Dreamline Aqua Fold DLT-1132320 Installation Instructions Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

HOWER

PLEASE REVIEW THIS ENTIRE MANUAL PRIOR TO INSTALLATION

IMPORTANT!

DreamLine

reserves the right to alter, modify or redesign products at any time without prior notice for the

purpose of product improvement and customer experience. Please refer to the model's web page on

DreamLine.com for the latest technical drawings, installation manuals, warranty information or additional

product details.

STEP 1:

Shower Base Installation Instructions

STEP 2:

Shower Backwall Installation Instructions

STEP 3:

Shower Door Installation Instructions

Do Not Return Product to the Store. Contact DreamLine® with any questions

Please contact DreamLine Customer Support

See DreamLine.com for hours of operation

AQUA FOLD Shower Door, Base & Backwall Manual Ver 2 02/2023

AQUA FOLD

, B

OOR

ASE AND

ACKWALL

NSTALLATION

NSTRUCTIONS

Left hand door installation shown

1-866-731-2244

Table of Contents

Need help?

Do you have a question about the Aqua Fold DLT-1132320 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dreamline Aqua Fold DLT-1132320

Page 1 ® purpose of product improvement and customer experience. Please refer to the model’s web page on DreamLine.com for the latest technical drawings, installation manuals, warranty information or additional product details. Left hand door installation shown...
Page 2 NSTRUCTIONS IMPORTANT DreamLine® reserves the right to alter, modify or redesign products at any time without prior notice for the purpose of product improvement and customer experience. Please refer to the model’s web page on DreamLine.com for the latest technical drawings, installation manuals, warranty information or additional product details.
Page 3 3. Shower bases must be installed by a licensed plumber. Please note that you should consult your local building codes with questions on installation compliance standards. Building and plumbing codes may vary by location and DreamLine ® is not responsible for code compliance standards for your project.
Page 6 ©2022 DreamLine. All Rights Reserved SINGLE THRESHOLD SHOWER BASE Center Drain Configuration MODEL SPECIFICATION D (in) W (in) D1 (in) W1 (in) DLT-1132320 32"× 32" 32" 32" 15" 16" DLT-1136360 36"× 36" 36" 36" 15" 18" DLT-1132420 32” x 42”...
Page 7 ©2022 DreamLine. All Rights Reserved SINGLE THRESHOLD SHOWER BASE Left-Hand Drain Configuration MODEL SPECIFICATION D (in) W (in) D1 (in) W1 (in) DLT-1130601 30"×60" 30" 60" 15" 12" DLT-1132601 32"×60" 32" 60" 15" 12" DLT-1134601 34"×60" 34" 60" 17" 12"...
Page 8 ©2022 DreamLine. All Rights Reserved SINGLE THRESHOLD SHOWER BASE Right-Hand Drain Configuration MODEL SPECIFICATION D (in) W (in) D1 (in) W1 (in) DLT-1130602 30"×60" 30" 60" 15" 12" DLT-1132602 32"×60" 32" 60" 15" 12" DLT-1134602 34"×60" 34" 60" 17" 12"...
Page 9 ©2022 DreamLine. All Rights Reserved NEO ANGLE SHOWER BASE MODEL SPECIFICATION W (in) A (in) B (in) C (in) DLT-2036360 36"×36" 36" 18 5/16" 25" 12" DLT-2038380 38"×38" 38" 20 5/16" 25" 12" DLT-2040400 40"×40" 40" 22 5/16" 25" 14 3/8"...
Page 10 ©2022 DreamLine. All Rights Reserved QUARTER ROUND SHOWER BASE MODEL SPECIFICATION W (in) C (in) R (in) DLT-7033330 33"×33" 33" 12" 21 5/8" DLT-7036360 36"×36" 36" 12" 21 5/8" DLT-7038380 38"×38" 38" 12" 21 5/8" SLIMLINE SHOWER BASE manual Ver 5 Rev 9b 08/2022...
Page 11 ©2022 DreamLine. All Rights Reserved DOUBLE THRESHOLD SHOWER BASE Corner Drain Configuration MODEL SPECIFICATION W (in) C (in) DLT-1032320 32"×32" 32" 12" DLT-1036360 36"×36" 36" 12" DLT-1042420 42” x 42” 42” 12” SLIMLINE SHOWER BASE manual Ver 5 Rev 9b 08/2022...
Page 12 ©2022 DreamLine. All Rights Reserved DOUBLE THRESHOLD SHOWER BASE Left-Hand Drain Configuration MODEL SPECIFICATION D (in) W (in) D1 (in) W1 (in) DLT-1034481 34"×48" 34" 48" 17" 12" DLT-1036481 36"×48" 36" 48" 18" 12" DLT-1036541 36"×54" 36" 54" 18" 12"...
Page 13 ©2022 DreamLine. All Rights Reserved DOUBLE THRESHOLD SHOWER BASE Right-Hand Drain Configuration MODEL SPECIFICATION D (in) W (in) D1 (in) W1 (in) DLT-1034482 34"×48" 34" 48" 17" 12" DLT-1036482 36"×48" 36" 48" 18" 12" DLT-1036542 36"×54" 36" 54" 18" 12"...
Page 14 ©2022 DreamLine. All Rights Reserved Shower Base Installation - Preparation 1. Ensure that the floor and the studs are at right angles. Provide a 5”×5” opening in the sub- floor for the drain. The 2” PVC waste pipe should extend above the surface of the...
