3.2. Connect Peripherals to the Board

Prepare the following peripherals:
VGA Monitor (LCD or CRT) with a resolution up to 1024x768pixel
PS2 Keyboard
USB Mouse
LAN-Cable, if available
Hard disk or CompactFlash
USB CD-Drive or Floppy drive
Power supply with 12Volt and min. 30Watts
1. Connect the VGA-Monitor to the 15pin high density DSub-connector.
2. Connect the Keyboard to the PS/2 connector.
3. Connect the USB-Mouse to one of the USB-connectors.
4. Connect the hard disk with a 44pin cable to the IDE-connector.
Alternatively to the hard disk, the CompactFlash-Card may be inserted into the CF-socket.
5. Connect a USB CD-Drive or a USB Floppy drive to one of the USB connectors.
6. Connect the 12Volt power supply to the power input of the computer board.
7. Insert a boot device: USB-Stick, Floppy or bootable CF.

3.3. The Development Kit, Part Nr. 805390

The Development Kit (DK) is currently unavailable but would allow for an immediate start-up with the
embedded system. The hard disk includes a DOS and a LINUX kernel V2.6 boot partition.
The material which will be included in the SMX945PC-DK (Development Kit) is not yet decided.
Item
The polarity must be correct. Pin1 of the cable must go to Pin1 of the connector,
which has a red mark next to it (not visible in the photo). Otherwise the hard disk
and/or the computer may be destroyed.
The polarity must be correct. Otherwise the electronic board may be destroyed.
Part Nr.
