It is perfectly safe to switch off the power without shutting down the operating system. The
Multi Scan NXA83B contains an Enhanced Write Filter which protects the system from
being corrupted due to a loss of power (see configuration document for description).
5.2

Status Bar

At the bottom of the Multi Scan NXA83B display screen is a status bar which will display the
following information:
Field Description
This field will show the currently logged in user account
NXA83_Display_Field_User
This field shows any information that is current to the system. This could include
such messages as:
• Watchdog Disabled
NXA83_Display_Field_Info
• W&M Approved
• W&M Unsealed (i.e. no longer approved)
This shows the current time
NXA83_Display_Field_Time
Operation
NXA83_Display_Grid-View