Page 15 ©2022 DreamLine. All Rights Reserved 2. Install the shower drain (NOT INCLUDED) according to the drain installation manual (supplied with the drain). (Fig 2) Fig 2 3. Place the tray into the designated position so that the Drain cutout drops around the Drain Pipe and butt the Shower Base up against the studs.
Page 16 ©2022 DreamLine. All Rights Reserved 4. Level the tray and place marks on the studs above the upper edge of the tile flange. (Fig 4) Level base in two directions Fig 4 5. Mix the bedding material (Mortar, cement-sand mix, etc.) Concrete or plaster is not recommended.
Page 17 ©2022 DreamLine. All Rights Reserved 6. After the bedding material has been before poured and it sets, place the shower base into the position with the drain assembly sliding over the PVC waste pipe. It will be necessary to push...
Page 19 To maximize the life of your door, it is important to regularly inspect the glass and other hardware for misalignment, proper attachment, and/or damage. Contact DreamLine with any questions or concerns. SLIMLINE SHOWER BASE manual Ver 5 Rev 9b 08/2022...
Page 20 NOTES...
Page 22 CRYLIC NSTALLATION NSTRUCTIONS IMPORTANT DreamLine reserves the right to alter, modify or redesign products at any time without prior notice. For the latest up-to-date technical drawings, manuals or any other details please refer to your model’s web page on BathAuthority.com Please read these instructions carefully before installing.
Page 23 2. Please note that you should consult your local building codes with questions about installation compliance standards. Building and plumbing codes may vary by location, and DreamLine is not responsible for code compliance standards for your project. 3. This acrylic wall system is specially designed to be installed over any solid surface. If you are installing the acrylic walls over existing tiles, remove all loose tiles before the installation.
Page 24 Before discarding the carton, check for small hardware bags that may have fallen to the bottom of the box. If any parts are damaged or missing, please contact DreamLine for replacement. The shipping boxes may contain extra parts not used in your model configuration.
Page 25 Preparation for Installation of Back Panel 1. Place a mark on the walls at a distance of 1” (one inch) from the corner and draw a plumb vertical line from top to bottom. 1" See Fig. 1 for details. NOTE: Repeat this step for both corners.
Page 26 3. The Back Panel (09) has 3-1/8” flange on both sides and has to be cut equally from both sides if necessary. See Fig. 3 for details. 4. Measure the Back Panel (09). The Width of the Back Panel has to be less than or equal to the distance between the two lines on the back wall in Step.
Page 27 5. Mark the measurement “W” on the Back Panel (09) Line and draw straight lines from top to bottom. to cut NOTE: Line The Back Panel has to be trimmed equally from both to cut sides. See Fig. 5 for details. 6.
Page 28 Preparation for Installation of Side Panels Side Panel Wall Profile ATTENTION: If you are installing a shower door with a wall profile, Wall you can hide the edge of the Side panel (01) behind the wall profile. See Fig. 8 for details. Side Panel Wall Profile Wall...
Page 29 7. Measure the side walls of the shower from the 1” (one inch) line in the corner (from Step. 1) to the distance where you want Side panels (01) to end. The distance is “D”. See Fig. 9 for details. 8.
Page 30 9. Place the Side panel (01) on a flat piece of plywood or particle board. Use a sharp industrial knife and a T- square to score along the marked wide ends of the Side panel and continue scoring until you have fully cut through the panel.
Page 31 10. Take exact measurements of the 1" fixture on the wall: • from the 1” (one inch) line in the corner of the shower to the fixture: (A, B, C) • from the bottom of the wall of the shower to the fixture: (E, F).
Page 32 12. Drill the holes for the fixtures in the Side panel (01) using the proper diameter saw bit or a handheld jig saw. See Fig. 15 for details. . 15 Acrylic Back Panel and Side Panel Installation Instruction 13. Attach the Corner cover (02) to the corner of the shower and mark the drilling holes through the predrilled holes in the Corner...
