5.4 Copper Ethernet Port Specifications
IEEE 802.1x
802.1Q-2005
5.4

Copper Ethernet Port Specifications

The following details the specifications for copper Ethernet ports that can be ordered
with the RUGGEDCOM M2200.
Note
•
•
•
Connector
Speed
Duplex
Cable Type
Wiring Standard
Maximum Distance
Isolation
a
Auto-Negotiating
b
Shielded or unshielded.
c
Auto-crossover and auto-polarity.
d
Typical distance. Dependent on the number of connectors and splices.
e
RMS 1 minute.
5.5

Fiber Optic Ethernet Port Specifications

The following details the specifications for fiber Ethernet ports that can be ordered
with the RUGGEDCOM M2200.
26
Standard 10 Mbps Ports
ü
IEEE
ü
(formerly
802.1s)
Maximum segment length is greatly dependent on factors such as fiber quality,
and the number of patches and splices. Consult a Siemens sales associate when
determining maximum segment distances.
All optical power numbers are listed as dBm averages.
F51 transceivers are rated for -40 to 85 °C (-40 to 185 °F).
micro-D
1000 Mbps
a
FDX/HDX
b
> CAT-5
c
TIA/EIA T568A/B
d
100 m (328 ft)
e
1.5 kV
100 Mbps 1000 Mbps
Ports Ports
ü ü
ü ü
Description
Port-Based Network Access
Control
Multiple Spanning Tree Protocol
(MSTP)
RUGGEDCOM M2200
Installation Manual, 11/2022, C79000-G8976-1044-19
