- Page 1 K&F Adjustable Speaker Mount PASSIO Version 1.4 User's Manual Released: 19.01.2017 Translation of the original instructions Important Information, Please Read Before Use! KLING & FREITAG GmbH Wohlenbergstraße 5 D-30179 Hannover TEL +49 (0) 511 96 99 70 FAX +49 (0) 511 67 37 94...
-
Page 3: Table Of Contents
User's Manual K&F Adjustable Speaker Mount PASSIO Table of contents Introduction Icons Used About these user's manual Product Description Intended Use Items Included Components Safety Instructions Mounting the Speakers / Wall and Ceiling Installation Admissible load capacity Installation and Usage Instructions... -
Page 4: Introduction
KLING & FREITAG PASSIO speaker system to achieve its full potential, please read these user's manual carefully before use. This item is a quality accessory for the PASSIO speaker system. Combining it with your existing speaker system creates an extremely versatile pro-grade tool that meets all requirements in terms of audio quality and safe installation. -
Page 5: Product Description
The Adjustable Speaker Mount PASSIO is solely for commercial use and may only be used with the loudspeaker PASSIO in the manner described here. The Adjustable Speaker Mount PASSIO may not be used to lift and secure people or objects other than the above-mentioned speaker systems. -
Page 6: Components
User's Manual K&F Adjustable Speaker Mount PASSIO Components KLING & FREITAG 'Fixing Pin' Clamp lever M10 Mounting plate Spacer plate Mounting hole Locking pins Bracket Lock nut M10 Thread M10 10. Cover cap, protects the 'Fixing Pins' from being pressed unintentionally KLING &... -
Page 7: Safety Instructions
The information described here does not relieve the user of the duty to follow the given safety requirements and legal regulations. Admissible load capacity The speaker accessories Adjustable Speaker Mount PASSIO may only be used with a speaker of the type PASSIO with a maximum weight of 6.5 kg (BGV C1). Warning KLING &... -
Page 8: Installation And Usage Instructions
1.Let go of the release button when you have completely inserted the bolt so that the release button pops back up. 2.Check if the Adjustable Speaker Mount PASSIO is securely mounted on the speaker. KLING & FREITAG GMBH © 2017 Version 1.4... - Page 9 C Warning You can alternately get the Adjustable Speaker Mount PASSIO with a screw fastening: M10 bolt including washer and lock washer instead of a 'Fixing Pin' and self-locking M10 screw nut instead of a clamp lever.
-
Page 10: Dimensions And Weight
User's Manual K&F Adjustable Speaker Mount PASSIO Dimensions and Weight Self weight: 0.8 kg 146,9 mm [5,783 in] 55,5 mm [2,185 in] 32,5 mm [1,28 in] 63,1 mm [2,486 in] 36,5 mm [1,437 in] 89,3 mm [3,515 in] KLING & FREITAG GMBH © 2017 Version 1.4... -
Page 11: Ec Declaration Of Conformity
User's Manual K&F Adjustable Speaker Mount PASSIO EC Declaration of Conformity applicable to all products designated hereafter and distributed by KLING & FREITAG GmbH including model variants unless these products have been altered afterwards. Mechanical speaker accessories: FIXING PIN Mounting bracket GRAVIS 12... -
Page 12: Accessories
Mini TV spigot with internal M10 thread. Necessary for suspending the Adjustable Speaker Mount with a Super Clamp! for use with the accessory Adjustable Speaker Mount PASSIO with a 'Super Clamp' Colour: black Stand socket M10 for use with the Adjustable Speaker... -
Page 13: Care And Maintenance
Make sure that the system is adequately ventilated during longer storage periods so any residual moisture can escape from the equipment. Furthermore, you have to ensure that the accessory Adjustable Speaker Mount PASSIO is protected from mechanical strain to prevent possible damage. - Page 14 User's Manual K&F Adjustable Speaker Mount PASSIO INDEX • Accessories........................... 12 • Care.............................. 13 • Components...........................6 • Dimensions...........................10 • Disposal............................13 • EC Declaration of Conformity....................11 • Intended Use..........................5 • Items Included..........................5 • Maintenance..........................13 • Mounting............................8 •...