Page 33 . 17 ATTENTION: Installation of all Acrylic panels must be finished before the sealant sets for easy leveling and adjustments. 14. Apply the sealant to the entire surface of the reverse side of the Back panel (09). See Fig. 18 for details. .
Page 34 15. Attach the Back Panel (09) to the center of the back wall with the equal distance between two lines. See Fig. 19 for details. . 19 16. Mount the Corner cover (02) to the corner of the shower using Countersunk screws ST4.2×40 (07).
Page 35 17. Apply the sealant to the entire surface of the reverse side of the Side panel (01). Also, apply the sealant around the drilled holes. See Fig. 21 for details. . 21 18. Slide the narrow edge of the Side panel (01) behind the Corner cover (02).
Page 36 19. Apply sealant to the entire surface of the reverse side of the other Side panel (01). See Fig. 21 for details. 20. Slide the narrow edge of the Side panel (01) behind the Corner cover (02). Align trimmed edge of the Side panel (from Step.
Page 37 ATTENTION; Side Panel Prior to the next step, please be sure the part of the Wall wall for installation of the Decorative edge molding (03) is clean, dry and free from soap, oil and any construction debris. 22. Gently remove the plastic tape from the adhesive side Decorative of the Decorative edge molding (03) and firmly press Molding...
Page 38 Glass Shelves Installation Instruction 24. Determine the desired height for the Glass shelves (05) and mark the locations on the wall. NOTE: The Glass shelves can be installed either two in one corner, or one in each. See Fig. 27 for details. .
Page 39 26. Mount the Shelf brackets (04) to the wall using the Countersunk screws ST4.2×40 (07). NOTE: the padded set screw of the Glass bracket should be facing down. Slide the upper Glass shelf (05) into the upper Shelf brackets and tighten the set screws at the bottom of the brackets.
Page 40 Product maintenance To ensure long lasting life for your acrylic back walls, wipe them off after each use with a soft cloth. To clean the acrylic back walls use non-abrasive sprays or cream based cleaners. Never use abrasive cleansers, metal brushes or scrapers that could scratch or dull the surface. Acrylic cleaning procedure: Acrylic should be cleaned with warm water and a clean, non-abrasive cloth.
Page 41 TEL: 866-731-2244 FAX: 866-857-3638 WWW. UTHORITY.COM For more information on DreamLine Shower Back Wall please visit www.BathAuthority.com Q-Wall 5.1 (w/single back panel) manual Ver. 1 Rev. 2 08/2015...
Page 42 ® purpose of product improvement and customer experience. Please refer to the model’s web page on DreamLine.com for the latest technical drawings, installation manuals, warranty information or additional product details. Do Not Return Product to the Store. Contact DreamLine® with any questions Please contact DreamLine Customer Support See DreamLine.com for hours of operation...
Page 43 Record the following purchase information for your records or in the event you need to contact DreamLine ® Purchase Order Store/Vendor Number Purchased From OD Number Installation Date (optional) *found on the shipping box or label if available. SKU Number...
Page 44: Table Of Contents
Table of Contents Section Title Page # Warnings and General Preparation Model Specific Preparation Tools Detailed Diagram of Shower/Tub Door Components Parts List Installation Steps 8-18 Product Maintenance Troubleshooting Factory Parts Information 21-23 Symbol Legend CORRECT - Average Installation Time TIP - for ease of installation.
Page 45: Warnings And General Preparation
• • DreamLine® reserves the right to alter, modify or redesign products any time without After opening all boxes and packages, read this introduction carefully. Check that all the prior notice for product improvement and customer experience. Please refer to the items are included in the package by marking off the components on the “Detailed...
Page 46: Model Specific Preparation
Model Specific Preparation REQUIRED: 3/8” Out-of-Plumb Adjustment at Wall Profile. DO NOT ±0.0 ±0.0 EXCEED this amount. Verify tub deck and 1” minimum walls with a level threshold Threshold must be level 1” minimum ±0.0 at threshold Contact the manufacturer of the base, tub or NOTE threshold material with any questions regarding Tile...
Page 47: Tools
