- Page 1 Operating Instructions WS-PS501 Portable Power Station 500 W Item no: 2619334...
-
Page 2: Table Of Contents
Table of Contents Introduction ..............................Intended use..............................Delivery contents ............................Latest product information ..........................Description of symbols........................... Safety instructions ............................General.............................. Handling ............................Operating environment........................Charging............................Operation............................Power adapter........................... LED light............................Connected devices..........................Product overview ............................Front view............................Side views ............................Display............................... - Page 3 15.6 AC output ............................15.7 Light..............................15.8 Operating and storage environment....................15.9 Others..............................15.10 Power adaptor........................... 15.11 Car charger cable..........................
-
Page 4: Introduction
1 Introduction Dear customer, Thank you for purchasing this product. If there are any technical questions, please contact: www.conrad.com/contact 2 Intended use The product is a portable rechargeable power station. Use the product: ■ to power mains-powered appliances (230 V/AC) ■... -
Page 5: Description Of Symbols
5 Description of symbols The following symbols are on the product/appliance or are used in the text: The symbol warns of hazards that can lead to personal injury. The symbol warns of dangerous voltage that can lead to personal injury by electric shock. This product must only be used in dry, enclosed indoor areas. -
Page 6: Charging
■ Protect the product from high humidity and moisture. ■ Protect the product from direct sunlight. 6.4 Charging ■ You are strongly advised to attend the product while it is being charged. In case of malfunction, immediately dis- connect the power supply to the product. ■... -
Page 7: Led Light
– Switch off the mains voltage to the socket containing the power adapter (switch off the corresponding circuit breaker or remove the safety fuse, and then switch off the corresponding RCD protective switch). – Unplug the power adapter from the mains socket. –... -
Page 8: Product Overview
7 Product overview 7.1 Front view Component Function/Description Display ■ Light Light with light modes: solid, SOS, flashing, off ■ Light button Light Press to switch light on. ■ Press to change light modes. ■ AC output activation button AC ON/OFF Press to activate mains output ports. -
Page 9: Side Views
Component Function/Description ■ Press to deactivate DC output ports. ■ DC input port INPUT Connect the supplied power adaptor or another suit- able power source to charge the rechargeable bat- tery. 7.2 Side views Component Function/Description Cooling fans... -
Page 10: Display
7.3 Display Component Description ■ Battery indicator Indicates the charging and discharging status of the re- chargeable battery. ■ High/low temperature indicator Lights up if the temperature is too low or too high. Product will stop operating. ■ Fan status indicator Lights up if the cooling fans run. -
Page 11: Getting Started
8 Getting started 8.1 Switching on/off 1. Press any output port activation button to switch the product on. à The display will light up. 2. Press two output port activation buttons at the same time to switch the product off. Note: You cannot switch the product off while the product battery is being charged. -
Page 12: Powering Devices (Output)
9 Powering devices (Output) 9.1 Connecting devices The product can power AC and DC powered devices. Connect your device to a port that meets the voltage and power requirements of the device. 1. Switch off the device. 2. Select a port on the product that meets the requirements of your device you want to power. Refer to the “Tech- nical data”... -
Page 13: Troubleshooting
11 Troubleshooting Problem Possible cause Suggested solution Temperature symbol Overtemperature protec- 1. Disable all output ports by pressing the output activation tion was triggered. buttons. is flashing. 2. Let the product cool down. Alarm is sounding. 3. Check if there are objects that cover the cooling fan inlet and outlet. -
Page 14: Disposal
14 Disposal This symbol must appear on any electrical and electronic equipment placed on the EU market. This sym- bol indicates that this device should not be disposed of as unsorted municipal waste at the end of its ser- vice life. Owners of WEEE (Waste from Electrical and Electronic Equipment) shall dispose of it separately from unsorted municipal waste. -
Page 15: Input
15.4 Input DC input port (barell jack) Unit Value Number of ports Input voltage V/DC 12 - 30 PV input voltage V/DC 12 - 30 Input current MPPT support 15.5 DC Output Barrell DC output port Unit Value Number of ports Output voltage V/DC 12 - 14... - Page 16 USB-C® output port (100 W) Unit Value Number of ports Output voltage/current V/DC, A 5/9/12/15 V/DC, 3 A; 20 V/DC, 5 A Max. output power 15.6 AC output Unit Value Number of ports Output voltage V/AC 220 - 240 Output voltage frequency Rated power (all sockets) Peak power (all sockets) 1000...
- Page 17 15.10 Power adaptor Unit Value Input voltage V/AC 100 - 240 Input voltage frequency 50/60 Input current Output voltage V/DC Output current 15.11 Car charger cable Unit Value Input voltage V/DC 12 - 30...
- Page 20 This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights including translation reserved. Reproduction by any method (e.g. photocopying, microfilming or the capture in electronic data processing systems) requires prior written approval from the editor. Reprinting, also in part, is pro- hibited.
