Supported alarms

Table 15: System settings
Description
Temperature Sensor
Sn-1
Temperature
Sensors Sn-1 and
Sn-2 & Pressure
Transducer Sn-3
System 450
communications
bus
Defrost termination Defrost termination
Defrost error
System 450 Series C450CCU Condensing Unit Control System Technical Bulletin
Alarm
High Temperature
Sensor failure, Open or
shorted Condition
Communication failure
between System 450
control and expansion
modules
failure
Defrost termination
sensor reading is at
or above termination
setting at the start of
the defrost cycle
Display
Notes
indicator
S1-H Auto resets when Sn-1 drops to
80% of the high temperature alarm
set-point. This alarm is disabled
during defrost. There is a user-
defined alarm delay for the high
temperature alarm. This delay
displays in units of minutes.
SNF Auto resets when the alarm
condition no longer exists. There is
a fixed thirty second delay for the
sensor failure alarm.
bUS The bUS ALRM screen shows
the sequential number of the
Expansion Module which is
not in communication with the
Control Module. Auto resets when
communications are re-established.
The alarm activates after three
consecutive communication faliures.
dtEr FAIL Occurs when an active defrost,
with a defined termination sensor,
runs the full defrost cycle without
reaching the termination setting
defined value. Auto resets when
the next defrost cycle starts, either
manually or scheduled. The alarm
displays again if the next defrost
terminates on time and not on
temperature.
dErr NOTC Auto resets if the termination sensor
does not indicate a termination
condition when the next active
defrost starts. You can start a
manual defrost to clear the alarm
manually. The alarm displays again
if the termination sensor is at or
above the defrost termination
setting at the start of the next
defrost cycle.
