- Page 1 Adjustable Speaker Mount PASSIO Version 1.2 User's Manual Released: 15.01.2016 Important Information, Please Read Before Use! KLING & FREITAG GmbH Junkersstraße 14 D-30179 Hannover TEL +49 (0) 511 96 99 70 FAX +49 (0) 511 67 37 94 www.kling-freitag.de...
-
Page 3: Table Of Contents
User's manual Adjustable Speaker Mount PASSIO Table of contents Introduction Symbols in User's Manual Information about this User's Manual Product Description Scope of Delivery Overview of Components Accessories Safety Instructions Mounting the Speakers / Wall and Ceiling Installation Intended Use... -
Page 4: Introduction
User's manual Adjustable Speaker Mount PASSIO Introduction Symbols in User's Manual This symbol indicates the possibility of life-threatening danger and a health risk for persons. Not following these instructions may result in serious health problems including potentially fatal injuries. Warning This symbol indicates a possibly dangerous situation. -
Page 5: Product Description
Adjustable Speaker Mount PASSIO Product Description Scope of Delivery • Adjustable Speaker Mount PASSIO with mounting plate, captive 'Fixing Pin' and clamp lever M10 (optionally with M10 screw instead of 'Fixing Pin' and with nut instead of clamp lever). •... - Page 6 User's manual Adjustable Speaker Mount PASSIO 10. Cover cap, protects the 'Fixing Pins' from being pressed unintentionally KLING & FREITAG GMBH © 2015 Version 1.2 Page 6 of 13...
-
Page 7: Accessories
Mini TV spigot with internal M10 thread. Necessary for suspending the Adjustable Speaker Mount with a Super Clamp! for use with the accessory 'Adjustable speaker mount PASSIO' with a 'Super Clamp' Colour: black Stand socket M10 for use with the 'Adjustable Speaker... -
Page 8: Safety Instructions
The Adjustable Speaker Mount PASSIO is solely for professional use and may only be used with the loudspeaker PASSIO in the manner described here. The Adjustable Speaker Mount PASSIO may not be used to lift and secure people or objects other than the above-mentioned speaker systems. -
Page 9: Installation And Usage Instructions
User's manual Adjustable Speaker Mount PASSIO Admissible load capacity The speaker accessories Adjustable Speaker Mount PASSIO may only be used with a speaker of the type PASSIO with a maximum weight of 6.5 kg (BGV C1). Warning Installation and Usage Instructions 1.Place the speaker on a stable support. - Page 10 C Warning You can alternately get the Adjustable Speaker Mount PASSIO with a screw fastening: M10 bolt including washer and lock washer instead of a 'Fixing Pin' and self-locking M10 screw nut instead of a clamp lever.
-
Page 11: Transport And Storage
Make sure that the system is adequately ventilated during longer storage periods so that possible residual moisture can escape from the equipment. Furthermore, you have to ensure that the accessory Adjustable Speaker Mount PASSIO is protected from mechanical strain to prevent possible damage. -
Page 12: Dimensions And Weight
User's manual Adjustable Speaker Mount PASSIO Dimensions and Weight Self weight: 0.8 kg 146,9 mm [5,783 in] 55,5 mm [2,185 in] 32,5 mm [1,28 in] 63,1 mm [2,486 in] 36,5 mm [1,437 in] 89,3 mm [3,515 in] Disposal Dispose of this product in compliance with your national regulations. -
Page 13: Ec Declaration Of Conformity
User's manual Adjustable Speaker Mount PASSIO EC Declaration of Conformity for the products mentioned hereafter including model variants from KLING & FREITAG GmbH provided the products have not been altered subsequently. Mechanical speaker accessories: FIXING PIN Mounting bracket GRAVIS 12...
