- Page 1 K&F Mounting Bracket PASSIO Version 2.3 User's Manual Released: 19.01.2017 Translation of the original instructions Important Information, Please Read Before Use! KLING & FREITAG GmbH Wohlenbergstrasse 5 D-30179 Hannover TEL +49 (0) 511 96 99 70 FAX +49 (0) 511 67 37 94...
-
Page 3: Table Of Contents
User's Manual K&F Mounting Bracket PASSIO Table of contents Introduction Icons Used About these user's manual Product Description Intended Use Items Included Components Safety Instructions Mounting the Speakers / Wall and Ceiling Installation Admissible load capacity Installation and Usage Instructions... -
Page 4: Introduction
KLING & FREITAG PASSIO speaker system to achieve its full potential, please read these user's manual carefully before use. This item is a quality accessory for the PASSIO speaker system. Combining it with your existing speaker system creates an extremely versatile pro-grade tool that meets all requirements in terms of audio quality and safe installation. -
Page 5: Product Description
Intended Use The speaker accessory 'K&F Mounting Bracket PASSIO' is solely for commercial use and may only be used with the PASSIO loudspeaker in the manner described here. The speaker accessory may not be used to lift and secure persons or objects other than the abovementioned PASSIO loudspeaker. -
Page 6: Components
User's Manual K&F Mounting Bracket PASSIO Components K&F Mounting Bracket PASSIO M10 bolt Flat washer Neoprene washer Set screw (2x) KLING & FREITAG GMBH © 2017 Version 2.3 Page 6 of 12... -
Page 7: Safety Instructions
Admissible load capacity The speaker accessory 'K&F Mounting Bracket PASSIO' may only be loaded with one speaker model PASSIO with a maximum weight of 6 kg (BGV C1). We recommend securing every mounted speaker with a safety element. -
Page 8: Installation And Usage Instructions
Only the included M10 bolts may be used for mounting the speakers. The Mounting Bracket can be rotated and locked on the PASSIO loudspeaker in steps of 90°. The possible adjustment angle between the PASSIO loudspeaker and the wall depends on the mounting position. -
Page 9: Dimensions And Weight
User's Manual K&F Mounting Bracket PASSIO Dimensions and Weight Handhold weight (incl. bolts): 0.5 kg 0.6 293,2 mm [11,545 in] 386,1 mm [15,201 in] 123,1 mm [4,845 in] 160,2 mm 95,0 mm [6,306 in] [3,74 in] 182,3 mm [7,179 in]... -
Page 10: Manufacturer's Declaration
User's Manual K&F Mounting Bracket PASSIO Manufacturer's Declaration Type: Mechanical speaker accessory Model: K&F Mounting Bracket PASSIO System: PASSIO The following standards have been applied: • DIN EN ISO 12 100 • DIN EN 18 800 • BGV C1 Hannover, 23.02.2012 Jürgen Freitag (CEO) -
Page 11: Care And Maintenance
Transportation and Storage The speaker accessory 'K&F Mounting Bracket PASSIO' is protected against short term moisture. Store, transport, and use the accessories in dry environments only. This speaker accessory is not designed for long-term use in a corrosive environment. - Page 12 User's Manual K&F Mounting Bracket PASSIO INDEX • Care.............................. 11 • Components...........................6 • Dimensions.............................9 • Disposal............................11 • Intended Use..........................5 • Items Included..........................5 • Maintenance..........................11 • Manufacturer's Declaration......................10 • Mounting............................8 • Product Description........................5 • Safety Instructions......................... 7 •...
