Corner covers (04) and the Center cover (05) to secure the Side panels (01) and the Back panels (02) in place. See Fig. 28 for details. . 28 Rev 1.1...
Page 20 22. Use decorative plugs to cover the screw holes in the Corner covers (04) and the Center cover (05). See Fig. 29 for details. . 29 23. Apply caulk along the top edge of panels along connection of the bottom edges of the panels with the tub.
Page 21 Tub Glass Shelves Installation Instruction 24. Find the desirable height for the Glass shelves (09) and mark the locations on the wall. NOTE: The Glass shelves can be installed either two in one corner, or one in each. See Fig. 31 for details. .
Page 22 10. Mount the Glass brackets (10) to the wall using the Countersunk screws ST4.2×30. NOTE: padded set screw of the Glass bracket should be facing down. Slide the upper Glass shelf (09) into the Glass brackets and tighten the set screws at the bottom of the brackets. Then slide the bottom Glass shelf in place.
Page 23: Product Maintenance
Product maintenance To insure long lasting life for your acrylic back walls, wipe them off after each use with a soft cloth. To clean the acrylic back walls use non-abrasive sprays or cream based cleaners. Never use abrasive cleansers, metal brushes or scrapers that could scratch or dull the surface. Acrylic cleaning procedure: Acrylic should be cleaned with warm water and a clean, nonabrasive cloth.
Page 24 SHOWER CABINS (JETTED & STEAM) DreamLine™ warrants glass, acrylic and finish to be free from defects in workmanship for a period of five (5) years from initial date of purchase by the owner/end-user, contractor or builder from an authorized dealer; and plumbing, electrical and steam generator components for a period of one (1) year from the initial date of purchase by the owner/end-user, contractor or builder from an authorized dealer.
Page 25 TEL: 866-731-8378 – 215-957-1411 FAX: 866-227-9245 – 215-893-1780 WWW. UTHORITY.COM For more information on DreamLine Tub Back Wall please visit www.BathAuthority.com Rev 1.1...
Page 26 SHDR-0960580-## 01-Chrome SHDR-0948720-## 04-Brushed Nickel SHDR-0960720-## 06-Oil Rubbed Bronze SHDR-0954720-## FR-Frosted Glass SHDR-0954720-##-FR For more information about DreamLine Shower Doors, Tub Doors & Enclosures, please visit DreamLine.com ® INFINITY-Z manual Ver 4 Rev 5 06/2017 ©2017 DreamLine. All Rights Reserved...
Page 27: Table Of Contents
Table of Contents Page # Section title Preparation Tools Parts List Installation Steps 6-13 Wheel Assemblies Vinyl Seals Product maintenance INFINITY-Z manual Ver 4 Rev 5 06/2017 ©2017 DreamLine. All Rights Reserved...
Page 28: Preparation
® purchase to help identify the original order. 2. Please note that you should consult your local building codes with questions on installation compliance standards. Building and plumbing codes may vary by location, and DreamLine is not ® responsible for code compliance standards for your project and will not accept any returns.
Page 29: Tools
Before discarding the carton, check for small hardware bags that may have fallen to the bottom of the box. If any parts are damaged or missing, please contact DreamLine for replacement. The shipping boxes may contain extra parts not used in ®...
Page 30 Detailed Diagram of shower door components INFINITY-Z manual Ver 4 Rev 5 06/2017...
Page 31: Parts List
Parts List DESCRIPTION PART# DESCRIPTION PART# 2pcs 8pcs Glass profile Round head screw ST4.2x25 2pcs 4pcs Wall profile Round head screw ST4.2x10 2pcs 2pcs Guide rail (top and bottom) Flat head screw ST4.2x16 4pcs Glass door Decorative cover (with washer) 8pcs Stationary glass Wall anchor...
Page 32: Installation Steps
Installation steps Measure the distance between the two finished walls at the top (at model height: 58” or 72”), middle and bottom. The wall profiles will adjust for out-of-plumb conditions, so use the smallest measurement as the “finished opening” dimension to determine the finished cut length in Step #2.
Page 33 After the Top and Bottom Guide Rails (#03) have been cut, you will need to re-install the 3-1/8" roller stopper on each Top and Bottom Guide Rails (#03) on the end that has been cut off (the door end). Remove the existing stopper. Mark the drilling hole at the distance of 3-1/8”...
Page 34 Slide the Stationary Glass (#05) fully into the groove of the Glass Profile (#01), and then secure the Glass Holder (#16) to the Bottom Guide Rail (#03) with the Flat Head Screw ST4.2x16 (#12). (Fig 6) NOTE: Use caution when installing the stationary glass into the frame to prevent damage to the edges of the glass.
Page 35 Slide the Wall Profiles (#02) all the way onto the Glass Profiles (#01) on both sides. Make sure the flange of the wall profile faces inside the shower. (Fig 8) Inside Fig 8 Move the assembled frame into the designated position on the shower base*, bathtub or threshold (depending on your installation), and push the Wall Profiles (#02) tight to the walls to compensate for any...
Page 36 Use a helper to hold the assembly in position and mark the drill holes on the wall through the holes on the flange of the Wall Profiles (#02). Gently set the assembled unit aside; drill the holes using a Ø5/16” drill bit and insert the Wall Anchors (#14).
Page 37: Wheel Assemblies
Fasten the top and the bottom Wheel Assemblies (#17) to the Door Glass (#04). The top wheels can adjust the door level using the adjustable bolt and lock nut. The bottom wheel has a press button to fix the wheel onto the Bottom Guide Rail (#03). The wheels must face towards the outside of the shower.
Page 38 Install the Handle (#06) to the Door Glass (#04). Press the Anti-Water Strips (#07) onto the vertical edges of the Stationary Glass (#05) and both vertical edges of the Door Glass (#04). Insert the Seal Gasket (#15) into the Glass Profile (#01) starting from the bottom (Fig.
Page 39 Apply good quality mildew-resistant silicone along the profiles and guide rails; on the seams between the bottom guide rail and the profiles as well as along the shower base or threshold. Allow 24 hours for the silicone to cure before using the shower. (Fig 16) Hours Waterproof silicone...
Page 40: Vinyl Seals
NOTE: To maximize the life of your door, it is important to regularly inspect the glass and all hardware for misalignment, proper attachment, and/or damage. Contact DreamLine with any questions or concerns. ® DreamLine shower doors and enclosures are designed not to leak when ®...