Diagram on page 5; and packing list in this manual as a reference. Before discarding the carton, check for small hardware bags that may have fallen to the bottom of the box. If any NOTE parts are damaged or missing, please contact DreamLine for replacement. The shipping ®...
Page 49: Parts List
Parts List Bottom Sweep Vinyl AQUA FOLD Shower and Tub Door Manual Ver 3 02/2023...
Page 50 Parts List AQUA FOLD Shower and Tub Door Manual Ver 3 02/2023...
Page 51: Installation Steps
Installation Steps Prepare and orient the NOTE panels for Hinge installation. NOTE Right-hand installation shown. Reverse for left-hand installation. Fig 1 Parts Needed Inside of Shower Door © 2023 DreamLine® All Rights Reserved...
Page 52 Installing the Hinges on Door Glass #1 with Hinged Profile Parts Needed Inside of Shower Fig 2 Tools Needed Be sure to use the gaskets on both sides of the glass to prevent glass to metal contact. © 2023 DreamLine® All Rights Reserved...
Page 53 Make sure the top edges of both doors are evenly aligned and that the space between the doors is even from top to bottom Parts Needed Inside of Shower Fig 3 Tools Needed Remove the Wall Profile from NOTE the assembly for the next step. © 2023 DreamLine® All Rights Reserved...
Page 54 Parts Needed NOTE 5/16” (8mm) for wall Bit Size anchors, or 3/16” Tools Needed (5mm) up to a stud in the wall, then 1/8” (3mm) pilot hole into the stud. Fig 4 © 2023 DreamLine® All Rights Reserved...
Page 55 Reverse for left-hand installation. Tools Needed Check the door for level and adjust for out of plumb conditions prior to connecting NOTE the profiles together from inside the shower with screws, washers and caps. © 2023 DreamLine® All Rights Reserved...
Page 56 1/8” 3mm) Bit Screws, Washers and Caps. ±0.0 ±0.0 Parts Needed Fig 6 Tools Needed Drill only through one layer of metal. Use a hand-held Phillips screwdriver to prevent stripping the holes. © 2023 DreamLine® All Rights Reserved...
Page 57 ‘Snap’ ‘Snap’ Parts Needed Right-hand installation shown. Reverse for left-hand installation. Fig 7 Tools Needed Allow the silicone to set up before NOTE proceeding to the next step. © 2023 DreamLine® All Rights Reserved...
Page 59 Installing the Side Vinyl Seal approx 1” Parts Needed Fig 9 Use a razor knife to notch the Vertical Vinyl Seal (#12) to fit around NOTE the Bottom Sweep Vinyl (#11) as shown to prevent leaks. Fig 9 © 2023 DreamLine® All Rights Reserved...
Page 60 Installing the Handle Fig 10 Parts Needed Warning: To avoid damage to the glass, always use caution when folding the doors. Make sure the metal Handle does not contact the Door Glass. © 2023 DreamLine® All Rights Reserved...
Page 61 Apply Silicone to the Interior Perimeter NOTE Use a high-quality, mildew-resistant silicone to seal the interior perimeter of the shower door. Allow 24 hours for the silicone to cure before using the shower. Tools Needed Fig 11 © 2023 DreamLine® All Rights Reserved...
Page 62: Product Maintenance
To maximize the life of your door, it is important to regularly inspect the glass and other hardware for misalignment, proper attachment, NOTE and/or damage. Contact DreamLine with any questions or concerns. ® AQUA FOLD Maintenance Checklist ◻...
Page 63: Troubleshooting
Suggested Solution •Check all shipping/packaging material for missing parts/components. Missing Parts •If not found, contact DreamLine Customer Support [1-866-731-2244] to order factory part replacement. Check the Vinyl Seals for proper trimming and installation • Confirm the Hinges (#04) are tightly secured to the Door Glass.
Page 64: Factory Parts Information
4 or 5 or 7 = Brushed SS 6 = Oil Rubbed Bronze 9 = Satin Black Contact Support@DreamLine.com for Part replacement, installation assistance or additional information. Complete Warranty information is available on DreamLine.com. © 2023 DreamLine® All Rights Reserved...
Page 65 4 or 5 or 7 = Brushed SS 6 = Oil Rubbed Bronze 9 = Satin Black Contact Support@DreamLine.com for Part replacement, installation assistance or additional information. Complete Warranty information is available on DreamLine.com. © 2023 DreamLine® All Rights Reserved...
Page 66 4 or 5 or 7 = Brushed SS 6 = Oil Rubbed Bronze 9 = Satin Black Contact Support@DreamLine.com for Part replacement, installation assistance or additional information. Complete Warranty information is available on DreamLine.com. © 2023 DreamLine® All Rights Reserved...
