Summary of Contents for KLING & FREITAG Single Bar
- Page 1 KLING & FREITAG SINGLE BAR (ALIGN) Version 1.0 User's Manual Released: 01.06.2007 Important Information, Pease Read Before Use! KLING FREITAG GmbH & Wohlenbergstrasse 5 D-30179 Hannover PHONE 0 (049) 511- 969 97-0 FAX 0 (049) 511- 67 37 94 www.kling-freitag.de...
- Page 2 User's Manual SINGLE BAR ( ALIGN) KLING & FREITAG GMBH ©2003-2007 Version 2.0, 01.06.2007 Page 2 of 23...
- Page 3 Important Information about this User's Manual User's Manual SINGLE BAR (ALIGN) Version 1.0, 01.06.2007 © by André Figula, Kling & Freitag GmbH, November 2003; all rights reserved. All specifications in this manual are based on information available at the time of pub- lishing for the features and safety guidelines of the described products.
-
Page 4: Table Of Contents
6.2.2 Strap Anchoring for 2 ACCESS Systems 7. Mounting the Single Bar (Align) 8. Dismantling 8.1 Releasing the Rigging Straps 9. Use of the Single Bar with other K&F Systems 10. Care and Maintenance 11. Dimensions, Weight and Permissible Load Capacity 11.1 Single Bar 11.2 Single Bar 'Align'... -
Page 5: Scope Of Delivery And Part Definitions
User's Manual SINGLE BAR (ALIGN) 1. Scope of Delivery and Part Definitions 1.1 Single Bar Thread M6 for fixing the swivel bracket Drill holes for safety rope Central suspension drill hole Single Bar 2 x ½ inch shackle, high strength... -
Page 6: Safety Instructions
The Single Bar ('Align') must be used only for the prescribed purpose and in the stated manner laid down in this document. For assembly only original Kling & Freitag parts may be used. -
Page 7: Wire Ropes And Chains
User's Manual SINGLE BAR (ALIGN) 3. Wire Ropes and Chains The loudspeaker systems are suspended from the Single Bar by means of wire ropes or chains. The vertical angle of array between speaker systems suspended one above the other is dependent upon the length of the wire ropes or chains between the flying points of the speaker systems. -
Page 8: Use With K&F Access Systems
Single Bar. Single Bar. The uppermost chains/ropes, i.e. those on the Single Bar, must have a work k k k ing The uppermost chains/ropes, i.e. those on the Single Bar, must have a wor The uppermost chains/ropes, i.e. those on the Single Bar, must have a wor The uppermost chains/ropes, i.e. -
Page 9: K&F Curving Hook
User's Manual SINGLE BAR (ALIGN) 5. K&F Curving Hook The Curving Hook is not absolutely essential when suspending several ACCESS Sys- tems one above the other. Its use can, however, simplify the assembly procedure, considerably reducing assembly and dismantling times. The Curving Hook prevents systems suspended one below the other from turning towards each other and ensures that the rear edges of the suspended systems align with each other. -
Page 10: Rigging Straps
User's Manual SINGLE BAR ( ALIGN) 6. Rigging Straps The rigging strap serves to align the speaker array vertically, while the angle of array between the speaker systems is determined by the length of the chains which join them. The tension of the strap is set using the ratchet. When securing the straps it must be ensured that the speaker array clears the ground. -
Page 11: One-Piece K&F Rigging Strap
User's Manual SINGLE BAR (ALIGN) To avoid overloading the rigging strap reel the strap should be drawn out manually, in other words the strap end should be pulled so far until only so much strap remains as can be taken up by the rigging strap reel. -
Page 12: Strap Anchoring For 2 Access Systems Without Curving Hook
User's Manual SINGLE BAR ( ALIGN) 6.1.2 Strap Anchoring for 2 ACCESS Systems without Curving Hook 2 x ACCESS System: Caution KLING & FREITAG GMBH ©2003-2007 Version 2.0, 01.06.2007 Page 12 of 23... -
Page 13: Strap Anchoring For 2 Access Systems With Curving Hook
User's Manual SINGLE BAR (ALIGN) 6.1.3 Strap Anchoring for 2 ACCESS Systems with Curving Hook 2 x ACCESS System + Curving Hook: Caution KLING & FREITAG GMBH ©2003-2007 Version 2.0, 01.06.2007 Page 13 of 23... -
Page 14: Two-Piece K&F Rigging Strap
User's Manual SINGLE BAR ( ALIGN) 6.2 Two-Piece K&F Rigging Strap The use of a two-piece strap offers the following advantages: − The strap is subjected to less friction, reducing wear and extending lifespan. − Compared with the one-piece strap, the rigging distance when using a two- piece strap is only half as long. -
Page 15: Strap Anchoring For 2 Access Systems
User's Manual SINGLE BAR (ALIGN) 6.2.2 Strap Anchoring for 2 ACCESS Systems The use of the two-piece strap for the suspension of two ACCESS Systems is possible only when the Curving Hook is used. Without the Curving Hook the two ACCESS Systems would slide against one another. -
Page 16: Mounting The Single Bar (Align)
Single Bar Align. The description only differs in the instructions for the Align Set. Make sure the girder or truss upon which the Single Bar is to be mounted is of ade- quate dimensions and is capable of bearing the weight with regard to the relevant safety requirements. - Page 17 Mount the chains or ropes on the drill-holes intended for securing the loudspeakers on the Single Bar. The chains / wire ropes on the Single Bar The chains / wire ropes on the Single Bar The chains / wire ropes on the Single Bar The chains / wire ropes on the Single Bar must have a working length of 510 mm.
- Page 18 User's Manual SINGLE BAR ( ALIGN) Fasten the chains or wire ropes to the rig- ging studs. − Take care when using chains with hooks that the open ends of the hooks face for- ward! This prevents the openings of the...
- Page 19 14. Having secured the rigging strap, you can align the system horizontally. To this end turn the Single Bar until you reach the de- sired position. The small tube clamp on the swivel bracket shifts along the tube while it is being turned.
-
Page 20: Dismantling
When using the K&F Single Bar in conjunction with other K&F systems pay particular attention to the maximum permissible load capacity of the Single Bar as well as that of the various K&F speaker systems. Observe national safety regulations and adhere to applicable safety and design factors. -
Page 21: Care And Maintenance
User's Manual SINGLE BAR (ALIGN) 10. Care and Maintenance For the owner and user it is of the utmost importance to be aware that a rigging sys- tem is an extremely safety-sensitive accessory within a loudspeaker system. For this reason it is absolutely imperative to carry out careful and well-documented maintenance procedures and checks. -
Page 22: Dimensions, Weight And Permissible Load Capacity
User's Manual SINGLE BAR ( ALIGN) 11. Dimensions, Weight and Permissible Load Capacity 11.1 Single Bar Weight: 8,5 kg Weight: 8,5 kg Weight: 8,5 kg Weight: 8,5 kg Permissible load capacity: 200 kg Permissible load capacity: 200 kg Permissible load capacity: 200 kg Permissible load capacity: 200 kg KLING &... -
Page 23: Single Bar 'Align
User's Manual SINGLE BAR (ALIGN) 11.2 Single Bar 'Align' Weight: 8,5 kg (incl. Single Bar) Weight: 8,5 kg (incl. Single Bar) Weight: 8,5 kg (incl. Single Bar) Weight: 8,5 kg (incl. Single Bar) Permissible load capacity: 200 kg Permissible load capacity: 200 kg...
