2.4. Specifications

CPU
CoreDuo / Celeron M
Clock
st
1 Level Cache
nd
2 Level Cache
Technology
VCCCore @ 1.6GHz
VCCCore @ 0.6GHz
VCCCore @ deep sleep
CPU-Bus
AGTL+ Termination
FSB
Mathematics Coprocessor
Intel 945GME Graphics Memory Controller Hub
Memory Controller
Supports
Socket
Technologies
Capacity
Voltage
Termination
Width
ECC-Support
Intel 945GME Graphics Memory Controller Hub
Graphic Controller
Alternative to the PEG Interface
Max. Video memory
Graphic Core Frequency
3D Graphic Engine
Direct-X Compatibility
Analog CRT
SDVO Port
Flat Panel Interface
TV Out
Specification
Intel Core Duo L2400
Intel Core 2 Duo L7400 LV
Intel Celeron M423
Intel Celeron M440
1GHz up to 1.86GHz
2x 32kByte
1, 2, 4 MByte (on die)
65nm
1.308V
0.844V
0.748V
AGTL+
Integrated
533/666MHz quad-pumped synchron bus
Available on the PENTIUM CPU
Specification
PC1600 / PC2100 / PC2700
DDR2 SODIMM 200pin
DDR2-667
256MByte up to 2GByte (3GByte with SMX945B)
2.5V
1.25V
64bit
No
Specification
224MByte with Intel GMA950
400MHz
3D-setup and rendering engine
Zone rendering
Texture engine
Direct-X9
400MHz RAMDAC with 24bit
Resolution up to 2048 x 1536 @ 70Hz (QXGA)
Hardware cursor support
I2C and DDC channels
Dual independent display
2 channels (multiplexed with the PEG signals)
2x 200 Mpixel/sec
Support for up to 2x DVI, 1x TV and 2x LVDS
Dotclock = 165MHz
Compliant with DVI Spec.1.5
2 channel LVDS interface
1x 18, 2x 18, 1x24, 2x24bpp TFT
Dotclock = up to 2x 112 MHz
Resolutions 640 x 480 up to 1600 x 1200 (UXGA)
Automatic panel detection via VESA EDID 1.3
Disabled.
A Macrovision license is required.
12
SMX945 Condensed Manual V1.0A
LV 2x 1.66GHz with 2MB L2-cache
2x 1.66GHz with 4MB L2-cache
ULV 1x 1.06GHz with 1MB L2-cache
1x 1.86GHz with 1MB L2-cache
