Spa Electrics Matrix LWB Series Instruction & Owner's Manual

Fibreglass waterblade
Hide thumbs

Advertisement

Quick Links

Download this manual
FIBREGLASS WATERBLADE
INSTALLATION

Advertisement

loading
Need help?

Need help?

Do you have a question about the Matrix LWB Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Spa Electrics Matrix LWB Series

Summary of Contents for Spa Electrics Matrix LWB Series

  • Page 1 FIBREGLASS WATERBLADE INSTALLATION...
  • Page 2 SPECIFICATIONS READ THIS FIRST INCLUDED PARTS FINISHED INSTALLATION INSTALLATION MOUNTING WIRING SPECIFICATIONS INPUT: 12V AC 2A ONLY OUTPUT: 24V DC 1A MAX MAX STRIP LENGTH : 5 METERS (TOTAL) MAX CABLE LENGTH: MATRIX EXTENSION CABLES) 40M - (USE ONLY FUSE: 2A BLADE FUSE 0°C ~ +40°C MAX OPERATING TEMPERATURE:...
  • Page 3 • Pool chemicals & pH levels: Due to the corrosive nature of unbalanced pool chemicals, Spa Electrics strongly recommends that your pool water is balanced prior to installing your lights or any plastic or stainless steel components, and tested weekly to maintain these levels. pH levels should be maintained between 7.2 –...
  • Page 4 STRIP LIGHT DRIVER 1.2M STRIP LIGHT 1M INPUT POWER CABLE 5M STRIP LIGHT POWER CABLE ADDITIONAL EXTENSION CABLES AVAILABLE IN 20, 30, 40M LENGTHS. CONTACT SPA ELECTRICS FOR MORE INFORMATION.
  • Page 5 MATRIX STRIP LIGHT POWER CABLE WATERBLADE 25MM ELECTRICAL CONDUIT TO TRANSFORMER WATER INLET INTERNAL ACCESS TO STRIP LIGHT IS STRONGLY RECOMMENDED...

  • Page 6: Installation - Mounting

    INSTALLATION – MOUNTING REMOVE ADHESIVE REMOVE ADHESIVE PEEL COAT POSITION STRIP LIGHT POSITION STRIP LIGHT OVER WATER BLADE ADHERE STRIP LIGHT AS CLOSE AS POSSIBLE TO EXTERNAL LIP OF WATER BLADE...
  • Page 7 ADHERE STRIP LIGHT ENSURE SURFACE IS DRY AND FREE OF DEBRIS BEFORE APPLICATION PRESS FIRMLY BY HAND TO ENSURE A STRONG ADHESION WARNING PROVIDED TAPE MUST BE USED TO ADHERE STRIP LIGHT. ANY ALTERNATIVE MAY VOID ON-SITE WARRANTY. STRIP LIGHT TOO LONG? EACH STRIP LIGHT CAN BE SHORTENED BY SIMPLY TRIMMING TO THE DESIRED LENGTH USING A PAIR OF SCISSORS.

  • Page 8: Installation & Wiring

    INSTALLATION – WIRING CONNECT PLUG HALVES ALIGN KEY WAY AND PRESS PLUG HALVES TOGETHER. TIGHTEN PLUG COLLAR FIRMLY BY HAND.

  • Page 9: Pin Connection

    5 PIN CONNECTION TO STRIP LIGHT 5 PIN CONNECTION CONNECT STRIP LIGHT POWER CABLE TO DRIVER BY ALIGNING KEY WAY AND PUSHING ONTO MATING CONNECTOR. 2 PIN CONNECTION TO 12V AC POWER SUPPLY 2 PIN CONNECTION CONNECT INPUT CABLE TO DRIVER BY ALIGNING KEY WAY AND PUSHING ONTO MATING CONNECTOR.

  • Page 10: Transformer Connection

    TRANSFORMER CONNECTION MOUNT THE DRIVER WITHIN 1 METER OF THE CHOSEN POWER SUPPLY. MAX LENGTH 1M SYSTEM COMPATIBLITY This lighting system is compatible with the following power supplies / controllers. LV SERIES TRANSFORMERS iRIS REMOTE CONTROL 3rd PARTY POOL CONTROLLERS...
  • Page 11 PAGE LEFT INTENTIONALLY BLANK...
  • Page 12 Spa Electrics 2020 20220509...
