Gigabit Ethernet (1 Gbps) Optical Specifications
Note
These transceivers utilize a distributed feedback (DFB) type laser and are rated for -20
to 85 °C (-4 to 185 °F) operation only.
Mode Connector
Type
MM LC
MM LC
SM LC
SM LC
a
All cabling is duplex type unless specified otherwise.
b
Typical.
c
All optical power numbers are listed as dBm averages.
d
Typical distance. The maximum segment length is greatly dependent on factors such as fiber quality, and the number of patches and splices. Consult a
Siemens sales associates when determining maximum segment distances.
5.6

Operating Environment

The RUGGEDCOM M2200 is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
Ambient Storage
Temperature
Ambient Relative
Humidity
Maximum Altitude
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
b
Non-condensing
5.7

Mechanical Specifications

Weight
Ingress Protection
Enclosure
RUGGEDCOM M2200
Installation Manual, 11/2022, C79000-G8976-1044-19
Cable Tx λ
b
Type (nm)
Minimum Maximum
a
(µm)
50/125 850
62.5/125 850
9/125 1310
9/125 1310
-40 to 85°C (-40 to 185 °F)
a
-40 to 85°C (-40 to 185 °F)
5% to 95%
b
2000 m (6562 ft)
4.8 kg (10.6 lbs)
IP30
18 AWG Galvanized Steel
c
Tx (dBm)
Sensitivity
(dBm)
-9 -2.5 -20
-9 -2.5 -20
-9.5 -3 -21
-7 -3 -24
Technical Specifications
5.6 Operating Environment
Rx Rx Distance
Saturation (km)
c c
(dBm)
0 0.5
0 0.5
-3 10
-3 25
Power
d
Budget
(dB)
11
11
11.5
17
27
