4. S
U
TART
With the PWRBTN# signal, the system can be started. Activating this signal a second time will shut the
system down.
How to Activate PWRBTN#
The PWRBTN# signal must be connected to a ground to be activated.
Minimum activation time is 3 seconds for the controller to start/stop the system.
A few seconds after powering up the board, the screen should display the BIOS initial messages/pictures.
/ P
O
P
OWER
B
FF THE
OARD
18
SMX945 Condensed Manual V1.0A
